Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
29
åL701RCiLF0029PEZZRCoil (20MU11)AH
åL701RCiLF0090CEZZCoil (20MU11)
L2040RCiLB0159CEZZJOscillation CoilAE
TRANSFORMERS
å T601 RTRNZ0168CEZZ J Transformer AH
çå T602 RTRNF0163PEZZ R H-Volt Transformer BE
or
RTRNF0149PEZZ
å T701 RTRNP0527CEZZ J Power Transformer AM
or
RTRNP0518CEZZ
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
C51 VCEA0A1CW476M J 47 16V EL. AB
C52 VCSATA1CE226K J 22 16V TantalumAD
C53 VCEA0A1HW105M J 1.0 50V EL. AB
C54 VCEA0A1HW475M J 4.7 50V EL. AB
(20MU11)
C54 VCEA0A1HW225M J 2.2 50V EL. AB
(20MU11)
C55 VCEA0A1CW477M J 470 16V EL. AC
(20MU11)
C55 VCEAGA1CW108M J 1000 16V EL. AD
(20MU11)
C201 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C202 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C203 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C204 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C205 VCEA0A1HW474M J 0.47 50V EL. AB
C206 VCEA0A1CW227M J 220 16V EL. AC
C207 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C208 VCEA0A1HW474M J 0.47 50V EL. AB
C209 VCKYCY1HB222K J 2200p 50V Ceramic AA
C210 VCKYCY1HB102K J 1000p 50V Ceramic AA
C302 VCCCCY1HH330J J 33p 50V Ceramic AA
C303 VCKYCY1HB472K J 4700p 50V Ceramic AA
C304 VCEA0A1HW225M J 2.2 50V EL. AB
C305 VCKYPA1HB151K J 150p 50V Ceramic AA
C306 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C308 VCKYCY1HB102K J 1000p 50V Ceramic AA
C309 VCEA0A1CW227M J 220 16V EL. AC
C312 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C314 VCEA0A1HW225M J 2.2 50V EL. AB
C351 VCKYCY1HB562K J 5600p 50V Ceramic AA
C352 VCEA0A1CW107M J 100 16V EL. AC
C353 VCEA0A1CW337M J 330 16V EL. AC
C354 RC-QZA104TAYK J 0.1 50V Mylar AB
C355 VCEA0A1CW226M J 22 16V EL. AB
C361 VCEA0A1CW477M J 470 16V EL. AC
C362 VCEA0A1CW476M J 47 16V EL. AB
C403 VCCCCY1HH101J J 100p 50V Ceramic AA
C404 VCCCCY1HH680J J 68p 50V Ceramic AA
C405 VCEA0A1HW335M J 3.3 50V EL. AB
C406 VCEA0A1HW335M J 3.3 50V EL. AB
C407 RC-QZA104TAYK J 0.1 50V Mylar AB
C408 VCEA0A1CW106M J 10 16V EL. AB
C409 VCEA0A1HW105M J 1.0 50V EL. AB
C410 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C411 VCEAGA1CW108M J 1000 16V EL. AD
C413 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C414 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C419 VCCCCY1HH330J J 33p 50V Ceramic AA
C420 VCCCCY1HH471J J 470p 50V Ceramic AA
C451 RC-QZA563TAYK J 0.056 50V Mylar AB
C454 VCEA0A1HW475M J 4.7 50V EL. AB
C502 VCEA0A1EW477M J 470 25V EL. AD
