Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
56
27L-S500,27L-X2000
CL27S50,CL27X200
PWB-B: DUNTK9510WEK2(27L-S500, CL27S50)
CRT UNIT
TRANSISTORS
Q851 VS2SC3198-Y-1 J 2SC3198(Y) AA
Q852 VS2SC3789//2E J 2SC3789 AF
or
VS2SC3619LB1E
Q853 VS2SC3198-Y-1 J 2SC3198(Y) AA
Q854 VS2SC3789//2E J 2SC3789 AF
or
VS2SC3619LB1E
Q855 VS2SC3198-Y-1 J 2SC3198(Y) AA
Q856 VS2SC3789//2E J 2SC3789 AF
or
VS2SC3619LB1E
Q881 VS2SA1266-Y-1 J 2SA1266(Y) AA
DIODES
You can substitute "RH-DX0475CEZZ" for "VHD1SS119//-1".
D881 VHD1SS119//-1 J Diode AB
D882 VHD1SS119//-1 J Diode AB
D884 VHD1SS119//-1 J Diode AB
COIL
L851 VP-MK820K0000 J Peaking 82µH AB
CAPACITORS
[EL.··· Electrolytic]
C851 VCCSPA1HL391J J 390p 50V Ceramic AA
C852 VCCSPA1HL331J J 330p 50V Ceramic AA
C853 VCCSPA1HL391J J 390p 50V Ceramic AA
C854 RC-KZ0024CEZZ J 0.001 2kV Ceramic AC
or
VCKYPB3DE472Z 0.00472kV Ceramic
C883 VCEA0A1HW106M J 10 50V EL. AB
RESISTORS
[M-Ox.··· Metal Oxide]
R851 VRD-RA2BE470J J 47 1/8W Carbon AA
R852 VRD-RA2BE181J J 180 1/8W Carbon AA
R853 VRD-RA2BE121J J 120 1/8W Carbon AA
R855 VRD-RA2BE471J J 470 1/8W Carbon AA
R856 VRD-RA2BE221J J 220 1/8W Carbon AA
å R857 VRS-VV3LB123J J 12k 3.0W M-Ox. AB
R858 VRD-RM2HD222J J 2.2k 1/2W Carbon AA
R859 VRD-RA2BE470J J 47 1/8W Carbon AA
R860 VRD-RA2BE181J J 180 1/8W Carbon AA
R861 VRD-RA2BE121J J 120 1/8W Carbon AA
R863 VRD-RA2BE471J J 470 1/8W Carbon AA
R864 VRD-RA2BE221J J 220 1/8W Carbon AA
å R865 VRS-VV3LB123J J 12k 3.0W M-Ox. AB
R866 VRD-RM2HD222J J 2.2k 1/2W Carbon AA
R867 VRD-RA2BE470J J 47 1/8W Carbon AA
R868 VRD-RA2BE181J J 180 1/8W Carbon AA
R869 VRD-RA2BE121J J 120 1/8W Carbon AA
R871 VRD-RA2BE471J J 470 1/8W Carbon AA
R872 VRD-RA2BE221J J 220 1/8W Carbon AA
å R873 VRS-VV3LB123J J 12k 3.0W M-Ox. AB
R874 VRD-RM2HD222J J 2.2k 1/2W Carbon AA
R881 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R882 VRD-RA2BE271J J 270 1/8W Carbon AA
R883 VRD-RA2BE561J J 560 1/8W Carbon AA
R884 VRD-RA2BE152J J 1.5k 1/8W Carbon AA
R895 VRD-RA2BE470J J 47 1/8W Carbon AA
MISCELLANEOUS PARTS
P851 QPLGN0541CEZZ J Plug, 5-pin(GBN) AB
P852 QPLGN0441CEZZ J Plug, 4-pin(YBN) AB
SC851 QSOCV0937CEZZ J CRT Socket AL
INTEGRATED CIRCUITS
IC850 VHiTDA6101Q-1 J TDA6101Q AH
IC851 VHiTDA6101Q-1 J TDA6101Q AH
IC852 VHiTDA6101Q-1 J TDA6101Q AH
TRANSISTORS
Q851 VS2SA1246//1E J 2SA1246 AE
Q852 VS2SC3198-Y-1 J 2SC3198(Y) AA
