Sharp 29FL84M - Printed Wiring Board Assemblies; Parts List

PRINTED WIRING BOARD ASSEMBLIES
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by å and shaded areas in the Replacement Parts Lists
and Schematic Diagrams. The use of a substitute replacement part
which dose no have the same safety characteristic as the factory
recommended replacement parts shown in this service manual may
create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBE
R2. REF. NO.
3. PART NO.4. DESCRIPTION
in USA:Contact your nearest SHARP Parts Distributor to order.
For location of SHARP Parts Distributor, Please call Toll-
Free; 1-800-BE-SHARP
« MARK: SPARE PARTS-DELIVERY SECTION
p
MARK: X-RAY RELATED PARTS
PICTURE TUBE
(NOT REPLACEMENT ITEM)
MAIN UNIT
PWB-A: DUNTKC290WEB9
TUNER
NOTE:THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDETLY
Ref. No. Part No. « Description Code
p U V101 VB68QCU770X2E X Picture Tube CH
U L799 RCILG0056PEZZ X Degaussing Coil AN
U QEARCA010WJZZ X Ground-Part AF
PWB-A DUNTKC290WEB9 — MAIN Unit —
PWB-B DUNTKA527WEW7 — CRT Unit —
PWB-C DUNTKB573WEV0 — 3-LINE Y/C Unit —
Ref. No. Part No. « Description Code
U TU51 VTUVT1T5UF202 X Tuner AS
IC101 VHIPQ050ES1-1+ X PQ050ES1MXP AD
p U IC201 VHITB1253AN-1 X TB1253AN AS
U IC361 VHIAN5277//-1 X AN5277 AK
U IC501 VHIAN15526A-1 X AN15526A AG
IC602 VHIBA15218F2EY X BA15218F AD
U IC701 VHITEA1533A-1 X TEA1533AP AG
U IC702 RH-FXA003WJZZ X PC123Y82 AC
pU IC703 VHISE130N++-F X SE130N AF
IC751 VHIPQ09RDA1-1 X PQ090RDA1SZ AF
IC900 VHICXA2089Q-2Y X CXA2089Q-6T AM
IC1403 VHIPQ05RDA1-1 X PQ050RDA1SZ AF
IC2001 RH-IXA418WJZZQ X TMP88CS38BFG AQ
IC2040 VHIKIA7045A-1+ X KIA7045AP AC
IC2101 VHIBR24L16F-1Y X BR24L16F AE
IC3001 VHICXA2194Q-1Y X CXA2194Q AR
Q201 VS2SC2735//1EY X 2SC2735 AB
Q361 VS2SB709AR/-1Y X 2SB709AR AA
Q401 VS2SD601AR/-1Y X 2SD601AR AA
Q402 VS2SB709AR/-1Y X 2SB709AR AA
Q403 VS2SD601AR/-1Y X 2SD601AR AA
Q404 VS2SD601AR/-1Y X 2SD601AR AA
Q451 VS2SA1266-Y-1+ X 2SA1266(Y) AB
Q460 VSRT1N441C/-1Y X RT1N441C AB
Q471 VS2SD601AR/-1Y X 2SD601AR AA
Q472 VS2SD601AR/-1Y X 2SD601AR AA
Q473 VS2SD601AR/-1Y X 2SD601AR AA
Q601 VS2SC2482//-1+ X 2SC2482 AC
U Q602 VS2SD2581++2E X SD2581++ AK
Q672 VS2SA1266-Y-1+ X 2SA1266(Y) AB
Q673 VS2SD1830//1E X 2SD1830 AF
U Q701 VSSPA07N603-1 X SPA07N60C3 AK
U Q751 VS2SC3198-G-1+ X 2SC3198-G AB
Q754 VS2SC3198-G-1+ X 2SC3198-G AB
Q755 VS2SD601AR/-1Y X 2SD601AR AA
Q756 VS2SD601AR/-1Y X 2SD601AR AA
Q757 VS2SC3198-G-1+ X 2SC3198-G AB
Q758 VS2SA1266-Y-1+ X 2SA1266(Y) AB
Q802 VS2SD601AR/-1Y X 2SD601AR AA
Q901 VS2SD601AR/-1Y X 2SD601AR AA
Q902 VS2SD601AR/-1Y X 2SD601AR AA
Q903 VS2SD601AR/-1Y X 2SD601AR AA
Q904 VS2SD601AR/-1Y X 2SD601AR AA
Q905 VS2SD601AR/-1Y X 2SD601AR AA
Q906 VS2SD601AR/-1Y X 2SD601AR AA
Q907 VS2SD601AR/-1Y X 2SD601AR AA
Q908 VS2SB709AR/-1Y X 2SB709AR AA
Q910 VS2SB709AR/-1Y X 2SB709AR AA
Q2041 VS2SB709AR/-1Y X 2SB709AR AA
Q2042 VS2SB709AR/-1Y X 2SB709AR AA
Q2060 VS2SD601AR/-1Y X 2SD601AR AA
Q2201 VS2SD601AR/-1Y X 2SD601AR AA
Q2211 VS2SD601AR/-1Y X 2SD601AR AA
D52 RH-EX0676GEZZY X Zener Diode 32V AB
D103 RH-DX0441CEZZY X Diode AA
D361 VHD1SS133++-1Y X Diode AA
D362 VHD1SS133++-1Y X Diode AA
D410 RH-EX0611GEZZY X Zener Diode 5.1V AB
D411 RH-EX0611GEZZY X Zener Diode 5.1V AB
INTEGRATED CIRCUITS
TRANSISTORS
DIODES
29FL84M
25
