Sharp 27L-S500 - Main Unit

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
51
27L-S500,27L-X2000
CL27S50,CL27X200
PWB-A: DUNTK9640WEK2(27L-X2000, CL27X200)
MAIN UNIT
INTEGRATED CIRCUITS
IC401 RH-iX3113CEZZ J TA1276AN AZ
å IC501 VHiTA8427K/-1 J TA8427K AL
IC502 VHiTA1241AN-1 J TA1241AN AM
çå IC701 RH-iX0758CEZZ J T8150 AF
å IC702 VHiT8889A//-1 J T8889A AL
å IC751 VHiKA7809Pi-1 M KIA7809PI AE
IC781 VHiKA7805Pi-1 M KIA7805PI AE
IC1301 VHiMM1313AD-1 J MM1313AD AP
IC1701 VHiMC14577F-1 J MC14577BF AG
IC1702 VHiM52055FP-1 J M52055FP AH
IC1703 VHiMM1111XF1E J MM1111XFBE AE
IC1704 VHiMM1111XF1E J MM1111XFBE AE
IC2001 RH-iX3274CEZZ M I.C. AX
IC2003 VHiKiA7045P-1 J KIA7045P AD
IC2701 VHiKA78S05P-1 J KIA78S05P AD
TRANSISTORS
You can substitute "VS2SC2412-C-1" or "VS2SC2462-C-1" for
"VS2SD601AR/-1".
Q451 VS2SA1266-Y-1 J 2SA1266(Y) AA
Q601 VS2SC2655Y/-1 J 2SC2655(Y) AE
å Q602 VS2SD2539//1E J 2SD2539 AP
or
VS2SD1556//1E
Q606 VS2SC3198-Y-1 J 2SC3198(Y) AA
å Q751 VS2SC1983//-2 J 2SC1983 AF
Q752 VS2SC3198-Y-1 J 2SC3198(Y) AA
Q753 VS2SA1013//1E J 2SA1013 AD
Q1301 VS2SD601AR/-1 J 2SD601AR AC
Q1302 VS2SD601AR/-1 J 2SD601AR AC
Q1402 VS2SB709AR/-1 J 2SB709AR AC
Q1404 VS2SD601AR/-1 J 2SD601AR AC
Q1405 VS2SD601AR/-1 J 2SD601AR AC
Q2004 VSUN2212///-1 J VSUN2212 AA
Q2005 VS2SD601AR/-1 J 2SD601AR AC
Q2008 VS2SD601AR/-1 J 2SD601AR AC
Q2009 VS2SD601AR/-1 J 2SD601AR AC
DIODES
You can substitute "RH-DX0475CEZZ" for "VHD1SS119//-1".
D406 VHD1SS119//-1 J Diode AB
D451 VHD1SS119//-1 J Diode AB
D452 RH-EX0217CEZZ J Zener Diode, 15V AB
D453 RH-EX0217CEZZ J Zener Diode, 15V AB
D454 RH-EX0611GEZZ J Zener Diode, 5.1V AA
or
RH-EX0293CEZZ
D455 VHD1SS119//-1 J Diode AB
D456 VHD1SS119//-1 J Diode AB
D457 RH-EX0631GEZZ J Zener Diode, 9.1V AA
or
RH-EX1314CEZZ
D501 RH-DX0441CEZZ J Diode AC
D503 RH-EX0631GEZZ J Zener Diode, 9.1V AA
D506 RH-EX0654CEZZ J Zener Diode, 75V AD
å D510 RH-DX0131CEZZ J Diode AC
D513 RH-DX0441CEZZ J Diode AC
D523 RH-EX0604GEZZ J Zener Diode, 3V AB
D617 RH-EX0630GEZZ J Zener Diode, 9V AA
or
RH-EX1314CEZZ
D619 VHD1SS119//-1 J Diode AB
D620 RH-EX0604GEZZ J Zener Diode, 3.9V AB