DIODES
D850 RH-EX0647GEZZ J Zener Diode, 15V AA
D851 VHD1SS119//-1 J Diode AB
D852 RH-EX0718GEZZ J Zener Diode,2.5V AB
D853 RH-EX0647GEZZ J Zener Diode,15V AA
D854 RH-EX0647GEZZ J Zener Diode,15V AA
D860 RH-EX0718GEZZ J Zener Diode,2.5V AB
D862 RH-DX0220CEZZ J Diode AB
CAPACITORS
[EL.··· Electrolytic]
C850 VCEA0A1CW477M J 470 16V EL. AC
C853 VCEA0A1CW227M J 220 16V EL. AC
C863 VCEA0A1HW106M J 10 50V EL. AB
C868 VCEA0A2EW106M J 10 250V EL. AD
C869 RC-KZ0153CEZZ J 0.001 3kV Ceramic AB
C870 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C871 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C873 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C874 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C876 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C877 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C880 RC-FZ0373CEZZ J 0.033 250V Mylar AC
C881 VCQYTA1HM472J J 4700p 50V Mylar AB
C882 RC-FZ0373CEZZ J 0.033 250V Mylar AC
C883 VCQYTA1HM472J J 4700p 50V Mylar AB
C884 RC-FZ0373CEZZ J 0.033 250V Mylar AC
C885 VCQYTA1HM472J J 4700p 50V Mylar AB
RESISTORS
[M-Ox.··· Metal Oxide]
R850 VRD-RA2BE101J J 100 1/8W Carbon AB
R851 VRD-RA2BE101J J 100 1/8W Carbon AB
R852 VRD-RA2BE101J J 100 1/8W Carbon AB
R853 VRD-RA2BE223J J 22k 1/8W Carbon AA
R855 VRD-RA2BE223J J 22k 1/8W Carbon AA
R856 VRD-RA2EE680J J 68 1/4W Carbon AA
R863 VRS-SV2HC122J J 1.2k 1/2W M-Ox. AA
R866 VRS-SV2HC122J J 1.2k 1/2W M-Ox. AA
R868 VRS-SV2HC122J J 1.2k 1/2W M-Ox. AA
R872 VRS-SV2HC272J J 2.7k 1/2W M-Ox. AA
R875 VRS-SV2HC272J J 2.7k 1/2W M-Ox. AA
R876 VRS-SV2HC272J J 2.7k 1/2W M-Ox. AA
R877 VRD-RA2BE222J J 2.2k 1/8W Carbon AA
R878 VRD-RA2BE222J J 2.2k 1/8W Carbon AA
R879 VRD-RA2BE222J J 2.2k 1/8W Carbon AA
å R880 VRS-VV3DB823J J 82k 2W M-Ox. AA
å R883 VRS-VV3DB823J J 82k 2W M-Ox. AA
å R884 VRS-VV3DB823J J 82k 2W M-Ox. AA
R888 VRC-MA2HG152K J 1.5k 1/2W Solid AA
å R890 VRS-SV2HC120J J 12 1/2W M-Ox. AA
R891 VRC-MA2HG152K J 1.5k 1/2W Solid AA
R893 VRD-RM2HD224J J 220k 1/2W Carbon AA
R894 VRC-MA2HG152K J 1.5k 1/2W Solid AA
R895 VRD-RA2BE392J J 3.9k 1/8W Carbon AA
R896 VRD-RA2BE182J J 1.8k 1/8W Carbon AA
R897 VRD-RA2BE154J J 150k 1/8W Carbon AA
R898 VRD-RA2BE333J J 33k 1/8W Carbon AA
R899 VRD-RA2BE123J J 12k 1/8W Carbon AA
R1532 VRS-RG2HC560J M 56 1/2W M-Ox. AA
PWB-B: DUNTK9835WEK2(27L-X2000, CL27X200)
CRT UNIT
