Sharp 27L-S500 - Sub Unit

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
57
27L-S500,27L-X2000
CL27S50,CL27X200
PWB-H: DUNTK9310WEK1
FRONT AV UNIT
MISCELLANEOUS PARTS
J1001 QJAKE0053GEZZ J Jack, Video in AD
J1002 QJAKE0055GEZZ J Jack, Audio in (L) AD
J1003 QJAKE0059GEZZ J Jack, Audio in (R) AC
P1001 QPLGN0541CEZZ J Plug, 5-pin (HA) AB
MISCELLANEOUS PARTS
P850 QPLGN0561CEZZ J Plug, 5-pin(GBN) AB
P851 QPLGN0361CEZZ J Plug, 3-pin(PA) AB
P855 QPLGN0461CEZZ J Plug, 4-pin(YBN) AB
SC851 QSOCV0937CEZZ J CRT Socket AL
PWB-B: DUNTK9835WEK2(27L-X2000, CL27X200)
CRT UNIT (Continued)
PWB-K: DUNTK9641WEK1(27L-S500, CL27S50)
PWB-K: DUNTK9641WEK2(27L-X2000, CL27X200)
SUB UNIT
TUNER
NOTE: THE PARTS HERES SHOWN ARE SUPPLIED
AS AN ASSEMBLY BUT NOT INDEPENDENTLY.
å TU51 VTUVTBT5UB202 M Tuner B AZ
å TU71 VTUVTBT5UR202 M Tuner A AZ
INTEGRATED CIRCUITS
IC351 VHiTDA7233/-1 J TDA7233 AF
IC352 VHiTDA7233/-1 J TDA7233 AF
å IC771 VHiKA7809Pi-1 M KIA7809PI AE
IC791 VHiKA7805Pi-1 M KIA7805PI AE
IC1501 VHiM24C16B/-1 J M24C16-BN6 AG
IC3001 VHiCXA2074Q-1 J CXA2074Q AY
TRANSISTORS
You can substitute "VS2SC2462-C-1" for "VS2SD601AR/-1".
Q61 VS2SB709AR/-1 J 2SB709AR AC
or
VS2SA812-M51E
Q62 VS2SB709AR/-1 J 2SB709AR AC
or
VS2SA812-M51E
Q63 VS2SD601AR/-1 J 2SD601AR AC
Q81 VS2SB709AR/-1 J 2SB709AR AC
or
VS2SA812-M51E
Q82 VS2SB709AR/-1 J 2SB709AR AC
or
VS2SA812-M51E
Q83 VS2SD601AR/-1 J 2SD601AR AC
Q351 VS2SD601AR/-1 J 2SD601AR AC
Q352 VS2SD601AR/-1 J 2SD601AR AC
Q901 VS2SD601AR/-1 J 2SD601AR AC
Q902 VS2SD601AR/-1 J 2SD601AR AC
Q903 VS2SD601AR/-1 J 2SD601AR AC
Q904 VS2SD601AR/-1 J 2SD601AR AC
Q905 VS2SD601AR/-1 J 2SD601AR AC
Q906 VS2SD601AR/-1 J 2SD601AR AC
DIODES
You can substitute "RH-DX0475CEZZ" for "VHD1SS119//-1".
D52 RH-EX0673GEZZ J Zener Diode, 32V AB
D75 RH-EX0673GEZZ J Zener Diode, 32V AB
å D771 RH-DX0441CEZZ J Diode AC
å D772 RH-DX0441CEZZ J Diode AC
å D773 RH-DX0441CEZZ J Diode AC
å D774 RH-DX0441CEZZ J Diode AC
TRANSFORMERS
å T771 RTRNP0533CEZZ M Power AL
(27L-S500, 27L-X2000)
å T771 RTRNP0549CEZZ M Power AM
or (CL27S50, CL27X200)
RTRNP0516CEZZ
CAPACITORS
[EL.··· Electrolytic]
C52 VCEA0A1CW108M J 1000 16V EL. AD
C54 VCEA0A1HW105M J 1.0 50V EL. AB
C61 RC-QZA473TAYJ J 0.047 50V Mylar AB
C62 VCEA0A1HW105M J 1.0 50V EL. AB
C63 RC-QZA472TAYJ J 4700P 50V Mylar AB
C72 VCEA0A1CW108M J 1000 16V EL. AD
C75 VCEA0A1HW105M J 1.0 50V EL. AB
C81 RC-QZA473TAYJ J 0.047 50V Mylar AB
C82 VCEA0A1HW105M J 1.0 50V EL. AB
C83 RC-QZA472TAYJ J 4700P 50V Mylar AB
C351 VCKYCY1HB392K J 3900p 50V Ceramic AA
C352 VCEA0A1CW107M J 100 16V EL. AC
C353 VCEA0A1CW337M J 330 16V EL. AC
C354 VCKYCY1CB104K J 0.1 16V Ceramic AB
