AR-M350 TROUBLE CODES 11-12
C. Operation mode in FAX send/receive operations
O : Operation enable X : Operation disable
1 : Enable in other than trouble tray
2 : Go to FAX status check menu, and printing of list is allowed.
: Received document is outputted.
3 : Paper exit enable to other tray than trouble one.
D. Trouble mode process
E. Writing to the trouble memory
In this series, the simulation (diag) allows to select whether the same trouble is written to the trouble memory when it occurs. If the DIAG simulation is
set as above, when any trouble occurs, its hysteresis is written to the trouble memory. DIAG(SIM 26-35)
0: The same trouble as the previous one is not recorded. (Default)
1: When a trouble occurs, it is written to the trouble memory without exception.
Trouble Trouble code
Operation enable mode
Send reservation Print Send call Receive call Note
PCU general troubles O X O O Note Possibly causing memory full.
Paper feed tray trouble F3,U6 O 1 O O
Paper exit section trouble F1 O 3 O O
Scanner general troubles X O O O
FAX trouble F6,F7 X X X X
ICU trouble E7(01,06,80,90) X X X X
ICU memory error U2(00,11,12) X X X X
RIC external communication trouble, PF U7 X X X X
Backup battery voltage fall U1 X 2 X Note X Transfer enable
Door open O X O O Note Possibly causing memory full.
Toner empty O X O O Note Possibly causing memory full.
No process cartridge, etc. O X O O Note Possibly causing memory full.
Paper empty O X O O Note Possibly causing memory full.
Paper jam O X O O Note Possibly causing memory full.
Document jam X O O O
Simulation X X X X
Key operation (Communication disable) X X X X
Machine operation possible
depending on conditions
Operations except for the trouble mode are possible (READY).
For the mode where operations are impossible, only setup can be allowed, and the message is provided to show
that operations are impossible. (NOT READY in this case.)
(Display)
A dialog is shown in case of a trouble. For the mode where operations are possible, the OK button is added to the
message. For the mode where operations are impossible, the OK button is not shown, and the process to cancel is
indicated.
Machine operation is impossible The trouble display is always shown, and all setup operations are invalid.
 $       !" #
