Sharp AF-R100CX - Cycle Parts; Accessory Parts

29
AF-R100CX
AF-R120CX
REF. NO. PART NO. DESCRIPTION Q'TY CODE
CONTROL BOX PARTS
2- 1 LBNDKA078JBWZ Capacitor clamp [AF-R100CX] 1 AD
2- 1 LBNDKA096JBWZ Capacitor clamp [AF-R120CX] 1 AC
2- 2 LPLTMA128JBW0 Control box cover 1 AK
2- 3 DPLT-A047JBW0 Cont. box angle ass’y 1 AS
2- 4 QACC-A263JBZZ Power supply cord 1 AT
2- 5 RH-HXA011JBZZ Thermistor 1 AL
2- 6 QW-VZD104JBE0 Lead wire 1 AD
2- 7 QW-IZA037JBZZ Lead wire [AF-R100CX] 1 AS
2- 7 QW-IZA036JBZZ Lead wire [AF-R120CX] 1 AS
2- 8 RC-HZA256JBE0 Fan motor capacitor 2 AM
2- 9 RC-HZA435JBZZ Running capacitor [AF-R100CX] 1 AY
2- 9 RC-HZA407JBZZ Running capacitor [AF-R120CX] 1 AY
2-10 TLABCB579JBRZ Wiring diagram [AF-R100CX] 1 AA
2-10 TLABCB377JBRZ Wiring diagram [AF-R120CX] 1 AC
2-11 DPWBFA193JBKZ Control board unit 1 BC
2-12 PSPA-A084JBE0 Spacer 2AC
2-13 PSPA-A085JBE0 Spacer 1AC
2-14 QFS-AA048JBE0 Fuse 1AB
2-15 LBND-A042JBE0 Wire fixing band 4 AC
CYCLE PARTS
3- 1 PCMPRA360JBEZ Compressor [AF-R100CX] 1 CB
3- 1 PCMPRA359JBEZ Compressor [AF-R120CX] 1 CC
3- 2 PPIPCF657JB1Z Discharge tube [AF-R100CX] 1 AP
3- 2 PPIPCF655JB1Z Discharge tube [AF-R120CX] 1 AR
3- 3 PPIPCF656JB1Z Suction tube [AF-R100CX] 1 AP
3- 3 PPIPCF654JB1Z Suction tube [AF-R120CX] 1 AS
3- 4 RHOG-A199JBZZ Overload relay [AF-R100CX] 1 AU
3- 4 RHOG-A198JBZZ Overload relay [AF-R120CX] 1 AT
3- 5 DCON-A166JBKZ Condenser ass’y [AF-R100CX] 1 BT
3- 5 DCON-A167JBKZ Condenser ass’y [AF-R120CX] 1 BT
3- 6 PEVA-A429JBEZ Evaporator [AF-R100CX] 1 BP
3- 6 PEVA-A424JBEZ Evaporator [AF-R120CX] 1 BQ
3- 7 GLEG-A103JBE0 Compressor cushion [AF-R100CX] 3 AG
3- 7 GLEG-A105JBE0 Compressor cushion [AF-R120CX] 3 AF
3- 8 PSEL-B161JBE0 Gasket washer [AF-R100CX] 1 AH
3- 9 PCOV-A371JBE0 Terminal cover [AF-R100CX] 1 AF
3- 9 PCOV-A321JBE0 Terminal cover [AF-R120CX] 1 AR
3-10 PSEL-B160JBE0 Terminal gasket [AF-R100CX] 1 AH
3-10 PSEL-A971JBE0 Terminal gasket [AF-R120CX] 1 AN
3-11 DCPY-A235JBKZ Capillary tube ass’y [AF-R100CX] 1 AT
3-11 DCPY-A234JBKZ Capillary tube ass’y [AF-R120CX) 1 AW
3-12 MSPR-A129JBE0 Cycle spring 1 AD
3-13 PGUM-0034JBE0 Damper rubber 1 AF
3-14 MSPR-A114JBE0 Protector spring [AF-R100CX] 1 AF
3-14 MSPR-A136JBE0 Protector spring [AF-R120CX] 1 AF
3-15 LPLTMA114JBW0 Condenser stay 2 AH
ACCESSORY PARTS
4- 1 TINSEA320JBRZ Operation manual 1 AD
4- 2 PSEL-A349JBE0 Window insulator 1 AE
4- 3 PSEL-A350JBE0 Window insulator 1 AD
4- 4 PSEL-B365JBE0 Window insulator 1 AD
4- 5 TCAD-A351JBEZ Consummer card 1 AB
4- 6 DX-BZA027JBK0 Screws kit 1 AE
4- 7 CRMC-A526JBEZ Remote control 1 AT
4- 8 LHLD-A389JBFB Controller holder 1 AE
4- 9 SSAKAA017YDE0 Bag 1AC
4-10 UBATUA027JBE0 Battery pack 1 AE
PACKING PARTS
5- 1 CPADBA688YDK0 Top pad ass’y 1 AL
5- 2 CPADBA009JBK0 Bottom pad ass’y 1 AT
5- 3 SPAKCA986JBEZ Packing case [AF-R100CX] 1 AX
5- 3 SPAKCA985JBEZ Packing case [AF-R120CX] 1 AX
5- 4 SSAKHA314YDE0 Protect 1AD
5- 5 PPAK-A007JBE0 Inner packing 1 AG
5- 6 TLABMA309JBRZ Feature card 1 AB
5- 7 SSAKAA053YDE0 Bag 1AB
