Sharp 70GS-64SDE - Page 38

38
70GS-64S
REF No. PARTS DESCRIPTION * SN CODE EX CODE
D 1809 RH-DX0501BMZZ DIODE 1N4004 S AA AA
D 1810 RH-EX0546BMZZ ZENER DIODE TZMC5V6 TFK SMD S AA AA
D 1813 RH-DX0505BMZZ DIODE 1N4935 S AB AE
D 1814 RH-DX0505BMZZ DIODE 1N4935 S AB AE
D 1815 RH-DX0505BMZZ DIODE 1N4935 S AB AE
COILS
L 1801 RCILP0276BMZZ COIL AR621LY-470K=R TOKO S AC AD
L 1802 VP-NM470K2R0N COIL 47UH SMD 10% S AA AC
CAPACITORS
C 1801 VCKYTV1HF104Z CERAM C 100NF 50V 2125SMD S AA AA
C 1805 VCKYTV1EF224Z CERAM C 220NF 25V 2125SMD S AA AA
C 1806 VCKYTV1HF103Z CERAM C 10NF 50V 2125SMD S AA AA
C 1807 VCEAGA1CW107M ELEC C 100UF 20% 16V S AA AA
C 1811 VCEAGA2EW106M ELEC C 10UF 20% 250V S AA AC
C 1812 VCEAGA2EW105M ELEC C 1UF 20% 250V S AA AB
C 1813 VCKYTV1HF103Z CERAM C 10NF 50V 2125SMD S AA AA
C 1814 VCKYPB3DE472Z C DE1110-1E472Z2K MURATA S AA AC
C 1815 VCKYTV1HF473Z CERAM C 47NF 50V 2125SMD S AA AA
C 1820 VCCCTV1HH100D CERAM C 10PF 50V 2125SMD S AA AA
C 1821 VCCCTV1HH100D CERAM C 10PF 50V 2125SMD S AA AA
C 1822 VCCCTV1HH100D CERAM C 10PF 50V 2125SMD S AA AA
C 1823 VCEAGA1CW226M ELEC C 22UF 20% 16V S AA AA
C 1824 VCFYAA2EA333K POL FILM C 33NF 10% 250V S AC AE
RESISTORS
R 1801 VRD-RA2BE221J RES 220 OHM 5% 1/8W S AA AA
R 1802 VRS-TV1JD391J 2125 390 OHM 5% 1/10W SMD S AA AA
R 1803 VRS-TV1JD750J 2125 75 OHM 5% 1/10W SMD S AA AA
R 1804 VRS-TV1JD101J 2125 100 OHM 5% 1/10W SMD S AA AA
R 1805 VRS-TV1JD102J 2125 1KOHM 5% 1/10W SMD S AA AA
R 1806 VRS-TV1JD181J 2125 180 OHM 5% 1/10W SMD S AA AA
R 1807 VRS-TV1JD391J 2125 390 OHM 5% 1/10W SMD S AA AA
R 1808 VRS-TV1JD750J 2125 75 OHM 5% 1/10W SMD S AA AA
R 1809 VRS-TV1JD101J 2125 100 OHM 5% 1/10W SMD S AA AA
R 1810 VRS-TV1JD102J 2125 1KOHM 5% 1/10W SMD S AA AA
R 1811 VRS-TV1JD181J 2125 180 OHM 5% 1/10W SMD S AA AA
R 1812 VRS-TV1JD391J 2125 390 OHM 5% 1/10W SMD S AA AA
R 1813 VRS-TV1JD750J 2125 75 OHM 5% 1/10W SMD S AA AA
R 1814 VRS-TV1JD101J 2125 100 OHM 5% 1/10W SMD S AA AA
R 1815 VRS-TV1JD102J 2125 1KOHM 5% 1/10W SMD S AA AA
R 1816 VRS-TV1JD181J 2125 180 OHM 5% 1/10W SMD S AA AA
R 1830 VRS-TV1JD472J 2125 4.7KOHM 5% 1/10W SMD S AA AA
R 1831 VRD-RA2HD101J RES 100 OHM 5% 1/2W S AA AA
R 1832 VRC-MA2HG681J SOLID R 680 OHM 5% 1/2W S AA AB
R 1833 VRD-RA2HD101J RES 100 OHM 5% 1/2W S AA AA