çå D651 RH-DX0131CEZZ J Diode AC
çå D652 RH-EX1313CEZZ J Zener Diode, 9.1V AD
Q602 R603 R609
COMBI- 2SD2539 12/3W/(RG) 12/3W/(RG)
NATION 2SD1556 18/3W/(RG) 18/3W/(RG)
çå D653 VHD1SS119//-1 J Diode AB
å D701 RH-DX0154CEZZ J Diode AC
å D702 RH-DX0154CEZZ J Diode AC
å D703 RH-DX0154CEZZ J Diode AC
å D704 RH-DX0154CEZZ J Diode AC
å D705 VHD1SS119//-1 J Diode AB
å D706 RH-EX0238CEZZ J Zener Diode, 75V AC
çå D707 VHSS6785GLB2E J Si.Control Rectifier AL
çå D708 VHSS6785GLB2E J Si.Control Rectifier AL
å D709 RH-DX0131CEZZ J Diode AC
å D710 RH-DX0131CEZZ J Diode AC
å D711 RH-DX0229CEZZ J Diode AF
or
RH-DX0444CEZZ
å D751 RH-DX0441CEZZ J Diode AC
D752 RH-EX0019TAZZ J Zener Diode, 13V AB
D753 RH-DX0441CEZZ J Diode AC
å D754 RH-DX0441CEZZ J Diode AC
å D755 RH-DX0441CEZZ J Diode AC
å D756 RH-DX0441CEZZ J Diode AC
D757 VHD1SS119//-1 J Diode AB
D758 RH-DX0441CEZZ J Diode AC
D760 RH-DX0441CEZZ J Diode AC
D761 RH-DX0441CEZZ J Diode AC
D1301 RH-EX0631GEZZ J Zener Diode, 9.1V AA
D1302 RH-EX0631GEZZ J Zener Diode, 9.1V AA
D1303 RH-EX0631GEZZ J Zener Diode, 9.1V AA
D1304 RH-EX0631GEZZ J Zener Diode, 9.1V AA
D1305 RH-EX0631GEZZ J Zener Diode, 9.1V AA
D1306 RH-EX0631GEZZ J Zener Diode, 9.1V AA
D1308 RH-EX0631GEZZ J Zener Diode, 9.1V AA
D1310 RH-EX0631GEZZ J Zener Diode, 9.1V AA
D1311 RH-EX0631GEZZ J Zener Diode, 9.1V AA
D2004 VHD1SS119//-1 J Diode AB
D2010 RH-EX0616GEZZ J Zener Diode, 5.6V AA
D2701 VHD1SS119//-1 J Diode AB
PACKAGED CIRCUITS
å PR701 RMPTP0088CEZZ M Packaged Circuit AE
or (L702: G0038ME)
RMPTP0026CEZZ Packaged Circuit
(L702: G0032ME)
X801 RCRSB0001PEZZ R Crystal AL
or
RCRSB0205CEZZ
FILTERS
CF501 RFiLA0034CEZZ J Ceramic Filter AD
CF2001 RFiLC0121GEZZ J Ceramic Filter AD
COILS
DL1401 RCiLZ0938CEZZ J Coil AW
L601 RCiLZ0621CEZZ J Coil AH
or
RCiLZ0101MEZZ
å L701 RCiLF0025PEZZ R Coil (27L-X2000) AK
or
RCiLF0029PEZZ
or
RCiLF0087PEZZ
or
RCiLF0235CEZZ
or
RCiLF0019PEZZ
or
RCiLF0090CEZZ
or
RCiLF0133CEZZ
å L701 RCiLF0133CEZZ J Coil (CL27X200) AL
L1404 VP-XF680K0000 J Peaking 68µH AB
T2001 RCiLB0158CEZZ M Oscillation Coil AC
TRANSFORMERS
å T601 RTRNZ0168CEZZ J H-Driver AH
çå T602 RTRNF0020MEZZ M H-Out BC
