USER DATA IN SERVICE MODE
. While SERVICE mode ON, EEPROM DATA will switch to the service data. Also, once SERVICE mode OFF, EEPROM will switch back to previous USER DATA.
. In the service mode, the user data establish as below,
USER DATA MODELS CONTRAST MAX 60 COLOUR CENT 0 BRIGHTNESS CENT 0 TINT CENT 0 SHARPNESS CENT 0 WHITE TEMP STANDARD S-VOLUME MIN SURROUND OFF BALANCE CENT 0 AVL *2 BLUE BACK OFF C SYSTEM AUTO S SYSTEM *1 EQUALIZER *2
ANTENNA BOOSTER *1
*1: For each CH, data is same as before switch to Service mode. *2: Data is same as before switch to Serice mode.
The flow of Mode list as following,
* Direct Key-in Mode for Service Items in Service Mode
RC CODE (HEX) R/C KEY NAME
80 POS 1 R-C UP (IN SERVICE MODE V00) 40 POS 2 G-C UP (IN SERVICE MODE V00)
C0 POS 3 B-C UP (IN SERVICE MODE V00)
20 POS 4 R-C DOWN (IN SERVICE MODE V00)
A0 POS 5 G-C DOWN (IN SERVICE MODE V00)
60 POS 6 B-C DOWN (IN SERVICE MODE V00)
E0 POS 7 R-D UP (IN SERVICE MODE V00)
10 POS 8 B-D UP (IN SERVICE MODE V00) 50 POS 0 B-D DOWN (IN SERVICE MODE V00)
E4 FLASHBACK R-D DOWN (IN SERVICE MODE V00) E4 FLASHBACK Y-MUTE (BESIDES OF SERVICE MODE V00)
75 WHITE TEMP UP RF-AGC (V01)
F5 WHITE TEMP DOWN VIF-VC0 (V02)
C2 TUNE DOWN H-VCO (V03) 8D SHARPNESS DOWN SUB-CON (V04) D6 BALANCE LEFT SUB-COL (V05) 0D SHARPNESS UP SUB-BRIGHT (V06)
36 BALANCE RIGHT SUB-TINT (V07) 46 TREBLE UP SUB-SHP-PRE (V08)
C6 TREBLE DOWN SUB-COL-YUV (V09)
26 BASS UP SUB-TINT-YUV (V10) 24 COLOUR UP V-SIZE (V11), V-SIZE60 (V16) 54 BRIGHTNESS DOWN V-SHIFT (V12), V-SHIFT60 (V17) 74 TINT DOWN H-SHIFT (V13), H-SHIFT60 (V18) 66 SURROUND UP SCM-BR (V14)
E6 SURROUND DOWN SCM-BB (V15)
C4 CONTRAST DOWN SUB-VOL 4C PICTURE S-TRAP-BG (V19)
CC HOLD S-TRAP-I (V20)
2C TEXT S-TRAP-DK (V21)
AC CANCEL S-TRAP-M (V22) EC SIZE S-TRAP-574 (V23)
C1 AUTO ADJ FOR V01, V02, V03,V19, V20, V21, V22, V23
CA T-SET
81 SERVICE MODE
SERVICE-ITEM
ALL MODELS
1.) Please set the MCL to
MCL1
as below:
2.) After set the MCL , please set the INITIAL SETTING for each models
.
INITIAL 3 :
All Channel Sound System are set to B/G
CH-No Fv (MHz) Sound Sys
0
1 48.25 B/G
2 62.25 B/G
3 77.25 D/K
4 175.25 B/G
5 182.25 B/G
6 183.25 D/K
7 191.25 D/K
8 196.25 B/G
9 199.25 M
10 210.25 B/G
11 224.25 B/G
12 471.25 B/G
13 487.25 I
14 503.25 B/G
15 575.25 B/G
16 583.25 B/G
17 599.25 B/G
18 621.25 M
19 639.25 D/K
20 703.25 B/G
21 735.25 I
22 767.25 B/G
23 815.25 B/G
24 855.25 I
25 855.25 B/G
26 55.25 M
27 83.25 M
28 183.25 M
29 193.25 M
30 217.25 M
31 471.25 M
32 477.25 M
33 693.25 M
34 885.25 M
35 112.25 B/G
36 168.25 B/G
37
38 294.25 B/G
39 463.25 B/G
40
41 647.25 B/G
42 663.25 B/G
43 679.25 B/G
44 174.95 B/G
45 175.55 B/G
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
MCL1 (HEX AE)
