Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
47
27L-S500,27L-X2000
CL27S50,CL27X200
PWB-A: DUNTK9640WEK1(27L-S500, CL27S50)
MAIN UNIT (Continued)
Q2005 VS2SD601AR/-1 J 2SD601AR AC
Q2008 VS2SD601AR/-1 J 2SD601AR AC
Q2009 VS2SD601AR/-1 J 2SD601AR AC
DIODES
You can substitute "RH-DX0475CEZZ" for "VHD1SS119//-1".
D406 VHD1SS119//-1 J Diode AB
D451 VHD1SS119//-1 J Diode AB
D452 RH-EX0217CEZZ J Zener Diode, 15V AB
D453 RH-EX0217CEZZ J Zener Diode, 15V AB
D454 RH-EX0611GEZZ J Zener Diode, 5.1V AA
or
RH-EX0293CEZZ
D455 VHD1SS119//-1 J Diode AB
D456 VHD1SS119//-1 J Diode AB
D457 RH-EX0631GEZZ J Zener Diode, 9.1V AA
or
RH-EX1314CEZZ
D501 RH-DX0441CEZZ J Diode AC
D503 RH-EX0631GEZZ J Zener Diode, 9.1V AA
D506 RH-EX0654CEZZ J Zener Diode, 75V AD
å D510 RH-DX0131CEZZ J Diode AC
D513 RH-DX0441CEZZ J Diode AC
D523 RH-EX0604GEZZ J Zener Diode, 3V AB
D617 RH-EX0630GEZZ J Zener Diode, 9V AA
or
RH-EX1314CEZZ
D619 VHD1SS119//-1 J Diode AB
D620 RH-EX0604GEZZ J Zener Diode, 3.9V AB
çå D651 RH-DX0131CEZZ J Diode AC
çå D652 RH-EX1313CEZZ J Zener Diode, 9.1V AD
çå D653 VHD1SS119//-1 J Diode AB
å D701 RH-DX0154CEZZ J Diode AC
å D702 RH-DX0154CEZZ J Diode AC
å D703 RH-DX0154CEZZ J Diode AC
å D704 RH-DX0154CEZZ J Diode AC
å D705 VHD1SS119//-1 J Diode AB
å D706 RH-EX0238CEZZ J Zener Diode, 75V AC
çå D707 VHSS6785GLB2E J Si.Control Rectifier AL
çå D708 VHSS6785GLB2E J Si.Control Rectifier AL
å D709 RH-DX0131CEZZ J Diode AC
å D710 RH-DX0131CEZZ J Diode AC
å D711 RH-DX0229CEZZ J Diode AF
or
RH-DX0444CEZZ
å D751 RH-DX0441CEZZ J Diode AC
D752 RH-EX0019TAZZ J Zener Diode, 13V AB
D753 RH-DX0441CEZZ J Diode AC
å D754 RH-DX0441CEZZ J Diode AC
å D755 RH-DX0441CEZZ J Diode AC
å D756 RH-DX0441CEZZ J Diode AC
D757 VHD1SS119//-1 J Diode AB
D758 RH-DX0441CEZZ J Diode AC
D760 RH-DX0441CEZZ J Diode AC
D761 RH-DX0441CEZZ J Diode AC
D1301 RH-EX0631GEZZ J Zener Diode, 9.1V AA
D1302 RH-EX0631GEZZ J Zener Diode, 9.1V AA
D1303 RH-EX0631GEZZ J Zener Diode, 9.1V AA
D1308 RH-EX0631GEZZ J Zener Diode, 9.1V AA
D1310 RH-EX0631GEZZ J Zener Diode, 9.1V AA
D1311 RH-EX0631GEZZ J Zener Diode, 9.1V AA
D2004 VHD1SS119//-1 J Diode AB
D2010 RH-EX0616GEZZ J Zener Diode, 5.6V AA
D2701 VHD1SS119//-1 J Diode AB
