PART NAMES
1 Inlet (Air)
2 Open Panel
3 AUX. Button
4 Air Filters
5 Receiver Window
6 Louvre Unit
Open to clean the inside of the
air conditioner.
7 Power Supply Cord
8 Indicator Panel
9 Vertical Adjustment Louvres
0 Horizontal Adjustment Louvres
q Outlet (Air)
w Remote Control
e TURBO COOLING Lamp (green
)
r TIMER Lamp (orange )
t OPERATION Lamp (red )
y PLASMACLUSTER Lamp (blue)
OUTDOOR UNIT
NOTE: Actual units might vary slightly from those shown above.
INDOOR UNIT
1
2
3
4
5
6
7
8
9
0
q
w
u Inlet(Air)
i Refrigerant Tube and Inter-
connecting Cord
o Drainage Hose
p Outlet(Air)
6
e
r
t
y
u
i
o
p
