E 25
Dimension: 176 x 250 mm
Printelligence (M) Sdn. Bhd
Specifications
• Design and specifications are subject to change without notice.
• Receiving system: These receiving systems, encompassing all currently available technology, include
those with planned broadcast, videotape and laserdisc hardware and software.
• Reception channels: Some examples of the main receivable channels are shown above.
MODEL 21AG1-SMK3
Receiving System World multi 18 system
TV Broadcasts/ PAL-I SECAM-B/G
VCR Playback PAL-B/G SECAM D/K, K1
PAL-D/K
VCR Playback NTSC 4.43/5.5 MHz/60 Hz
NTSC 4.43/6.0 MHz/60 Hz
NTSC 4.43/6.5 MHz/60 Hz
NTSC 4.43/5.5 MHz/50 Hz
NTSC 4.43/6.0 MHz/50 Hz
NTSC 4.43/6.5 MHz/50 Hz
SECAM-I (6.0 MHz)
VCR Playback SECAM-L (French SECAM)
(Using Video-in terminals) PAL 60Hz
NTSC 3.58 MHz
Laserdisc Player Playback PAL 5.5 MHz/60 Hz
(Using RF-in terminals) PAL 6.0 MHz/60 Hz
PAL 6.5 MHz/60 Hz
Reception Channels
PAL-B/G VHF E2–E12 ch
SECAM-B/G
UHF E21–E69 ch
PAL-D/K VHF C1–C12 ch, R1–R12 ch
SECAM-D/K, K1
UHF C13–C57 ch, R21–R69 ch
PAL-I VHF B–J ch
UHF 21–69 ch (Hong Kong)
CATV S1–S20 ch, S21–S41 ch (Hyper)
Receiving Frequency 48.25 MHz – 863.25 MHz
Channel Tuning 100-Channel Electronic Tuner with Full Auto Tuning System
Picture Tube 21-Inch Tinted
Terminals Audio/video input × 2 (front × 1, rear × 1)
Audio/video output × 1 (rear) , Headphone jack × 1 (front)
Sound Output 3 W (RMS) × 1
Power Source AC 110 – 240V, 50/60 Hz
Power Consumption 79 W
Dimensions 499 (W) × 474 (H) × 486 (D) mm
Weight 20.5 kg (Approx.)
21AG1-SMK3(22-26)EN 16/12/04, 9:43 AM25
