Sharp 27L-S500 - Page 60

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
60
27L-S500,27L-X2000
CL27S50,CL27X200
PWB-L: DUNTK9657WEK0(27L-X2000, CL27X200)
SURROUND UNIT (Continued)
MISCELLANEOUS PARTS
P3201 QPLGN0685CEZZ J Plug, 6-pin (LA) AA
P3202 QPLGN0685CEZZ J Plug, 6-pin (LB) AA
PWB-R: DUNTK9642WEK0
P-IN-P UNIT
INTEGRATED CIRCUIT
IC1801 VHiM65667FP-2 M M65667FP BB
TRANSISTORS
You can substitute "VS2SC2412-C-1" or "VS2SC2462-C-1" for
"VS2SD601AR/-1".
Q1861 VS2SB709AR/-1 J 2SB709AR AC
or
VS2SA1037KR-1
Q1881 VS2SD601AR/-1 J 2SD601AR AC
Q1882 VS2SD601AR/-1 J 2SD601AR AC
Q1883 VS2SD601AR/-1 J 2SD601AR AC
Q1921 VS2SD601AR/-1 J 2SD601AR AC
Q1941 VS2SB709AR/-1 J 2SB709AR AC
or
VS2SA1037KR-1
Q1942 VS2SB709AR/-1 J 2SB709AR AC
or
VS2SA1037KR-1
Q1991 VS2SC1959Y/1E J 2SC1959(Y) AC
DIODES
You can substitute "RH-DX0475CEZZ" for "VHD1SS119//-1".
D1801 VHD1SS119//-1 J Diode AB
D1821 VHD1SS119//-1 J Diode AB
D1991 RH-EX0604GEZZ J Zener Diode, 3.9V AB
PACKAGED CIRCUIT
X1861 RCRSB0241CEZZ M Crystal AE
COILS
L1801 VP-XF100K0000 J Peaking 10µH AB
L1821 VP-XF100K0000 J Peaking 10µH AB
L1861 VP-XF100K0000 J Peaking 10µH AB
L1862 VP-XF100K0000 J Peaking 10µH AB
L1863 VP-XF100K0000 J Peaking 10µH AB
L1881 VP-XFR27K0000 J Peaking 0.27µH AB
L1882 VP-XFR27K0000 J Peaking 0.27µH AB
L1921 VP-XF680K0000 J Peaking 68µH AB
L1941 VP-XFR27K0000 J Peaking 0.27µH AB
L1981 VP-XFR27K0000 J Peaking 0.27µH AB
CAPACITORS
[EL.··· Electrolytic]
C1801 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1802 VCKYCY1HB103K J 0.01 50V Ceramic AA
C1803 VCKYCY1HB103K J 0.01 50V Ceramic AA
C1804 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1805 VCEA0A1HW106M J 10 50V EL. AB
C1806 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1807 VCKYCY1HB103K J 0.01 50V Ceramic AA
C1809 VCKYCY1HB103K J 0.01 50V Ceramic AA
C1810 VCEA0A1CW226M J 22 16V EL. AB
C1811 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1812 VCEA0A1HW106M J 10 50V EL. AB
C1821 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1822 VCEA0A1HW106M J 10 50V EL. AB
C1826 VCKYCY1HB272K J 2700p 50V Ceramic AA
C1841 VCEA0A1HW106M J 10 50V EL. AB
C1842 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1843 VCCCCY1HH680J J 68p 50V Ceramic AA
C1845 VCKYCY1HB103K J 0.01 50V Ceramic AA
C1846 VCCCCY1HH151J J 150p 50V Ceramic AA
C1847 VCKYCY1HB103K J 0.01 50V Ceramic AA
C1848 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1849 VCEA0A1HW106M J 10 50V EL. AB
C1850 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1851 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1861 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1862 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1863 VCCCCY1HH101J J 100p 50V Ceramic AA
