Sharp AF-05CML User Manual

21
AF-05CML
REF. NO. PART NO. DESCRIPTION Q'TY CODE
ACCESSORY PARTS
4- 1 TINSEA299JBRZ Operation manual 1 AE
4- 2 LANGAA011JBFE Left closure frame 1 AH
4- 3 LANGAA012JBFE Right closure frame 1 AH
4- 4 PPLTPA016JBFB Closure 2 AK
4- 5 PSEL-A931JBE0 Window insulator 1 AH
4- 6 PSEL-A932JBE0 Window insulator 1 AE
4- 7 PSEL-C251JBEZ Window insulator 1 AC
4- 8 DX-BZA016JBK0 Screws kit 1 AW
4- 9 SSAKAA018YDE0 Bag 1AB
4-10 XCTSD40P10000 Tapping screw 6 AA
4-11 XMPSD40P25000 Wood screw 7 AA
4-12 LANGAA030JBTA Base pan angle 2 AD
4-13 SPADBA163JBEZ Card board 1 AC
4-14 SSAKHA009JBEZ Bag 1AC
4-15 CFZK-B935JBKZ Closure ass’y 1 AX
PACKING PARTS
5- 1 DPADBA004JBFZ Top pad ass’y 1 AH
5- 2 CPADBA046JBKZ Bottom pad ass’y 1 AN
5- 3 SPAKCB001JBEZ Packing case 1 AP
5- 4 SSAKHA245YDE0 Protect 1 AB
5- 5 SSAKAA053YDE0 Bag 1AB
SCREWS AND NUTS
6- 1 XTTSD40P20000 Tapping screw 4 AA
6- 2 XCTWJ40P16000 Tapping screw 2 AA
6- 3 XTTSD40P14000 Tapping screw 7 AA
6- 4 XTTSD40P12000 Tapping screw 13 AA
6- 5 XHTSD40P10000 Tap tight screw 6 AA
6- 6 XHTSD40P08000 Tap tight screw 5 AA
6- 7 XBPSD40P06J00 Machine screw 3 AB
6- 8 LX-BZA236JBE0 Special screw 1 AC
6- 9 LX-CZA038WRE0 Special screw 4 AA
6-10 LX-HZA001JBE0 Special screw 1 AB
6-11 LX-BZA140JBE0 Special screw 2 AB
6-12 LX-NZA074JBE0 Special nut 1 AB
6-13 LX-NZA103JBE0 Frange nut 1 AF
6-14 LX-NZA026JBE0 Special nut 3 AC
HOW TO ORDER REPLACEMENT PARTS
To have your order filled prompty and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO. 3. PART NO. 4. DESCRIPTION
