Sharp AH-AP9MMV - Part Names

EN-2
1 Inlet (Air)
2 Open Panel
3 Air Filter
4 AUX Button
5 Receiver Window
6 Power Supply Cord
7 Vertical Airfl ow Louvre
8 Horizontal Airfl ow Louvre
9 Outlet (Air)
10 PLASMACLUSTER Lamp
(blue
)
11 OPERATION Lamp (red
)
12 TIMER Lamp (orange
)
13 POWERFUL JET Lamp
(green
)
14 Inlet (Air)
15 Refrigerant Pipe and In
terconnecting Cord
16 Drainage Hose
17 Outlet (Air)
NOTE:
Actual units might vary slightly
from those shown above.
1
2
3
4
5
6
7
8
9
10
11
12
13
PART NAMES
INDOOR UNIT
14
15
16
17
OUTDOOR UNIT
14
15
16
17
AU-A9MMV
AU-A12MMV
