29L-FG1L
8
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
R4023 VRS-CY1JF103JY AA R 10k 1/16W Metal Oxide
R4024 VRS-CY1JF473JY AA R 47k 1/16W Metal Oxide
R4025 VRS-CY1JF472JY AA R 4.7k 1/16W Metal Oxide
R4033 VRD-RA2BE181JY AA R 180 1/8W Carbon
R4911 VRS-CY1JF472JY AA R 4.7k 1/16W Metal Oxide
R4912 VRS-CY1JF103JY AA R 10k 1/16W Metal Oxide
R4913 VRS-CY1JF472JY AA R 4.7k 1/16W Metal Oxide
R4914 VRS-CY1JF103JY AA R 10k 1/16W Metal Oxide
R5021 VRS-CY1JF181JY AA R 180 1/16W Metal Oxide
R5026 VRS-CY1JF331JY AA R 330 1/16W Metal Oxide
S4001 QSW-K0079GEZZ+ AB R Switch , MENU
S4002 QSW-K0079GEZZ+ AB R Switch , VOL UP
S4003 QSW-K0079GEZZ+ AB R Switch , CH DOWN
S4004 QSW-K0079GEZZ+ AB R Switch , CH UP
S4005 QSW-K0079GEZZ+ AB R Switch , VOL DOWN
S4701 QSW-PA006WJZZ AG R Switch , POWER
FB501 RBLN-0047CEZZY AB R Ferritte Bead
FB502 RBLN-0047CEZZY AB R Ferritte Bead
!
FB601 RBLN-0047CEZZY AB R Ferritte Bead
FB602 RBLN-0047CEZZY AB R Ferritte Bead
FB603 RBLN-A203WJZZ+ AB R Ferritte Bead
FB700 RBLN-0036CEZZY AB R Ferritte Bead
FB703 RBLN-A203WJZZ+ AB R Ferritte Bead
FB705 RBLN-A203WJZZ+ AB R Ferritte Bead
FB751 RBLN-0047CEZZY AB R Ferritte Bead
FB752 RBLN-A034WJZZY AA R Ferritte Bead
FH4701 QFSHD1013CEZZ+ AC R Fuse Holder
FH4702 QFSHD1014CEZZ+ AC R Fuse Holder
F4701 QFS-CA003WJZZ AC R Fuse , 5A , 250V
J1 VW7UGB6-060KK R Jumper
J5 QCNW-F070WJPZ R FBT GND TO CRT
J6 QCNW-F071WJPZ R TUNER - CRT GND
J352 QJAKJ0101SEZZ AE R HP Jack
J905 QTANJA088WJZZ AG R Terminal
J4901 QJAKGA023WJZZ AE R Front AV Jack
P301 QPLGNA109WJZZ AB R Plug , 4pin
!
P601 QPLGN0160FJZZ AD R Plug , 5pin (K)
P701 QPLGN0260CEZZ AC R Plug , 2pin
P2100 QPLGN0661CEZZ AD R Plug , 6pin
P2101 QPLGN0661CEZZ AD R Plug , 6pin
P4701 QPLGN0269GEZZ AB R Plug , 2pin (AC)
RDA301 PRDARA287WJFW AH R Heat Sink for IC301
RDA501 PRDARA288WJFW AG R Heat Sink for IC501
RDA602 PRDARA123WJPW AF R Heat Sink for Q602
RDA604 PRDARA113WJPW AF R Heat Sink for Q604
!
RDA701 PRDARA286WJFW AG R Heat Sink for IC701
RDA755 PRDARA181WJFW AC R Heat Sink for D755
!
RY701 RRLYJ0089CEZZ AG R Relay
TP53 QLUGP0102PEZZ AA R Lug
[4] CRT UNIT
IC851 VHITDA6107A-1 AK R TDA6107AJF/N1
D851 RH-DX0443CEZZY AB R DX0443CE
D852 RH-DX0443CEZZY AB R DX0443CE
D853 RH-DX0443CEZZY AB R DX0443CE
C851 VCFYSB2EB823J AD R 0.082 250V
C852 VCEA0A2EW106M+ AD R 10 250V Electrolytic
C854 RC-KZ018JCEZZ AC R 0.01 AC250/Ceramic
C856 VCKYPA2HB102K+ AA R 1000p 500V Ceramic
C861 VCKYPA2HB102K+ AA R 1000p 500V Ceramic
C862 VCKYPA2HB561K+ AA R 560p 500V Ceramic
R851 VRD-RM2HD391JY AA R 390 1/2W Carbon
R852 VRD-RM2HD391JY AA R 390 1/2W Carbon
R853 VRD-RM2HD391JY AA R 390 1/2W Carbon
R854 VRC-MA2HG152KY AA R 1.5k 1/2W Solid
R855 VRC-MA2HG152KY AA R 1.5k 1/2W Solid
R856 VRC-MA2HG152KY AA R 1.5k 1/2W Solid
R861 VRD-RM2HD224JY AA R 220k 1/2W Carbon
R862 VRD-RA2BE101JY AA R 100 1/8W Carbon
R863 VRD-RA2BE221JY AA R 220 1/8W Carbon
R864 VRD-RA2BE221JY AA R 220 1/8W Carbon
R865 VRD-RA2BE221JY AA R 220 1/8W Carbon
R858 VRS-RG2HC100J+ AA R 10 1/2W Metal Oxide
L850 RCILP0179CEZZ+ R Filter
FB852 RBLN-A034WJZZY AA R Ferrite Bead
P851 QTIPM0083CEZZ AB R Tip
P852 QTIPM0083CEZZ AB R Tip
RDA851 PRDAR0248PEFW AF R Heat Sink , IC851
!
SC851 QSOCVA024WJZZ R Socket 12pin
[3] MAIN UNIT
