Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
31
å R701 RR-HZ0046CEZZ J 2.7M 1/2W Solid AD
or
RR-DZ0047CEZZ
or
VRC-UB2HG275K
å R702 VRW-KP3HC1R8K J 1.8 5W Cement AC
å R703 VRS-KA3NG681J J 680 7.0W M-Ox. AF
R704 VRD-RM2HD123J J 12k 1/2W Carbon AA
R705 VRD-RA2EE334J J 330k 1/4W Carbon AA
R706 VRD-RM2HD470J J 47 1/2W Carbon AA
å R707 VRN-VV3DB1R5J J 1.5 2W M-Film AB
å R708 VRD-RM2HD824J J 820k 1/2W Carbon AA
å R709 VRS-KA3NG681J J 680 7.0W M-Ox. AF
å R711 VRS-KA3NG681J J 680 7.0W M-Ox. AF
å R717 VRS-KA3HG3R3K J 3.3 5W M-Ox. AD
å R730 VRS-VV3DB270J J 27 2W M-Ox. AA
å R750 VRS-VV3AB561J J 560 1W M-Ox. AA
R752 VRD-RA2BE562J J 5.6k 1/8W Carbon AA
R754 VRS-CY1JF471J J 470 1/16W M-Ox. AA
å R755 VRS-VV3DB470J J 47 2W M-Ox. AA
R757 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA
å R758 VRS-SV2HC100J J 10 1/2W M-Ox. AA
R801 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R802 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R803 VRS-CY1JF182J J 1.8k 1/16W M-Ox. AA
R804 VRS-CY1JF182J J 1.8k 1/16W M-Ox. AA
R805 VRS-CY1JF182J J 1.8k 1/16W M-Ox. AA
R806 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
R902 VRS-CY1JF750J J 75 1/16W M-Ox. AA
R906 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R925 VRS-CY1JF104J J 100k 1/16W M-Ox. AA
R961 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R962 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2001 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R2002 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2006 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2007 VRD-RA2BE223J J 22k 1/8W Carbon AA
R2008 VRD-RA2BE224J J 220k 1/8W Carbon AA
R2009 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R2010 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R2011 VRS-CY1JF821J J 820 1/16W M-Ox. AA
R2012 VRS-CY1JF471J J 470 1/16W M-Ox. AA
R2020 VRD-RM2HD223J J 22k 1/2W Carbon AA
R2022 VRD-RA2BE333J J 33k 1/8W Carbon AA
R2024 VRD-RA2BE682J J 6.8k 1/8W Carbon AA
R2025 VRD-RA2BE682J J 6.8k 1/8W Carbon AA
R2026 VRD-RA2BE682J J 6.8k 1/8W Carbon AA
R2027 VRD-RA2BE682J J 6.8k 1/8W Carbon AA
R2028 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R2029 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R2032 VRS-CY1JF471J J 470 1/16W M-Ox. AA
R2033 VRD-RA2BE103J J 10k 1/8W Carbon AA
R2040 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R2041 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
R2042 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2043 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2044 VRS-CY1JF683J J 68k 1/16W M-Ox. AA
R2045 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2047 VRS-CY1JF221J J 220 1/16W M-Ox. AA
R2048 VRD-RA2BE562J J 5.6k 1/8W Carbon AA
R2049 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
R2054 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA
R2055 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2060 VRS-CY1JF221J J 220 1/16W M-Ox. AA
R2061 VRS-CY1JF562J J 5.6k 1/16W M-Ox. AA
R2062 VRS-CY1JF183J J 18k 1/16W M-Ox. AA
R2063 VRD-RA2BE222J J 2.2k 1/8W Carbon AA
R2064 VRD-RA2BE332J J 3.3k 1/8W Carbon AA
R2066 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2067 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2068 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2070 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2101 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2102 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2401 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2402 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2403 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2404 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2501 VRS-CY1JF123J J 12k 1/16W M-Ox. AA
R2503 VRS-CY1JF273J J 27k 1/16W M-Ox. AA
R2504 VRS-CY1JF123J J 12k 1/16W M-Ox. AA
R2505 VRS-CY1JF563J J 56k 1/16W M-Ox. AA
R2506 VRS-CY1JF563J J 56k 1/16W M-Ox. AA
R2507 VRS-CY1JF823J J 82k 1/16W M-Ox. AA
R2508 VRS-CY1JF153J J 15k 1/16W M-Ox. AA
R2509 VRS-CY1JF272J J 2.7k 1/16W M-Ox. AA
R2601 VRD-RA2BE331J J 330 1/8W Carbon AA
SWITCHES
S2501 QSW-K0079GEZZ J Power AB
S2502 QSW-K0079GEZZ J Vol-Down AB
S2503 QSW-K0079GEZZ J Vol-Up AB
S2504 QSW-K0079GEZZ J CH-Down AB
S2505 QSW-K0079GEZZ J CH-Up AB
MISCELLANEOUS PARTS
å RY701 RRLYU0036CEZZ J Relay AM
or
RRLYU0038CEZZ
or
RRLYU0077CEZZ
å F701 QFS-B4023CEZZ J Fuse, 4A(125V) AC
or
QFS-B4021GEZZ
FB602 RBLN-0037CEZZ J Ferrite Bead AB
FB603 RBLN-0037CEZZ J Ferrite Bead AB
FH701 QFSHD1013CEZZ J Fuse Holder AC
or
QFSHD1013CEZZ
FH702 QFSHD1014CEZZ J Fuse Holder AC
or
QFSHD1010CEZZ
J903 QJAKE0159CEZZ J Jack, Audio IN AF
J905 QJAKE0158CEZZ J Jack, Video IN AF
P302 QPLGN0261CEZZ J Plug, 4-pin (S) AB
P401 QPLGN0561CEZZ J Plug, 5-pin (GBN) AB
P601 QPLGN0603CEZZ J Plug, 6-pin (K) AB
P651 QPLGN0361CEZZ J Plug, 3-pin AB
P701 QPLGN0207CEZZ J Plug, 2-pin (M) AA
P751 QPLGN0461CEZZ J Plug, 4-pin (YBN) AB
P2001 QPLGN0561CEZZ J Plug, 5-pin AB
RMC2601 RRMCU0227CEZZ J R/C Receiver AK
or
RRMCU0235CEZZ
or
RRMCU0222CEZZ
HM601 LX-GZ3002PEZZ R Screw AB
HM602 LX-GZ3002PEZZ R Screw AB
HM705 LX-GZ3001PEZZ R Screw AB
HM706 LX-GZ3001PEZZ R Screw AB
HM707 LX-GZ3001PEZZ R Screw AB
HM708 LX-GZ3001PEZZ R Screw AB
HM711 LX-GZ3001PEZZ R Screw AB
HM712 LX-GZ3001PEZZ R Screw AB
HM713 LX-GZ3001PEZZ R Screw AB
HM714 LX-GZ3001PEZZ R Screw AB
HM715 LX-GZ3001PEZZ R Screw AB
HM716 LX-GZ3001PEZZ R Screw AB
HM717 LX-GZ3001PEZZ R Screw AB
HM718 LX-GZ3001PEZZ R Screw AB
HM719 LX-GZ3001PEZZ R Screw AB
HM720 LX-GZ3001PEZZ R Screw AB
HM722 LX-GZ3002PEZZ R Screw AB
HM724 LX-GZ3002PEZZ R Screw AB
PWB-A : DUNTK9532WEX0 (20MU11)
MAIN UNIT (Continued)
20MU11
