26
AH-N45DP2
AU-N45DP2
AH-N56DP2
AU-N56DP2
The Electric Control box.
1. Remove the screw fixing the Receiving filter.
2. Remove the 2 Switch and Photo detector unit.
3. Remove a screw fixing the Cord holder.
4. Remove a screw fixing the Cord holder and 2
screws fixing the Terminal board.
5. Remove 2 screws fixing the Transformer and pull
the Control board unit.
The DRAIN PAN and related
To Next Page
