Sharp 29FL84M - Crt Unit

PWB-A: DUNTKC290WEB9
MAIN UNIT
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
PWB-B: DUNTKA527WEW7
CRT UNIT
INTEGRATED CIRCUITS
TRANSISTORS
DIODES
MISCELLANEOUS PARTS
FERRITE BEAD
SWITCHES
Ref. No. Part No. « Description Code
R3005 VRS-CY1JF623JY X 62k 1/16W M-Ox. AA
R3007 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R3008 VRS-CY1JF302JY X 3k 1/16W M-Ox. AA
R3010 VRS-CY1JF392JY X 3.9k 1/16W M-Ox. AA
R3017 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R3018 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R3019 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R3024 VRD-RA2BE102JY X 1k 1/8W Carbon AA
S2501 QSW-KA003WJZZ+ X Switch, AB
S2502 QSW-KA003WJZZ+ X Switch, AB
S2503 QSW-KA003WJZZ+ X Switch, AB
S2504 QSW-KA003WJZZ+ X Switch, AB
S2505 QSW-KA003WJZZ+ X Switch, AB
S2506 QSW-KA003WJZZ+ X Switch, AB
FB601 RBLN-0047CEZZY X FERRITE BEAD AB
FB706 RBLN-0037CEZZY X FERRITE BEAD AA
FB2001 RBLN-0037CEZZY X FERRITE BEAD AA
U ACC701 QACCD3070CESA X AC Cord AH
U F701 QFS-B4023CEZZ X FUSE - 4A 125V AC
U FH701 QFSHD1013CEZZ+ X FUSE CLIP AB
U FH702 QFSHD1014CEZZ+ X FUSE CLIP AB
J904 QJAKGA023WJZZ X JACK (A/V) AD
J921 QSOCD0456CEZZ X Socket, S-Video AD
J1401 QTANJ1101SEZZ X AV In/Out Terminal AG
P361 QPLGN0461CEZZA X plug, 4pin(S1-4) AB
P401 QPLGN0861CEZZA X plug,8pin(CJ) AC
P605 QPLGN0160FJZZ X plug 5pin(K1-5) AC
P621 QPLGN0761CEZZA X plug,7pin(N) AB
P651 QPLGN0361CEZZA X plug,3pin,(TP651-3) AB
P702 QPLGN0269GEZZ X plug 2pin(P1-2) AB
P703 QPLGN0260CEZZ X plug 2pin(M1-2) AB
P2401 QPLGN0661CEZZA X plug,6pin AB
RDA361 PRDAR0258PEFW X Heat Sink AE
RDA501 PRDARA039WJFW X Heat Sink AF
RDA601 PRDARA041WJFW X Heat Sink AF
RDA671 PRDARA057WJFW X Heat Sink AD
RDA701 PRDAR0279PEFW X Heat Sink AD
RDA750 PRDAR5072CEFW X Heat Sink AC
RDA1403 PRDAR5072CEFW X Heat Sink AC
RMC2601 RRMCU0222CEZZ X R/C Receiver AF
RY701 RRLYJ0081CEZZ X Relay AE
RY702 RRLYJ0088CEZZ X Relay AE
U IC850 VHITDA6103Q-1 X TDA6103Q/N3 AK
Q850 VS2SA1266-Y-1+ X 2SA1266(Y) AB
Q851 VS2SC3198-G-1+ X 2SC3198-G AB
Q1504 VS2SC3198-G-1+ X 2SC3198-G AB
Q1505 VS2SA1266-Y-1+ X 2SA1266(Y) AB
Q1506 VS2SA1964E/-1 X 2SA1964E AE
Q1507 VS2SC5248E/-1 X 2SC5248E AE
D850 RH-DX0220CEZZY X DX0220CE AB
D851 RH-DX0220CEZZY X DX0220CE AB
D852 RH-DX0220CEZZY X DX0220CE AB
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
Ref. No. Part No. « Description Code
D853 RH-EX0647GEZZY X Zener Diode, 15V AB
D854 VHD1SS119//-1Y X Diode AA
D855 VHD1SS119//-1Y X Diode AA
D862 VHD1SS119//-1Y X Diode AA
