2
AY-XP08/10/13CE
AE-X08/10BE-C
AE-X13BE
MODEL
I
NDOOR UNIT
OUTDOOR UNIT
INDOOR UNIT
OUTDOOR UNIT
INDOOR UNIT
OUTDOOR UNIT
ITEMS AY-XP08CE
AE-X08BE-C
AY-XP10CE
AE-X10BE-C
AY-XP13CE AE-X13BE
Cooling capacity
(Min. ~ Max.)
kW 2.2(0.9
_
2.7) 2.8(0.9
_
3.3) 3.6(0.9
_
4.2)
Heating capacity
(Min. ~ Max.)
kW 3.2(0.9
_
3.6) 3.7(0.9
_
5.0) 4.8(1.0
_
6.2)
Moisture removal(at cooling) Liters/h 0.7 0.8 1.3
Electrical data
Phase Single
Rated frequency Hz 50
Rated voltage V 220 - 240
Cool A 3.4
_
3.1 4.3
_
4.0 5.5
_
5.1
Rated current Heat A 4.2
_
3.9 4.8
_
4.4 6.8
_
6.2
Cool W 730 930 1200
Rated input Heat W 910 1050 1480
Cool % 98
_
98 98
_
97 99
_
98
Power factor Heat % 98
_
97 99
_
99 99
_
99
Type Hermetically sealed rotary type
Compressor Model 44A072QV2JD HV187X1-S12F3 HV237A1-S15DK
Oil charge 280cc (SUNISO 4GST) 370cc (SUNISO 4GSD) 455cc (SUNISO 4GSD)
Evaporator Louver Fin and Grooved tube type
Refrigerant system Condenser Corrugate Fin and Grooved tube type
Control Capillary tube
Refrigerant volume
760g 850g 880g
De-lce system Micro computer controled reversed systems
Noise level
High dB(A) 33 43 36 43 38 48
(at cooling)
Med. dB(A) 29 – 32 – 33 –
Low dB(A) 27 – 27 – 29 –
Fan system
Drive Direct drive
Air flow quantity High m
3
/min. 7.5 28 9.8 27.7 9.4 30
(at cooling) Med. m
3
/min. 6.5 – 8.0 – 8.0 –
Low m
3
/min. 5.1 – 6.0 – 6.5 –
Fan
Cross flow fan Propeller fan Cross flow fan Propeller fan Cross flow fan Propeller fan
Connections
Refrigerant coupling Flare type
Refrigerant tube size Gas, Liquid 3/8", 1/4" 1/2", 1/4"
Drain piping mm O.D ø 18
Others
Compressor: Thermal protector
Safety device Fan motors: Thermal fuse
Fuse, Micro computer control
Air filters Polypropylene net (Washable)
Width mm 815 780 815 780 815 780
Net dimensions Height mm 278 540 278 540 278 540
Depth mm 198 269 198 269 198 269
Net weight kg 9 36 10 36 10 39
Note: The condition of star "
" marked item are ‘ISO5151’ : 1994(E), condition T1.
SPECIFICATIONS
