AR-M205 SIMULATIONS 7-11
43 01 Fusing temperature setting
(During normal copy)
When the simulation is terminated, the current set value is displayed. When the [%] key is pressed,
the setting is changed. When the [START] key is pressed, the set content is written into the EEPROM
and the machine goes into the sub code input standby mode.
10 Postcard paper feed cycle setting Used to set the paper feed cycle timing in postcard printing. (Pickup interval)[1] ~ [99]
(Center [50], Unit: 100msec)(Example: When 50, pickup interval = 100msec x 50)
11 Postcard size paper fusing
temperature setting
When this simulation is executed, the current set value is displayed. When the [%] key is pressed, the
setting is changed. When the [START] key is pressed, the set content is written into the EEPROM
and the machine goes into the sub code input standby mode.
12 Standby mode fusing fan rotation
setting
When this simulation is executed, the current set code number is displayed. Enter the desired code
number and press the [START] key to set the code number.
13 Fusing paper interval control allow/
inhibit setting
Used to set the paper feed timing of 21st and later page to A3 or WLT when multi copying or printing
paper of narrow width. (A3 or WLT depends on the destination.)
When this simulation is executed, the currently set code number is displayed. Enter a desired code
number and press the [START] key, and the entered code number is written into the EEPROM and
the machine goes into the sub code entry standby mode.
<Applicable paper>
1) Cassette paper feed: A4R, B5R, 8-1/2" X 14", 8-1/2" X 13", 8-1/2" X 11", A5, INV
2) Manual paper feed: A4R, B5R, 8-1/2" X 14", 8-1/2" X 13", 8-1/2" X 11", A5, INV,16KR
* A5 size for manual paper feed is valid only for EX Japan AB series.
44 34 Transfer current setting Used to set the transfer current for the front surface and that for the back surface. When this
simulation is executed, the current set value is displayed on the 7-seg display. Select the set value
with the zoom (Up/Down) keys and press the [START] key, and the set content is written into the
EEPROM and the machine goes into the sub code input standby mode. Press the [Mode select] key
to select each setting mode. At that time, the setup content is written into the EEPROM.
The set range is 90uA ~ 360uA in the increment of 10uA.
* Small size paper must be Letter R (A4R) or smaller.
* For the special size of tray, use the normal size width.
40 Setting of rotation time before
toner supply
Used to set the time interval between start of rotation (ready) of the main motor and start of toner
supply in previous rotation after supplying the power. [1] ~ [99] (Default [8], unit: sec)
Main
code
Sub
code
Contents Details of operation
Set temperature (°C) Set temperature (°C)
160
165
170 * Default
175
180
185
190
195
200
Set temperature (°C) Set temperature (°C)
160
165
170
175
180
185
190
195 * Default
200
Code number Setting
0
1
Low speed rotation *Default
High speed rotation
Code number Setting
0
1
Inhibit * Default
Allow
Display lamp Setting mode
AE mode lamp
TEXT mode lamp
AE mode lamp & PHOTO mode lamp
TEXT mode lamp & PHOTO mode lamp
AE & TEXT & PHOTO mode lamps
Normal size width: Front
Normal size width: Back
Small size width: Front
Small size width: Back
Manual paper feed
!"#$
