24
Specifications
MODEL 14LK22
Receiving System NTSC
Reception Channels
AIR VHF 2-13 CH
UHF 14-69 CH
CATV 1-125 CH
Channel Tuning 181-Chnnel Reception PLL tuning system
Antenna Input Impedance VHF/UHF 75 ohm Unbalanced
Screen Size 14˝ Diagonally Measured
Terminals Audio/Video input x 2 (Front x 1, Rear x 1)
Sound Output 1.0 W (MAX)
Power Source AC 110-220 V, 50/60 Hz
Power consumption 53 W
Dimensions 14
1
/
32
˝ (W) x 12
11
/
16
˝ (H) x 14
21
/
32
˝ (D)
[355.5 mm (W) x 322.0 mm (H) x 372.0 mm (D)]
Weight (approx.) 18.7 lbs (8.5 kg)
• Design and specifications are subject to change without notice.
