ENG-
E-3
1
Inlet (Air)
2
Open Panel
3
Air Filter
4
AUX Button
5
Receiver Window
6
Power Supply Cord
7
Vertical Airflow Louvre
8
Horizontal Airflow Louvre
9
Outlet (Air)
10
PLASMACLUSTER Lamp
(blue
)
11
OPERATION Lamp (red
)
12
TIMER Lamp (orange
)
13
POWERFUL JET Lamp
(blue
)
14
Inlet (Air)
15
Refrigerant Pipe and
Interconnecting Cord
16
Drainage Hose
17
Outlet (Air)
NOTE:
Actual units might vary slightly
from those shown above.
INDOOR UNIT
OUTDOOR UNIT
1
2
3
4
5
6
7
8
9
14
15
16
17
14
15
16
17
AU-PN19
AU-PN24
10
11
12
13
AH-PN19, AH-PN24
OM_AH-PN10 13GY_EN.indd Sec1:3OM_AH-PN10 13GY_EN.indd Sec1:3 12/22/11 6:30:11 PM12/22/11 6:30:11 PM
