Page #2 background imageLoading...
Page #2 background image
2
AF-05CML
SPECIFICATIONS
Models AF-05CML
Cooling capacity BTU/h 5000
Moisture removal Pints/h 1.0
ELECTRICAL DATA
Phase Single
Rared frequency Hz 60
Rated voltage Volts 115
Rated current Amps 4.6
Rated input Watts 500
Power factor % 95
EER BTU/Wh 10.0
COMPRESSOR
Type (Hermetically sealed rotary type)
Model, Motor output
RM5455GQ86, 400W
REFRIGERANT SYSTEM
Evaporator Louver fin, Grooved tube, 7mm, Hair pin
Condenser Louver fin, Grooved tube, 7mm, Hair pin
Control O.D. x I.D. x Length x Q'ty(mm) 2.7 x 1.1 x 400 x 1
(Capillary tube)
Refrigerant volume R-22(OZ) 8.5
(Factory change)
NET DIMENSIONS
Width Height Depth
inches(mm)
17-23/32(450) x 14-9/16(370) x 14-7/8(378)
Net Weight lbs 47
GROSS DIMENSIONS
Width Height Depth
inches(mm)
20-7/8(530) x 18-1/8(460) x 18-3/8(467)
Gross Weight lbs 52
FAN SYSTEM
Indoor side(Evaporator) Centrifugal fan
Outdoor side(Condenser) Propeller fan
Air flow rate(indoor side) CFM High / Med / Low
195 / 175 / 150
OTHERS
Safety devices Compressor: Overload relay
Fan motor: Internal thermal protector
Air filter Polypropylene net
Power cord length ft 6.0
Power plug type 125V, 10A
ELECTRICAL PARTS
Running capacitor 250V-40µF
Fan capacitor 250V-6µF
Selector switch 2109
Thermistor No. APPLI- COLD COLD WARM WARM
. CAUTION CUT-IN CUT-OUT CUT-IN CUT-OUT
MM1-A001 Cooling 66.2˚F 61.7˚F 86.0˚F 82.5˚F
Fan motor OBM-2016K1 (MLA998)
Overload relay MRA99484