R 1834 VRC-MA2HG681J SOLID R 680 OHM 5% 1/2W S AA AB
R 1835 VRD-RA2HD101J RES 100 OHM 5% 1/2W S AA AA
R 1836 VRC-MA2HG681J SOLID R 680 OHM 5% 1/2W S AA AB
R 1837 VRS-TV1JD225J 2125 2,2MOHM 5% 1/10W SMD S AA AA
R 1839 VRS-TV1JD100J 2125 10 OHM 5% 1/10W SMD S AA AA
R 1841 VRS-TQ2BD220J OX RE 22 OHM 5% 1/8W SMD S AA AA
R 1843 VRS-TV1JD102J 2125 1KOHM 5% 1/10W SMD S AA AA
R 1844 VRS-TV1JD122J 2125 1,2KOHM 5% 1/10W SMD S AA AA
MISCELLANEOUS PARTS
QSOCV0103BMZZ SOCK HPS1521-014408 HOSHI S AD AG
(K) QPLGN0641CEZZ PLUG S AA AA
JF 0062 VRS-TV1JD102J 2125 1KOHM 5% 1/10W SMD S AA AA
VR 1801 RH-VX0037BMZZ VARISTOR 2322 593 02506 BC 25V S AA AC
PWB-C DIGITAL MODULE
INTEGRATED CIRCUITS
IC 6001 RH-IX1790BMZZ IC VPC3230D-BZ MICRONAS S AV BG
IC 6002 RH-IX1807BMZZ CI SAA4956TJ PHILIPS VIDEO MEMORY S AS BD
IC 6003 RH-IX1788BMZZ CI DDP3310B-E4 MICRONAS S AU BF
IC 6005 RH-IX1674BMZZ IC KA431AZ SAMSUNG S AA AD
IC 6006 RH-IX1556BMZZ IC BA10393 S0P8 SMD ROHM S AC AD
TRANSISTORS
Q 6003 RH-TX0108BMZZ TRT BC635 S AA AC
Q 6008 VS2SC2412KQ-1 TRT 2SC2412 ROHM S AA AA
Q 6021 VS2SC2412KQ-1 TRT 2SC2412 ROHM S AA AA
!
REF No. PARTS DESCRIPTION * SN CODE EX CODE
Q 6022 VS2SA1037KQ-1 TRT BC807 SMD S AA AA
Q 6023 VS2SC2412KQ-1 TRT 2SC2412 ROHM S AA AA
Q 6024 VS2SA1037KQ-1 TRT BC807 SMD S AA AA
Q 6027 VS2SC2412KQ-1 TRT 2SC2412 ROHM S AA AA
DIODES
D 6001 RH-EX0544BMZZ ZENER DIODE TZMC4V7 TFK SMD S AA AA
D 6002 RH-DX0551BMZZ DIODE LL4148 TFK SMD S AA AA
D 6003 RH-DX0551BMZZ DIODE LL4148 TFK SMD S AA AA
D 6004 RH-EX0544BMZZ ZENER DIODE TZMC4V7 TFK SMD S AA AA
D 6005 RH-DX0551BMZZ DIODE LL4148 TFK SMD S AA AA
D 6006 RH-EX0561BMZZ ZENER DIODE TZMC24 TFK SMD S AA AA
D 6007 RH-DX0551BMZZ DIODE LL4148 TFK SMD S AA AA
D 6008 RH-DX0551BMZZ DIODE LL4148 TFK SMD S AA AA
D 6010 RH-DX0551BMZZ DIODE LL4148 TFK SMD S AA AA
PACKAGED CIRCUITS
X 1003 RCRSB0236BMZZ CRYSTAL 5MHZ ACAL S AB AG
X 6001 RCRSB0219BMZZ CRYSTAL 20.25 HMZ S AG AH
COILS
L 6001 VP-NM3R3MR19N COIL 3,3UH SMD S AA AC
L 6002 VP-NM3R3MR19N COIL 3,3UH SMD S AA AC
L 6003 VP-NM3R3MR19N COIL 3,3UH SMD S AA AC
L 6004 VP-NM100KR42N COIL 10UH SMD S AA AC
L 6005 VP-NM1R0MR10N COIL 1UH SMD S AB AB
L 6006 VP-NM3R3MR19N COIL 3,3UH SMD S AA AC
L 6007 VP-NM3R3MR19N COIL 3,3UH SMD S AA AC
L 6008 VP-NM3R3MR19N COIL 3,3UH SMD S AA AC
