DEFINITION
The definition of each Rank is as follows and also noted in the list
Rank A : Maintenance parts, and consumable parts which are not included in but closely related to maintenance parts
Rank B : Performance/function parts (sensors, clutches, and other electrical parts), consumable parts
Rank E : Unit parts including PWB
Rank D : Preparation parts (External fitting, packing, parts packed together)
Rank C : Parts other than the above (excluding sub components of PWB)
Because parts marked with " !" is indispensable for the machine safety m aintenance and operation, it m ust be re placed with
the parts specific to the product specification.
F Other than this Parts Guide, please refer to documents Service Manual(including Circuit Diagram)of this model.
F Please use the 13 digit code described in the right hand corner of front cover of the document, when you place an order.
F For U.S. only-Use order codes provided in advertising literature. Do not order from parts department.
* These parts are supplied by SMF.
1
Exteriors
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1 CCAB-0003QS47 AR N D Front cover
2 LSOU-0042QSZ1 AY D Delivery tray
3 XEBSE30P08000 AA C Screw(3×8)
4 LSOU-0043QSZ1 AH D Extension tray
5 XEBSE40P12000 AA C Screw(4×12)
6 PTPE-0041QSZZ AB C Glass fixing tape B
7 DHAI-0428QSZZ AH C OP-MCU harness
8 PSHEZ0369QSZZ AE C Shading sheet
9 XBBSE30P08000 AA C Screw(3×8)
10 GCAB-0061QSZ3 AL D Left exterior
11 TLABH0560QSZZ AF C Operation instruction label
12 GCOV-0045QSZ4 AH D Rear cover SPF
13 CFIX-0021QS16 AH D Glass fixing plate
14 PGLSP0007QSZZ AV B Table glass
15 PTPE-0059QSZZ AC N C Glass fixing tape
16 GCOV-0058QSZZ AH D NWB option cover
17 GCAB-0062QSZ6 AM D Right exterior SPF
18 GCAB-0087QSZ3 AX N D Rear exterior SPF
19 TCAUA0770FCZZ AB D Service caution label
20 PMLT-0024QSZZ AC C Fan cushion
21 PFILZ0002QSZZ AL D Ozone filter
22 PTPE-0044QSZZ AC C Slit glass tape
23 PGLSP0008QSZZ AH B SPF glass
25 PTPE-0010QSZZ AC C Slit glass tape
26 XHBSE30P08000 AA C Screw(3×8)
27
TLABZ0058QSZZ AD D Class 1 label (Australia,New Zealand,Iran)
TLABZ0531TSZZ * N D Class 1 label (Other Countries)
28 PSHEZ0404QSZZ AF C Right cabinet ground sheet
29 PTPE-0047QSZZ AC C Ground tape F
30 PTPE-0048QSZZ AA C Ground tape R
31 PTPE-0049QSZZ AC C Right cabinet ground tape
32 PTPE-0060QSZZ AC N C Glass aluminum tape
33 PGSK-0034QSZZ AE N C Gasket
34 PMLT-0069QSZZ AA C Ground malt
501 CFIX-0021RS55 BA E Table unit