PACKAGED CIRCUITS
å PR701 RMPTP0088CEZZ M Packaged Circuit AE
or (L702: G0038ME)
RMPTP0026CEZZ Packaged Circuit
(L702: G0032ME)
X801 RCRSB0001PEZZ R Crystal AL
or
RCRSB0205CEZZ
FILTERS
CF501 RFiLA0034CEZZ J Ceramic Filter AD
CF2001 RFiLC0121GEZZ J Ceramic Filter AD
COILS
DL1401RCiLZ0938CEZZ J Coil AW
L601 RCiLZ0621CEZZ J Coil AH
or
RCiLZ0101MEZZ
å L701 RCiLF0025PEZZ R Coil (27L-S500) AK
or
RCiLF0029PEZZ
or
RCiLF0087PEZZ
or
RCiLF0235CEZZ
or
RCiLF0019PEZZ
or
RCiLF0090CEZZ
or
RCiLF0133CEZZ
å L701 RCiLF0133CEZZ J Coil (CL27S50) AL
L1404 VP-XF680K0000 J Peaking 68µH AB
T2001 RCiLB0158CEZZ M Oscillation Coil AC
TRANSFORMERS
å T601 RTRNZ0168CEZZ J H-Driver AH
çå T602 RTRNF0020MEZZ M H-Out BC
å T701 RTRNP0533CEZZ M Power (27L-S500) AL
å T701 RTRNP0549CEZZ M Power (CL27S50) AM
or
RTRNP0516CEZZ
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
C401 VCEA0A1CW337M J 330 16V EL. AC
C403 VCKYCY1HB103K J 0.01 50V Ceramic AA
C404 VCEA0A1HW105M J 1.0 50V EL. AB
C405 VCEA0A1HW225M J 2.2 50V EL. AB
C406 VCKYCY1HB103K J 0.01 50V Ceramic AA
C407 VCEA0A1CW337M J 330 16V EL. AC
C408 VCEA0A1HW474M J 0.47 50V EL. AB
C409 VCFYSA1HB334J J 0.33 50V Mylar AB
C427 VCFYSA1HB104J J 0.1 50V Mylar AB
C440 VCKYCY1HB103K J 0.01 50V Ceramic AA
C441 VCEA0A1CW337M J 330 16V EL. AC
C451 RC-QZA104TAYK J 0.1 50V Mylar AB
C452 VCEA0A1HW475M J 4.7 50V EL. AB
å C453 VCEA0A2EW226M J 22 250V EL. AC
C456 VCEA0A1CW226M J 22 16V EL. AB
C502 VCEA0A1VW108M J 1000 35V EL. AD
C504 VCKYPA2HB391K J 390p 500V Ceramic AA
C506 RC-QZA103TAYK J 0.01 50V Mylar AA
C507 VCEA0A1VW107M J 100 35V EL. AC
C510 VCEA0A1VW108M J 1000 35V EL. AD
C511 VCFYSA1JA473J J 0.047 63V Mylar AC
C512 VCFYSA1JA564J J 0.56 63V Mylar AE
C513 VCEA0A1HW474M J 0.47 50V EL. AB
C514 VCEACA1HC105K J 1.0 50V EL. AC
C515 VCEACA1HC474K J 0.47 50V EL. AB
C521 RC-QZA102TAYK J 1000P 50V Mylar AA
C522 VCEA0A1CW477M J 470 16V EL. AC
C523 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C524 VCFYSA1HB223J J 0.022 50V Mylar AA
C525 VCEACA1HC225J J 2.2 50V EL. AC
C526 VCEAGA1HW334T J 0.33 50V EL. AC
C528 RC-QZA473TAYK J 0.047 50V Mylar AB
C538 VCCSPA1HL101J J 100p 50V Ceramic AA
C601 VCFYSA1HB103J J 0.01 50V Mylar AA
C603 RC-QZA273TAYK J 0.027 50V Mylar AB