L 6009 VP-NM3R3MR19N COIL 3,3UH SMD S AA AC
L 6010 VP-NM3R3MR19N COIL 3,3UH SMD S AA AC
L 6012 VP-NM3R3MR19N COIL 3,3UH SMD S AA AC
L 6013 VP-NM3R3MR19N COIL 3,3UH SMD S AA AC
L 6014 VP-NM3R3MR19N COIL 3,3UH SMD S AA AC
L 6015 VP-NM3R3MR19N COIL 3,3UH SMD S AA AC
L 6017 VP-NM3R3MR19N COIL 3,3UH SMD S AA AC
CAPACITORS
C 6001 VCKYTV1HF683Z CERAM C 68NF 50V 2125SMD S AA AA
C 6002 VCKYTV1HB152K CERAM C 1,5NF 50V 2125SMD S AA AA
C 6004 VCKYTV1HF683Z CERAM C 68NF 50V 2125SMD S AA AA
C 6005 VCKYTV1EF224Z CERAM C 220NF 25V 2125SMD S AA AA
C 6006 VCKYTV1HF473Z CERAM C 47NF 50V 2125SMD S AA AA
C 6007 VCKYTV1HB152K CERAM C 1,5NF 50V 2125SMD S AA AA
C 6008 VCKYTV1HF104Z CERAM C 100NF 50V 2125SMD S AA AA
C 6010 VCKYTV1HF683Z CERAM C 68NF 50V 2125SMD S AA AA
C 6011 VCKYTV1HF104Z CERAM C 100NF 50V 2125SMD S AA AA
C 6014 VCEAGA1HW335M ELEC C 3,3UF 20% 50V S AA AA
C 6015 VCKYTV1HF104Z CERAM C 100NF 50V 2125SMD S AA AA
C 6016 VCEAGA1HW226M ELEC C 22UF 20% 50V S AA AA
C 6017 VCKYTV1HF223Z CERAM C 22NF 50V 2125SMD S AA AA
C 6018 VCKYTV1HF153Z CERAM C 15NF 50V 2125SMD S AA AA
C 6019 VCKYTV1HF153Z CERAM C 15NF 50V 2125SMD S AA AA
C 6020 VCKYTV1HF153Z CERAM C 15NF 50V 2125SMD S AA AA
C 6021 VCEAGA1HW226M ELEC C 22UF 20% 50V S AA AA
C 6022 VCKYTV1HF223Z CERAM C 22NF 50V 2125SMD S AA AA
C 6023 VCEAGA1HW226M ELEC C 22UF 20% 50V S AA AA
C 6024 VCKYTV1HF104Z CERAM C 100NF 50V 2125SMD S AA AA
C 6025 VCCCTV1HH391J CERAM C 390PF 50V 2125SMD S AA AA
C 6026 VCKYTV1HB152K CERAM C 1,5NF 50V 2125SMD S AA AA
C 6027 VCEAGA1HW476M ELEC C 47UF 20% 50V S AA AA
C 6028 VCKYTV1HF473Z CERAM C 47NF 50V 2125SMD S AA AA
C 6029 VCKYTV1HF103Z CERAM C 10NF 50V 2125SMD S AA AA
C 6030 VCEAGA0JW477M ELEC C 470UF 20% 6,3V S AA AA
C 6031 VCCCTV1HH3R3C CERAM C 3,3PF 50V 2125SMD S AA AA
C 6032 VCCCTV1HH3R3C CERAM C 3,3PF 50V 2125SMD S AA AA
C 6033 VCKYTV1HF103Z CERAM C 10NF 50V 2125SMD S AA AA
C 6034 VCEAGA0JW477M ELEC C 470UF 20% 6,3V S AA AA
C 6035 VCEAGA1HW476M ELEC C 47UF 20% 50V S AA AA
C 6036 VCKYTV1HF473Z CERAM C 47NF 50V 2125SMD S AA AA
C 6037 VCKYTV1HF473Z CERAM C 47NF 50V 2125SMD S AA AA
C 6038 VCCCTV1HH391J CERAM C 390PF 50V 2125SMD S AA AA
C 6039 VCKYTV1EF334Z CERAM C 330NF 25V 2125SMD S AA AB
C 6040 VCKYTV1EF334Z CERAM C 330NF 25V 2125SMD S AA AB
