2
AF-T908X
AF-R908X
AF-R1108X
AF-R1208X
SPECIFICATIONS
Models AF-T908X, AF-R908X AF-R1108X AF-R1208X
Cooling capacity BTU/h 8500 10500 12000
Moisture removal Pints/h 2.1 3.0 3.8
ELECTRICAL DATA
Phase Single
Rated frequency Hz 60
Rated voltage Volts 115
Rated current Amps 8.0 10.2 11.9
Rated input Watts 850 1100 1300
Power factor % 92 94 95
EER BTU/Wh 10.0 9.5 9.2
COMPRESSOR
Type (Hermetically sealed rotary type)
Model, Remarks QB125CL22
A, 700W QK164CN22A, 890W QK189CN22A, 1050W
REFRIGERANT SYSTEM
Evaporator Louver fin, Grooved tube, 7mm, Hair pin
Condenser
Louver fin, Bare tube, 7mm Hair pin Louver fin, Grooved tube, 7mm Hair pin
Control O.D. x I.D. x Length x Q'ty(mm)
Capillary tube 2.7 x 1.4 x 650 x 1 Capillary tube 2.7 x 1.6 x 800 x 1 Capillary tube 2.7 x 1.2 x 650 x 2
Refrigerant volume R-22(OZ) 15.2(Factory charged) 14.6(Factory charged) 18.5(Factory charged)
NET DIMENSIONS
Width Height Depth
inches(mm)
22-1/16(560) x 14-3/4(375) x 24-5/16(617)
Net Weight lbs 84 84 88
GROSS DIMENSIONS
Width Height Depth
inches(mm)
22-25/32(655) x 18-29/32(480) x 27-7/8(708)
Gross Weight lbs 95 95 99
FAN SYSTEM
Indoor side(Evaporator) Centrifugal fan
Outdoor side(Condenser) Propeller fan
Air flow rate(indoor side) CFM
(High/Med/Low) 275 / 223 / 198 (High/Med/Low) 293 / 265 / 237
(High/Med/Low) 286 / 258 / 230
OTHERS
Safety devices Compressor: Overload relay
Fan motor: Internal thermal fuse
Air filter Polypropylene net
Power cord length ft 4.3
Power plug type 125V, 15A
