CHAPTER 2. ELECTRIC CIRCUIT
[ 1] ELECTRIC PARTS
1. AH-G13 / AU-G13
DESCRIPTION
MODEL
REMARKS
SITE
Compressor QJ208PHA
220 - 240V , 50Hz, 1000W
OUTDOOR
Indoor fan motor CMOT-A448JBKZ 220 - 240V , 50Hz INDOOR
Outdoor fan motor
CMOTLB182JBEZ 220 - 240V , 50/60Hz
OUTDOOR
Indoor fan motor capacitor
— 450V, 2
µF INDOOR
Outdoor fan motor capacitor
— 400V, 2
µF
OUTDOOR
Running capacitor
— 400V, 35µF
OUTDOOR
Transformer — Primary ; AC 220 / 240V 50Hz
Secondary ; AC15.3V , 50Hz
INDOOR
—
Fuse — 250V, 2.5A INDOOR
2. AH-PG15 / AU-PG15
5
DESCRIPTION
MODEL
REMARKS
SITE
Compressor
QJ208PHA 220 - 240V , 50Hz, 1000W OUTDOOR
Indoor fan motor CMOT-A448JBKZ 220 - 240V , 50Hz INDOOR
Outdoor fan motor
CMOTLB182JBEZ 220 - 240V , 50/60Hz
OUTDOOR
Indoor fan motor capacitor
— 450V, 2
µF INDOOR
Outdoor fan motor capacitor
— 400V, 2
µF
OUTDOOR
Running capacitor
— 400V, 35µF
OUTDOOR
Transformer — Primary ; AC 220 / 240V 50Hz
Secondary ; AC15.3V , 50Hz
INDOOR
—
Fuse
— 250V, 2.5A INDOOR
