REF. NO. PART NO. DESCRIPTION Q'TY CODE
CABINET AND UNIT PARTS
1- 1 LSUB-A024JBPZ Motor angle sub 2 AP
1- 2 CMOTLB027JBEZ Fan motor [AU-N45DP2] 1 BU
1- 2 CMOTLB028JBEZ Fan motor [AU-N56DP2] 1 BS
1- 3 NFANPA108JBFA Propeller fan 1 BA
1- 4 LANGKA145JBPZ Motor angle 1 AV
1- 5 PSKR-A242JBWZ Bulkhead 1 AT
1- 6 GPLTMA060JBTA Right side cover 1 AS
1- 7 CFTA-B310JBKZ Control cover assembly [AU-N45DP2] 1 BA
1- 7 CFTA-A311JBKZ Control cover assembly [AU-N56DP2] 1 AW
1- 8 GCAB-A221JBTA Rear cabinet 1 BE
1- 9 GCAB-A189JBTA Cabinet 1 BG
1-10 GGADFA028JBTA Fan guard 1 AZ
1-11 PSEL-C280JBEZ Bulkhead insulator C 1 AE
1-12 PSPF-A827JBEZ Compressor cover 1 AS
1-13 PSEL-C017JBEZ Cabinet seal 1 AC
1-14 TSPC-E398JBRZ Name label [AU-N45DP2] 1 AE
1-14 TSPC-E399JBRZ Name label [AU-N56DP2] 1 AE
1-15 TLABBA100JBRA SHARP badge 1 AE
1-16 CCHS-A777JBTZ Base pan assembly 1 BE
1-18 PSEL-C264JBEZ Bulkhead insulator B 1 AD
1-19 LBSHCA022JBF0 Bushing 1 AE
1-20 PFPFPC111JBEZ Corner insulator 1 AC
1-21 PSEL-B643JBE0 Insulator No.9 1 AC
1-22 PSEL-C275JBEZ Insulator 1 AD
1-23 PSEL-C278JBEZ Insulator 1 AC
1-24 PSEL-C282JBEZ Cushion 1 AD
1-25 PSEL-C370JBEZ Insulator 1 AC
1-26 PSEL-C378JBEZ Insulator 1 AB
1-27 PSEL-C379JBEZ Insulator 1 AB
1-28 PSEL-C380JBEZ Insulator 1 AC
1-29 PSEL-A191JBE0 Condenser seal 1 AA
1-30 PFTA-A095JBFA Side cover 1 AN
CONTROL BOX PARTS
2- 1 RRLYJA088JBZZ Relay [AU-N56DP2] 1 BA
2- 2 LHLD-A544JBFA Cord clamp holder 1 AG
2- 3 QW-IZA031JBZZ Compressor cord 1 AT
2- 4 RC-HZA472JBZZ Running capacitor 1 AX
2- 5 RC-HZA404JBZZ Fan motor capacitor 1 AU
2- 6 QTANZA002JBZZ Terminal board [AU-N45DP2] 1 AN
2- 6 QTANZA001JBZZ Terminal board [AU-N56DP2] 1 AQ
2- 7 LHLD-A539JBFA Cord clamp 1 AE
2- 8 PBOX-A379JBWZ Control box 1 AR
2- 9 LBNDKA047JBW0 Capacitor clamp 1 AH
2-10 TLABCB806JBRZ Wiring diagram [AU-N45DP2] 1 AE
2-10 TLABCB807JBRZ Wiring diagram [AU-N56DP2] 1 AE
CYCLE PARTS
3- 1 PCMPRA294JBE0 Compressor [AU-N45DP2] 1 CP
3- 1 PCMPRA392JBEZ Compressor [AU-N56DP2] 1 CH
3- 2 PCON-A511JBPZ Condenser 1 CB
3- 3 DVLV-A606JBKZ 2 Way valve assembly 1 AR
3- 4 LX-NZA250JBEZ Flare nut 1 AE
3- 5 MSPRPA018JBE0 Terminal cover holder 1 AK
3- 6 PCAP-A075JBFZ Bonnet 1 AC
3- 7 DVLV-A607JBKZ 3 Way valve assembly [AU-N45DP2] 1 AX
3- 7 DVLV-A608JBKZ 3 Way valve assembly [AU-N56DP2] 1 AZ
3- 8 LX-NZA280JBEZ Flare nut [AU-N45DP2] 1 AG
3- 8 LX-NZA286JBEZ Flare nut [AU-N56DP2] 1 AH
3- 9 CPIPCA817JBKZ Discharge tube ass’y [AU-N45DP2] 1 AT
3- 9 CPIPCA818JBKZ Discharge tube ass’y [AU-N56DP2] 1 AY
3-10 PCAP-A089JBEZ Bonnet [AU-N45DP2] 1 AX
3-10 PCAP-A090JBEZ Bonnet [AU-N56DP2] 1 AE
3-11 CCPY-A161JBKZ Capillary tube assembly [AU-N45DP2] 1 AR
3-11 CCPY-A139JBKZ Capillary tube assembly [AU-N56DP2] 1 BF
3-12 PCOV-A379JBE0 Terminal cover 1 AF
3-13 CPIPCA794JBKZ Suction tube ass’y [AU-N45DP2] 1 AX
3-13 CPIP-A054JBKZ Suction tube ass’y [AU-N56DP2] 1 AZ
3-14 GLEG-A094JBE0 Compressor cushion rubber 4 AG
3-15 PSEL-B173JBE0 Terminal gasket 1 AE
3-13 CPIPCA794JBKZ Suction tube ass’y [AU-N45DP2] 1 AX
3-13 CPIP-A054JBKZ Suction tube ass’y [AU-N56DP2] 1 AZ
REPLACEMENT PARTS LIST [AU-N45DP2 / AU-N56DP2]
