Sharp AF-R100CX - Replacement Parts List

28
AF-R100CX
AF-R120CX
REPLACEMENT PARTS LIST
CABINET AND UNIT PARTS
1- 1 CMOTLA895JBEZ Fan motor 1 BN
1- 2 DCHS-A442JBTA Base pan ass’y [AF-R100CX] 1 BC
1- 2 DCHS-A440JBTA Base pan ass’y [AF-R120CX] 1 BC
1- 3 DCAB-A094JBTA Cabinet ass’y 1 BF
1- 4 PSEL-B150JBE0 Cabinet seal 2 AD
1- 5 HPNLCA770JBFA Control panel 1 AF
1- 6 PSEL-C059JBEZ Evaporator insulator 1 AD
1- 7 LANG-A459JBWZ Conecting stay 1 AC
1- 8 LANG-A355JBTA Top inst. Angle 1 AP
1- 9 LHLD-A482JBFZ Thermistor holder 1 AE
1-10 CLEV-A035JBKZ Damper ass’y 1 AE
1-11 NFANPA092JBFZ Propeller fan 1 AV
1-12 NFANSA030JBFZ Centrifugal fan 1 AU
1-13 PFILMA116JBEB Air filter 1 AN
1-14 PFPFPB466JBE0 Insulator 2 AC
1-15 PKESPA082JBTA Condenser shroud 1 AV
1-16 PKESPA083JBFA Orifice 1AQ
1-17 LBND-A046JBE0 Wire fixing band 1 AE
1-18 LCOV-A002JBF0 Shroud cover 1 AM
1-19 PCOV-A320JBP0 Motor cover 1 AC
1-20 PSEL-C057JBEZ Tube insulator 1 AD
1-21 LANG-A356JBTA Bottom inst. Angle 1 AE
1-22 PSKR-A207JBFA Bulkhead 1 BA
1-23 PSRA-A120JBFZ Drain tray 1 AE
1-24 TLAB-C206JBRZ Energy card [AF-R100CX] 1 AC
1-24 TLAB-C205JBRZ Energy card [AF-R120CX] 1 AC
1-25 TSPC-E052JBRZ Name badge [AF-R100CX] 1 AC
1-25 TSPC-E051JBRZ Name badge [AF-R120CX] 1 AC
1-26 GWAKPA136JBFB Louver duct 1 AH
1-27 GWAKPA135JBFB Front panel 1 AT
1-28 TLABBA110JBRA SHARP badge 1 AB
1-29 LANGAA038JBFB Left closure frame 1 AK
1-30 LANGAA039JBFB Right closure frame 1 AK
1-31 PPLTPA013JBFB Closure 2AL
1-32 PSPRCA010JBE0 Spring 1AD
1-33 TLABKA564JBE0 Number card 1 AC
1-34 PFPFPB446JBE0 Insulator 1 AC
1-35 CWAK-C095JBKZ Front panel ass’y 1 AX
1-36 MJNTPA074JBFB Louver link 2 AC
1-37 MLOV-A252JBFB Vertical louver A 4 AB
1-38 MLOV-A253JBFB Vertical louver B 2 AC
1-39 PSEL-B360JBE0 Cabinet insulator 1 AB
1-40 PSEL-C064JBEZ Drain tray insulator 1 AC
1-41 PSEL-B361JBE0 Cabinet insulator 2 AE
1-42 PSEL-B367JBE0 Cabinet insulator 2 AC
1-43 PSEL-B516JBE0 Base pan insulator 2 AC
1-44 PFPFPB443JBE0 Insulator 1 AC
1-45 PSEL-C063JBEZ Bulkhead insulator 1 AC
1-46 PSEL-B519JBE0 Angle insulator 1 AD
1-47 PSEL-C056JBEZ Motor seal 1 AE
1-48 LHLDW0367JBE0 Wire holder 1 AA
1-49 LHLDW0368JBE0 Wire holder 1 AA
1-50 PFPFPB528JBE0 Panel insulator 1 AD
1-51 PSEL-A432JBE0 Damper insulator 1 AC
1-52 PFPFPB611JBE0 Insulator 1 AG
1-53 PSEL-B532JBE0 Damper insulator 1 AB
1-54 PSEL-B394JBE0 Panel insulator 1 AB
1-55 PSEL-B560JBE0 Damper insulator 1 AB
1-56 LANG-A507JBWZ Fan motor angle 1 AH
1-57 HPNLCA771JBEA Decoration panel 1 AM
1-58 PSEL-B366JBE0 Panel insulator 1 AD
1-59 PSEL-C104JBEZ Insulator 1 AB
1-60 PSEL-C105JBEZ Cabinet insulator 1 AE
1-61 LHLDW0363JBE0 Wire holder 1 AA
1-62 PSHE-A191JBEZ Sheet 1AE
1-63 LHLD-A356JBE0 Wire holder [AF-R120CX] 1 AE
REF. NO. PART NO. DESCRIPTION Q'TY CODE
