Sharp 27L-S500 - Replacement Parts List

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
46
27L-S500,27L-X2000
CL27S50,CL27X200
Ref. No. Part No. ★ Description Code
PICTURE TUBE
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
Ref. No. Part No. ★ Description Code
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by å and shaded areas in the Replacement Parts Lists
and Schematic Diagrams. The use of a substitute replacement part
which dose no have the same safety characteristic as the factory
recommended replacement parts shown in this service manual may
create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
in USA: Contact your nearest SHARP Parts Distributor to order.
For location of SHARP Parts Distributor, Please call Toll-
Free; 1-800-BE-SHARP
★ MARK: SPARE PARTS-DELIVERY SECTION
▲ MARK: X- RAY RELATED PARTS
LISTE DES PIECES
CHANGE DES PIECES
Les pi`eces de rechange qui pr élelesentent ces caract éleristiques
sp éleciales de s élecurit éle, sont identifi élees dans ce manuel : les
pi`eces élelectriques qui pr élesentent ces particularit éles, sont rep
éler élee par la marque å et sont hachur élees dans les listes de
pi`eces et dans les diagrammes sch élematiques.
La substitution d'une pi`ece de rechange par une autre qui ne pr
éLesente pas les m éoemes caract éLeristiques de s élecurit éle que
la pi`ece recommand élee parl'usine et dans ce manuel de service,
peut provoquer une éLelectrocution, un incendie ou toutautre sinistre.
"COMMENT COMMANDER LES PIECES DE RECHANGE"
Pour que votre commande soit rapidement et correctement remplie,
veuillez fournir les renseignements suivants.
1. NUMERO DU MODELE 2. NO. DE REF
3. NO. DE PIECE 4. DESCRIPTION
in CANADA: Contact SHARP Electronics of Conada Limited
Phone (416) 890-2100
★MARQUE: SECTION LIVRAISON DES PIECES DE RECHANGE
▲ MARQUE: PIECES RELATIVE AUX RAYONS X
çå V101 VB68ADT2506*S M Picture Tube (I.T.C.) CP
å L702 RCiLG0038MEZZ M Degaussing Coil AP
or (PR701:P0088CE)
RCiLG0032MEZZ M Degaussing Coil AS
(PR701:P0026CE)
MSPRT0002MEZZ M Spring for CRT AA
å QEARC2702MEZZ M Grounding-Part AD
27L-S500, CL27S50
PWB-A DUNTK9640WEK1 – Main Unit —
PWB-B DUNTK9510WEK2 – CRT Unit —
PWB-H DUNTK9310WEK1 – Front AV Unit —
PWB-K DUNTK9641WEK1 – Sub Unit —
PWB-R DUNTK9642WEK0 – P-IN-P Unit —
27L-X2000, CL27X200
PWB-A DUNTK9640WEK2 – Main Unit —
PWB-B DUNTK9835WEK2 – CRT Unit —
PWB-H DUNTK9310WEK1 – Front AV Unit —
PWB-K DUNTK9641WEK2 – Sub Unit —
PWB-L DUNTK9657WEK0 – Surround Unit —
PWB-R DUNTK9642WEK0 – P-IN-P Unit —
INTEGRATED CIRCUITS
IC401 RH-iX3113CEZZ J TA1276AN AZ
å IC501 VHiTA8427K/-1 J TA8427K AL
IC502 VHiTA1241AN-1 J TA1241AN AM
çå IC701 RH-iX0758CEZZ J T8150 AF
å IC702 VHiT8889A//-1 J T8889A AL
å IC751 VHiKA7809Pi-1 M KIA7809PI AE
IC781 VHiKA7805Pi-1 M KIA7809PI AE
IC1301 VHiMM1313AD-1 J MM1313AD AP
IC2001 RH-iX3274CEN2 M I.C. AX
IC2003 VHiKiA7045P-1 J KIA7045P AD
IC2701 VHiKA78S05P-1 J KIA78S05P AD
TRANSISTORS
You can substitute "VS2SC2412-C-1" or "VS2SC2462-C-1" for
"VS2SD601AR/-1".
Q451 VS2SA1266-Y-1 J 2SA1266(Y) AA
Q601 VS2SC2655Y/-1 J 2SC2655(Y) AE
å Q602 VS2SD2539//1E J 2SD2539 AP
or
VS2SD1556//1E
Q606 VS2SC3198-Y-1 J 2SC3198(Y) AA
å Q751 VS2SC1983//-2 J 2SC1983 AF
Q752 VS2SC3198-Y-1 J 2SC3198(Y) AA
Q753 VS2SA1013//1E J 2SA1013 AD
Q1301 VS2SD601AR/-1 J 2SD601AR AC
Q1302 VS2SD601AR/-1 J 2SD601AR AC
Q1402 VS2SB709AR/-1 J 2SB709AR AC
Q1404 VS2SD601AR/-1 J 2SD601AR AC
Q1405 VS2SD601AR/-1 J 2SD601AR AC
Q2004 VSUN2212///-1 J VSUN2212 AA
PWB-A: DUNTK9640WEK1(27L-S500, CL27S50)
MAIN UNIT
Q602 R603 R609
COMBI- 2SD2539 12/3W/(RG) 12/3W/(RG)
NATION 2SD1556 18/3W/(RG) 18/3W/(RG)
