Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
30
C2062 VCEA0A1AW107M J 100 10V EL. AB
C2402 VCCCCY1HH560J J 56p 50V Ceramic AA
C2601 VCEA0A1HW475M J 4.7 50V EL. AB
C2602 VCCCCY1HH101J J 100p 50V Ceramic AA
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
RJ1 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ3 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ5 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ6 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ7 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ9 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ10 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ15 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ17 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ18 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ19 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ20 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ21 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ23 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ24 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ26 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ31 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ32 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ35 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ39 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ40 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ46 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ49 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ52 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ54 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ55 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ57 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ59 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ62 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ63 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ66 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ67 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ68 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ69 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ71 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ75 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ77 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ78 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ79 VRS-CY1JF000J J 0 1/16W M-Ox. AA
å R51 VRS-VV3AB331J J 330 1W M-Ox. AA
(20MU11)
å R51 VRS-VV3DB151J J 150 2W M-Ox. AA
(20MU11)
å R52 VRS-VV3DB470J J 47 2W M-Ox. AA
(20MU11)
å R52 VRS-VV3DB1R0J J 1.0 2W M-Film AB
(20MU11)
å R53 VRS-VV3LB223J J 22k 3.0W M-Ox. AB
R54 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R55 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R56 VRS-CY1JF823J J 82k 1/16W M-Ox. AA
R57 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA
(20MU11)
R57VRS-CY1JF103JJ10k1/16WM-Ox.AA
(20MU11)
R201 VRS-CY1JF221J J 220 1/16W M-Ox. AA
R202 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA
R203 VRD-RA2BE682J J 6.8k 1/8W Carbon AA
R204 VRS-CY1JF270J J 27 1/16W M-Ox. AA
R205 VRD-RA2BE391J J 390 1/8W Carbon AA
R206 VRD-RA2EE151J J 150 1/4W Carbon AA
R208 VRS-CY1JF391J J 390 1/16W M-Ox. AA
R301 VRD-RA2BE222J J 2.2k 1/8W Carbon AA
R302 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R303 VRS-CY1JF153J J 15k 1/16W M-Ox. AA
R307 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
R352 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R353 VRS-CY1JF4R7J J 4.7 1/16W M-Ox. AA
R354 VRS-CY1JF152J J 1.5k 1/16W M-Ox. AA
R361 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R364 VRS-CY1JF473J J 47k 1/16W M-Ox. AA
R401 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R403 VRD-RA2BE331J J 330 1/8W Carbon AA
R404 VRS-CY1JF391J J 390 1/16W M-Ox. AA
R407 VRS-CY1JF471J J 470 1/16W M-Ox. AA
R409 VRS-CY1JF471J J 470 1/16W M-Ox. AA
R410 VRD-RA2BE563J J 56k 1/8W Carbon AA
R411 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R412 VRD-RA2EE561J J 560 1/4W Carbon AA
R413 VRD-RA2BE470J J 47 1/8W Carbon AA
R414 VRD-RA2BE470J J 47 1/8W Carbon AA
R415 VRD-RA2BE470J J 47 1/8W Carbon AA
R416 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R417 VRD-RA2BE101J J 100 1/8W Carbon AB
R418 VRS-CY1JF152J J 1.5k 1/16W M-Ox. AA
R419 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA
R423 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA
R426 VRS-CY1JF271J J 270 1/16W M-Ox. AA
R440 VRS-CY1JF821J J 820 1/16W M-Ox. AA
å R451 VRS-SV2HC103J J 10k 1/2W M-Ox. AA
R452 VRD-RA2BE152J J 1.5k 1/8W Carbon AA
R454 VRD-RA2BE334J J 330k 1/8W Carbon AA
R455 VRD-RA2BE392J J 3.9k 1/8W Carbon AA
R456 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R457 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R458 VRD-RA2BE334J J 330k 1/8W Carbon AA
R459 VRD-RA2BE123J J 12k 1/8W Carbon AA
R504 VRD-RA2BE471J J 470 1/8W Carbon AA
R505 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R506 VRD-RA2BE683G J 68k 1/8W Carbon AA
R507 VRD-RA2BE104G J 100k 1/8W Carbon AA
R508 VRD-RA2BE473J J 47k 1/8W Carbon AA
R510 VRD-RM2HD1R2J J 1.2 1/2W Carbon AA
å R511 VRN-SV2HB1R5J J 1.5 1/2W M-Film AB
R512 VRD-RM2HD681J J 680 1/2W Carbon AA
R516 VRD-RA2BE683G J 68k 1/8W Carbon AA
R517 VRD-RA2BE103G J 10k 1/8W Carbon AA
R518 VRD-RA2BE154J J 150k 1/8W Carbon AA
R524 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R525 VRD-RA2BE473J J 47k 1/8W Carbon AA
R552 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R553 VRS-CY1JF273J J 27k 1/16W M-Ox. AA
R554 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA
R555 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R556 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R602 VRD-RA2EE820J J 82 1/4W Carbon AA
å R603 VRS-VV3LB220J J 22 3.0W M-Ox. AB
R605 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R606 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R608 VRD-RA2BE101J J 100 1/8W Carbon AB
R609 VRD-RA2BE331J J 330 1/8W Carbon AA
å R610 VRS-VV3DB391J J 390 2W M-Ox. AA
R620 VRD-RA2BE473J J 47k 1/8W Carbon AA
R621 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R631 VRS-CY1JF391J J 390 1/16W M-Ox. AA
R632 VRS-CY1JF152J J 1.5k 1/16W M-Ox. AA
R633 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA
R634 VRD-RM2HD121J J 120 1/2W Carbon AA
å R641 VRS-VV3AB682J J 6.8k 1W M-Ox. AA
R642 VRD-RA2BE821J J 820 1/8W Carbon AA
çå R651 VRD-RM2HD1R0J J 1.0 1/2W Carbon AA
çå R654 VRD-RA2BE154J J 150k 1/8W Carbon AA
çå R655 VRS-CY1JF104J J 100k 1/16W M-Ox. AA
çå R656 VRS-CY1JF273J J 27k 1/16W M-Ox. AA
å R659 VRN-VV3AB1R0J J 1.0 1W M-Film AA
å R661 VRN-VV3ABR47J J 0.47 1W M-Film AA
PWB-A : DUNTK9532WEX0 (20MU11)
MAIN UNIT (Continued)
20MU11
