INDOOR UNIT
70
Hold the bottom corners of the
open panel and gently pull out-
wards.
0
Operation Lamp (red)
@I
Timer Lamp (yellow)
@I
Remote Control
Reciever
Window
@
AUX. Button
OUTDOOR UNIT
@
Inlet (Air)
@
Indicator Panel
@
Hinged Front Panel
@
Operation Panel
@
Air Filters
@
Power Supply Cord
0
Vertical Adjustment Louvre
@
Horizontal Adjustment Louvres
@
Outlet (Air)
@
Remote Control
@
Inlet (Air)
@
Refrigerant Tubes and Intercon-
necting Cord
0
Drainage Hose
@
Outlet (Air)
NOTE:
Actual units might vary slightly from those shown above.
3
To Next Page
