35
AH-N45DP2
AU-N45DP2
AH-N56DP2
AU-N56DP2
REF. NO. PART NO. DESCRIPTION Q'TY CODE
HOW TO ORDER REPLACEMENT PARTS
To have your order filled prompty and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
SCREWS, NUT AND BOLT
6- 1 LX-BZA072JBE0 Special screw 4 AB
6- 2 LX-NZ0128JBE0 Special nut 1 AB
6- 3 LX-BZA140JBE0 Special screw 24 AB
6- 4 LX-BZA292JBE0 Special screw 19 AC
6- 5 LX-BZA166JBE0 Special screw 1 AB
6- 6 LX-NZA048JBE0 Special nut 4 AA
6- 7 XCPSD40P25000 Tapping screw 1 AC
6- 8 XCTSD40P12000 Tapping screw [AU-N45DP2] 2 AA
6- 8 XCTSD40P12000 Tapping screw [AU-N56DP2] 4 AA
6- 9 XCTSD40P40000 Tapping screw 2 AA
6-10 LX-BZA075JBE0 Special screw 1 AA
PACKING PARTS
7- 1 CPADBA050JBKZ Bottom pad assembly 1 AM
7- 2 CPADBA051JBKZ Packing pad assembly 1 AM
7- 3 SPAKCB322JBEZ Packing case [AU-N45DP2] 1 AX
7- 3 SPAKCB323JBEZ Packing case [AU-N56DP2] 1 AX
To Next Page