C504 VCKYPA2HB391K J 390p 500V Ceramic AA
C505 VCQYTA1HM473K J 0.047 50V Mylar AB
C507 VCKYPA1HB102K J 1000p 50V Ceramic AA
C508 VCEAGA1VW107M J 100 35V EL. AC
C509 VCKYPA2HB102K J 1000p 500V Ceramic AA
C510 VCEAGA1VW477M J 470 35V EL. AD
C511 VCQYTA1HM473K J 0.047 50V Mylar AB
C514 VCEACA1HC225J J 2.2 50V EL. AC
C517 VCKYCY1HB102K J 1000p 50V Ceramic AA
C522 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C551 VCSATA1CE225K J 2.2 16V Tantalum AB
C552 VCEA0A1HW225M J 2.2 50V EL. AB
C604 VCEA0A1CW227M J 220 16V EL. AC
çå C608 VCFPPD3CA802H J 8000p 1.6kV M-Poly. AF
C609 RC-QZA223TAYK J 0.022 50V Mylar AB
C612 VCFPPJ2EB474J J 0.47 250V M-Poly. AF
C631 VCEA0A1HW225M J 2.2 50V EL. AB
C632 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C633 VCEA0A1HW105M J 1.0 50V EL. AB
C652 VCEA0A1HW475M J 4.7 50V EL. AB
C653 VCEA0A1CW106M J 10 16V EL. AB
C661 VCKYPA2HB152K J 1500p 500V Ceramic AA
C662 VCEA0A1CW477M J 470 16V EL. AC
å C701 RC-FZ027SCEZZ J 0.047 AC125V Plastic
or
RC-FZ015SCEZZ
or
RC-FZ002SCEZZ
or
RC-FZ059SCEZZ
or
RC-FZ004SGEZZ
or
RC-FZ027CUMZZ
C702 VCKYPB2HE103P J 0.01 500V Ceramic AB
C703 VCKYPB2HE103P J 0.01 500V Ceramic AB
C704 VCKYPB2HE103P J 0.01 500V Ceramic AB
å C705 RC-EZ0422CEZZ J 470 200V EL. AN
or
RC-EZ0522CEZZ
å C706 RC-KZ0092GEZZ J 3300p AC125V Ceramic AC
or
RC-KZ0311CEZZ
C707 VCEAGA2CW226M J 22 160V EL. AD
å C712 RC-EZ0638CEZZ J 33 160V EL. AG
C751 VCEA0A1VW477M J 470 35V EL. AB
C754 VCEA0A1CW337M J 330 16V EL. AC
C755 VCEA0A1CW107M J 100 16V EL. AC
C756 VCEAGA1CW108M J 1000 16V EL. AD
C757 RC-QZA104TAYK J 0.1 50V Mylar AB
å C758 VCEAGA2EW106M J 10 250V EL. AC
C760 VCEAGA1CW108M J 1000 16V EL. AD
C801 RC-QZA223TAYK J 0.022 50V Mylar AB
C802 VCEA0A1HW474M J 0.47 50V EL. AB
C803 VCCCCY1HH120J J 12p 50V Ceramic AA
C804 VCEA0A1HW104M J 0.1 50V EL. AB
C805 VCEA0A1HW104M J 0.1 50V EL. AB
C806 VCEA0A1HW104M J 0.1 50V EL. AB
C807 VCCCCY1HH820J J 82p 50V Ceramic AA
C901 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C905 VCEA0A1HW335M J 3.3 50V EL. AB
C2001 VCCCCY1HH101J J 100p 50V Ceramic AA
C2002 VCCCCY1HH101J J 100p 50V Ceramic AA
C2021 VCCCCY1HH101J J 100p 50V Ceramic AA
C2022 VCCCCY1HH101J J 100p 50V Ceramic AA
C2023 VCCCCY1HH101J J 100p 50V Ceramic AA
C2024 VCCCCY1HH101J J 100p 50V Ceramic AA
C2040 VCEA0A1AW107M J 100 10V EL. AB
C2041 VCEA0A1HW105M J 1.0 50V EL. AB
C2051 VCCCCY1HH101J J 100p 50V Ceramic AA
C2060 RC-QZA104TAYK J 0.1 50V Mylar AB
C2061 VCKYD41HB101K J 100p 50V Ceramic AA
PWB-A : DUNTK9532WEX0 (20MU11)
MAIN UNIT (Continued)
20MU11
