Sharp AF-05CML User Manual

3
AF-05CML
WIRING DIAGRAM
Figure W-1
EXTERNAL DIMENSIONS
POWER SUPPLY CORD
115V 60Hz
THERMOSTAT
OFF
FAN
LOW-COOL
MED-COOL
HIGH-COOL
642
214563
8
1
SELECTOR SWITCH
S
C
WH
WH
OR
RE
WH
OR
RE
R
RE
BK
BK
BK
BL
BL
BK
BK
BK
OVERLOAD
RELAY
A.C
M.C
COMPRESSOR
MOTOR
FAN MOTOR
CAPACITOR
250V 6µF
FAN MOTOR
RUNNING
CAPACITOR
250V 40µF
BK
BL
RE
WH
OR
GR
G
:
BLACK
:
BLUE
:
RED
:
WHITE
:ORANGE
:
GRAY
: GREEN
BL
THERMAL
PROTECTOR
EARTH
G
EARTH
NON RIBBED
RIBBED
GR
GR
GR
G
CONNECTOR
H
M
L
14-7/8"
4-1/8"
13-5/8"
17-23/32"
33-7/16" (full opened)
21-21/32" (full closed)
15-11/16"
1-15/32"
