AY-XP08/10/13CE
AE-X08/10BE-C
AE-X13BE
REF. NO. PART NO. DESCRIPTION Q'TY CODE
REPLACEMENT PARTS LIST [AY-XP08CE/XP10CE/XP13CE]
CABINET AND UNIT PARTS
1- 1 CMOT-A397JBKZ Fan motor sub ass’y 1 BG
1- 2 PGUMSA046JBE0 Damper rubber 1 AD
1- 3 CHLD-A067JBK0 Bearing ass’y 1 AL
1- 4 DCHS-A399JBKZ Cabinet sub ass’y [AY-XP08CE] 1 BD
1- 4 DCHS-A401JBKZ Cabinet sub ass’y [AY-XP10CE/XP13CE] 1 BC
1- 5 NFANCA089JBEZ Cross flow fan 1 BD
1- 6 DSRA-A246JBKZ Drain pan sub ass’y 1 BE
1- 7 CMOTLA915JBEZ Fan motor 1 BK
1- 8 MJNTPA082JBFA Louver link 2 AC
1- 9 MLOV-A299JBFA Vertical louver 12 AC
1-10 MLOV-A334JBRA Horizontal louver A 1 AM
1-11 MLOV-A298JBFA Horizontal louver B 1 AK
1-12 QW-VZE022JBZZ Lead wire (for Fan motor) 1 AM
1-13 LHLD-A197JBFP Louver holder 2 AX
1-14 NBRG-A026JBFA Louver bushing 2 AB
1-15 LHLD-A561JBFA Holder 1 AM
1-16 PHOS-A025JBE0 Drain hose 1 AL
1-17 PPACGA010JBE0 O ring 1 AB
1-18 PGID-A097JBFZ Drain cover 2 AF
1-19 RMOT-A061JBE0 Louver motor 2 AS
1-20 PGUMMA110JBE0 Drain plug 1 AD
1-21 CWAK-C213JBKZ Front panel ass’y 1 BE
1-22 PPLT-A212JBFZ Side cover R 1 AL
1-23 PPLT-A213JBFZ Side cover L 1 AL
1-24 PCOV-A764JBRA Display cover 1 BB
1-25 PFILMA145JBEA Air filter 2 AL
1-26 DHLD-A010JBKZ Tube holder ass’y 1 AK
1-27 HPNL-A514JBTA Open panel 1 AQ
1-28 TSPC-E067JBRA Name label [AY-XP08CE] 1 AC
1-28 TSPC-E066JBRA Name label [AY-XP10CE] 1 AC
1-28 TSPC-E065JBRA Name label [AY-XP13CE] 1 AC
1-29 PFPFPB901JBEZ Cabinet insulator [AY-XP08CE] 1 AH
1-30 QW-VZE013JBZZ Lead wire (for Louver motor:Upper) 1 AG
1-31 GWAK-A271JBFA Front panel 1 AV
1-32 PCOV-A614JBFZ Drain cover 1 AG
1-33 TLABCB584JBRZ Wiring diagram 1 AC
1-34 QW-VZD893JBZZ Lead wire (for Louver motor:Lower) 1 AG
1-35 LHLD-A303JBFA Tube cover 1 AD
1-36 PSEL-C125JBEZ Panel insulator 1 AF
1-37 PFPFPB971JBEZ Sheet 1 AA
1-38 PSPA-A154JBEZ Rubber spacer 1 AD
1-39 PSHE-A126JBE0 Evaporator seal 1 AG
1-40 LSPR-A007JBE0 Sheet spring 2 AD
1-41 LHLD-A536JBFA Holder 1 AM
1-42 PFPFPB962JBEZ Sidecover insulator 1 AC
1-43 PFPFPB967JBEZ Insulator 1 AC
1-44 HDEC-B147JBEA Display panel 1 AQ
1-45 PSEL-C055JBEZ Evaporator seal 1 AC
1-46 PSEL-C136JBEZ Insulator [AY-XP10CE/XP13CE] 1 AC
1-47 PSEL-C294JBEZ Aluminum tape 1 AC
1-48 TLAB-C211JBRZ Filter label 1 AE
1-49 DCOV-A206JBKZ Cover ass’y 1 AE
1-50 PCOV-A821JBEZ Lead cover A 1 AC
1-51 PCOV-A822JBEZ Lead cover B 1 AC
CONTROL BOX
2- 1 RTHM-A300JBE0 Thermistor 1 AP
2- 2 PBOX-A342JBFZ Control box 1 AQ
2- 3 PBOX-A341JBFZ Terminal cover 1 AH
2- 4 VSKRA105M//-3 Transistor (Q1, Q2,Q10) 3 AB
2- 5 VS2SA1585SQR3 Transistor (Q8) 1 AD
2- 6 HPNLCA776JBFA Control box cover 1 AG
2- 7 HPNLCA777JBEA Control panel 1 AD
2- 8 PCOV-A618JBFB Led holder 1 AE
2- 9 PCOV-A766JBFA Led holder B 1 AE
2-10 DPWBFA265JBKZ Control board unit [AY-XP08CE] 1 BS
2-10 DPWBFA266JBKZ Control board unit [AY-XP10CE] 1 BS
2-10 DPWBFA264JBKZ Control board unit [AY-XP13CE] 1 BS
2-11 QACC-A158JBE0 Power supply cord 2 AT
2-12 QTANZA002JBEZ Terminal board (3PIN) 1 AN
2-13 QTANZA001JBZZ Terminal board (4PIN) 1 AQ
2-14 PCOV-A609JBWZ Control box cover 1 AC
2-15 RIC—-A025BDE0 IC (IC4, IC5) 2 AE
To Next Page