D1502 VHD1SS119//-1Y X Diode AA
D1503 VHD1SS119//-1Y X Diode AA
D1506 RH-DX0487CEZZY X Diode AC
D1507 RH-DX0487CEZZY X Diode AC
D1510 VHD1SS119//-1Y X Diode AA
C850 VCFYSB2EB224K X 0.22 250V M.Poly. AB
C851 RC-KZ018JCEZZ X 0.01 AC250V Ceramic AB
C852 VCEA0A1CW107M+ X 100 16V EL. AA
C853 VCFYFA1HA224J+ X 0.22 50V Mylar AB
C854 VCEA0A1CW227M+ X 220 16V EL. AB
C855 VCEA0A2EW106M+ X 10 250V EL. AC
C856 VCEA0A1HW226M+ X 22 50V EL. AA
C1501 VCEA0A1CW476M+ X 47 16V EL. AA
C1506 VCKYPA1HF103Z+ X 0.01 50V Ceramic AA
C1508 VCKYPA2HB472K+ X 4700p 500V Ceramic AB
C1509 VCKYPA1HB472K+ X 4700p 50V Ceramic AA
C1510 VCKYPA1HF103Z+ X 0.01 50V Ceramic AA
C1511 VCKYPA1HF103Z+ X 0.01 50V Ceramic AA
C1515 VCEA0A1HW476M+ X 47 50V EL. AB
C1516 VCEA0A1HW476M+ X 47 50V EL. AB
C1517 VCEA0A2AW106M+ X 10 100V EL. AB
C1518 VCCSPA2HL560K+ X 56p 500V Ceramic AB
C1519 VCEA0A2CW106M+ X 10 160V EL. AB
U R850 VRS-SV2HC152J X 1.5k 1/2W M-Ox. AA
U R851 VRS-SV2HC152J X 1.5k 1/2W M-Ox. AA
U R852 VRS-SV2HC152J X 1.5k 1/2W M-Ox. AA
U R853 VRS-SV2HC272J X 2.7k 1/2W M-Ox. AA
U R854 VRS-SV2HC272J X 2.7k 1/2W M-Ox. AA
U R855 VRS-SV2HC272J X 2.7k 1/2W M-Ox. AA
R856 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R857 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R858 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R861 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R862 VRC-MA2HG152KY X 1.5k 1/2W Solid AB
R863 VRC-MA2HG152KY X 1.5k 1/2W Solid AB
R864 VRC-MA2HG152KY X 1.5k 1/2W Solid AB
U R867 VRS-SV2HC392J X 3.9k 1/2W M-Ox. AA
U R868 VRS-SV2HC682J X 6.8k 1/2W M-Ox. AA
R869 VRD-RA2BE103JY X 10k 1/8W Carbon AA
R870 VRD-RA2BE223JY X 22k 1/8W Carbon AA
R871 VRD-RA2BE472JY X 4.7k 1/8W Carbon AA
R872 VRD-RA2EE680JY X 68 1/4W Carbon AA
R873 VRD-RM2HD224JY X 220k 1/2W Carbon AA
R874 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R875 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R876 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R877 VRD-RA2BE103JY X 10k 1/8W Carbon AA
U R878 VRS-SV2HC120J X 12 1/2W M-Ox. AA
R1511 VRD-RA2BE101JY X 100 1/8W Carbon AA
U R1513 VRS-VV3DB561J X 560 2W M-Ox. AA
R1514 VRD-RA2BE100JY X 10 1/8W Carbon AA
R1515 VRD-RA2BE820JY X 82 1/8W Carbon AA
R1516 VRD-RA2BE820JY X 82 1/8W Carbon AA
R1517 VRD-RA2BE122JY X 1.2k 1/8W Carbon AA
R1518 VRD-RA2BE683JY X 68k 1/8W Carbon AA
R1519 VRD-RA2BE123JY X 12k 1/8W Carbon AA
R1520 VRD-RA2BE683JY X 68k 1/8W Carbon AA
R1521 VRD-RA2BE122JY X 1.2k 1/8W Carbon AA
R1525 VRD-RA2EE560JY X 56 1/4W Carbon AA
R1526 VRD-RA2EE560JY X 56 1/4W Carbon AA
