29L-FG1L
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PICTURE TUBE
!
VB68MAU085X3E R S-ITC MTPDT AK(N) Picture Tube
!
RCILGA127WJN2 R Degaussing Coil
PMAGG3002CEZZ AC R Magnet
QEARCA045WJPZ R Ground-Part
[2] PRINTED WIRING BOARD ASSEMBLIES
DUNTKD538WEG1 - - PWB-A : MAIN Unit
DUNTKD539WEE9 - - PWB-B : CRT Unit
[3] MAIN UNIT
!
TU51 VTUVT1Y5EF201 R Tuner
IC301 VHILA42072N-1 AK R LA42072N
IC501 VHITDA4863AJ1 AK R TDA4863AJ
!
IC701 VHISTRW6556-1 AP R STRW6556A
!
IC702 RH-FXA003WJZZ AD R PC123Y82
IC704 VHIBD33KA5W-1Y AF R BD33KA5WF-E2
IC714 VHIMM1431AT-1+ AD R MM1431ATT
IC751 VHIBA50B0WP-1Y AF R BA50BC0WFP-E2
!
IC752 VHIBA50B0WP-1Y AF R BA50BC0WFP-E2
IC2031 VHIBD4847G+-1Y AC R BD4847G-TR
IC2100 RH-IXB841WJZZQ R IXB841W
IC2101 VHIBR24L16F-1Y AF R BR24L16F-WE2
IC2102 VHIBD00K5WP-1Y AF R BD00KA5WFP-E2
IC2104 VHIBD00K5WP-1Y AF R BD00KA5WFP-E2
Q200 VS2SC2735//1EY AC R 2SC2735
Q310 VS2PB709AR/-1Y AB R 2PB709AR
Q312 VS2PD601AR/-1Y AB R 2PD601AR
Q602 VS2SK2161++-1 AG R 2SK2161++
Q603 VS2PD601AR/-1Y AB R 2PD601AR
!
Q604 VS2SD2646++1E AM R 2SD2646++
Q605 VS2PB709AR/-1Y AB R 2PB709AR
Q606 VS2SC2482//-1+ AD R 2SC2482
Q607 VSKRC103S//-1Y AA R KRC103S
Q609 VS2SC3198-Y-1+ AA R 2SC3198-Y
Q755 VS2SC3198-G-1+ AA R 2SC3198-G
Q902 VS2PD601AR/-1Y AB R 2PD601AR
Q903 VS2PD601AR/-1Y AB R 2PD601AR
Q904 VS2PB709AR/-1Y AB R 2PB709AR
Q905 VS2PB709AR/-1Y AB R 2PB709AR
Q906 VS2PD601AR/-1Y AB R 2PD601AR
Q907 VSKRC105S//-1Y AB R KRC105S
Q4001 VS2PB709AR/-1Y AB R 2PB709AR
Q4002 VS2PD601AR/-1Y AB R 2PD601AR
D52 RH-EX0677GEZZY AC R Zener Diode , 32V
D202 VHD1SS133++-1Y AA R 1SS133
D203 RH-EX0627GEZZY AA R Zener Diode , 8.2V
D305 VHD1SS133++-1Y AA R 1SS133
D310 VHD1SS133++-1Y AA R 1SS133
D311 RH-DX0302CEZZY AC R DX0302CE
D322 VHD1SS355//-1Y R 1SS355
D501 RH-DX0441CEZZY AC R DX0441CE
D502 VHD1SS133++-1Y AA R 1SS133
D503 RH-EX0612GEZZY AB R Zener Diode , 5.2V
D601 VHD1SS244//-1Y AB R 1SS244
D603 RH-DX0131CEZZY AC R DX0131CE
!
D604 RH-EX0640GEZZY AA R Zener Diode , 12.03V
D605 RH-DX0302CEZZY AC R DX0302CE
!
D606 VHD1SS133++-1Y AA R 1SS133
!
D607 RH-DX0255CEZZ AC R DX0255CE
!
D608 RH-DXA006WJZZ AD R DXA006WJ
D610 RH-EX0612GEZZY AB R Zener Diode , 5.2V
D611 RH-DX0302CEZZY AC R DX0302CE
D612 VHD1SS133++-1Y AA R 1SS133
D613 VHD1SS133++-1Y AA R 1SS133
D616 RH-DX0321CEZZY AC R DX0321CE
D617 RH-EX0604GEZZY AB R Zener Diode , 4.16V
D671 RH-EX0604GEZZY AB R Zener Diode , 4.16V
D703 RH-EX0654GEZZY AB R Zener Diode , 18.96V
!
D704 RH-DX0477CEZZ AF R DX0477CE
D705 VHD1SS133++-1Y AA R 1SS133
D708 VHD1SS244//-1Y AB R 1SS244
D713 RH-DX0321CEZZY AC R DX0321CE
D751 RH-DXA006WJZZ AD R DXA006WJ
D752 VHD1SS133++-1Y AA R 1SS133
D753 RH-DX0302CEZZY AC R DX0302CE
D755 RH-DX0445CEZZ AL R DX0445CE
D757 VHD1SS133++-1Y AA R 1SS133
D758 VHD1SS133++-1Y AA R 1SS133
D759 VHD1SS133++-1Y AA R 1SS133
D901 VHD1SS133++-1Y AA R 1SS133
D2001 VHD1SS133++-1Y AA R 1SS133
D2106 RH-EX0630GEZZY AA R Zener Diode , 9V
D2107 RH-EX0630GEZZY AA R Zener Diode , 9V
D2108 RH-EX0630GEZZY AA R Zener Diode , 9V
