E-6
Placing the system
Notes:
● The front panel of the sound bar is not removable.
● The maximum transmission distance of the wireless sig-
nal between the subwoofer and sound bar is about 10
metres (32 feet), but may vary depending on your oper-
ating environment. If a steel-concrete or metallic wall is
between the subwoofer and the sound bar, the system
may not operate at all, because the wireless signal can-
not penetrate metal.
Caution:
● Do not change the installation direction when the sound
bar is turned on.
● Do not stand or sit on the sound bar and subwoofer as
you may be injured.
● Do not allow any objects to fall into or to be placed in the
bass reflex duct.
Installation image:
TV
Sound Bar
Digital Tuner BD player
Subwoofer
Place the system as shown.
■ Placing the subwoofer cushion
Stick the subwoofer cushion as shown.
1 When attaching the subwoofer cushion, place the sub-
woofer on a cushion or soft cloth to avoid damage.
Caution:
When using these subwoofer on glossy or slippery table
such as on glass top, stick foot cushions at the bottom of
the subwoofer to avoid slippage.
2 Stick into 4 corner of the subwoofer stand.
To Next Page
