Sharp AF-T908X

4
AF-T908X
AF-R908X
AF-R1108X
AF-R1208X
EXTERNAL DIMENSIONS
24-5/16"
5-3/16"
14-3/4"
19/32"
1-3/8"
16-23/32"
22-1/16"
38-19/32"
27-5/32"
OPERATION INSTRUCTIONS
PARTS NAMES
UNIT
1
Front panel
2 Air inlet (Indoor side)
3 Louvers
4 Air outlet (Indoor side)
5 Exhaust lever
6 Control panel
7 Cabinet
8 Air outlet (Outdoor side)
9 Air inlet (Outdoor side)
0 Filter (Pull the filter handle to the right to remove.)
q Filter handle
w Power cord
8
12
1
2
3
4
5
6
7
9
10
11
