3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[1] OVEN PARTS
Electric parts
1-1 CHET-A027WRKZ BF Engine unit assembly (ENGINE UNIT ASSY)
1-2 FH-HZA110WREZ AP Thermistor (Engine) (THERMISTOR)
1-2 FH-HZA100WREZ AN Thermistor (Engine) (THERMISTOR) (Interchangeable)
1-3 RTHM-A149WRZZ AK Thermal cut-out (Engine) (SH THERMOSTAT)
1-3 RTHM-A144WRZZ AF Thermal cut-out (Engine) (SH THERMOSTAT) (Interchangeable)
1-5 RTHM-A132WRZZ AM Thermal cut-out (Fan) (THERMAL CUT OUT)
1-5 RTHM-A116WRE0 AK Thermal cut-out (Fan) (THERMAL CUT OUT) (Interchangeable)
1-5 RTHM-A148WRZZ AH Thermal cut-out (Fan) (THERMAL CUT OUT) (Interchangeable)
1-12 QSW-MA117WRE0 AE Antenna switch (SENSING SW)
1-15 FH-HZA109WREZ AN Thermistor (Oven) (THERMISTOR)
1-15 FH-HZA099WREZ AN Thermistor (Oven) (THERMISTOR) (Interchangeable)
1-16 RMOTDA248WRZZ AH Antenna motor (TURNTABLE MOTOR)
1-17 QSW-MA168WRZZ AK Door sensing switch (MICRO SWITCH A)
1-17 QSW-MA147WRZZ AG Door sensing switch (MICRO SWITCH A) (Interchangeable)
1-18 QSW-MA148WRZZ AF Monitor switch (MICRO SWITCH B)
1-18 QSW-MA169WRZZ AF Monitor switch (MICRO SWITCH B) (Interchangeable)
1-19 QSW-MA170WRZZ AK Secondary interlock switch (MICRO SWITCH C)
1-19 QSW-MA146WRZZ AM Secondary interlock switch (MICRO SWITCH C) (Interchangeable)
1-21 FHLD-A030WRKZ Tube pump assembly (PUMP HOLDER ASSY)
1-21-1 RMOTDA248WRZZ AH Pump motor (TURNTABLE MOTOR)
1-21-2 XHPS740P08K00 AB Screw : 4mm x 8mm (TAP TIGHT SCREW)
1-21-3 XEPS740P08000 AB Screw : 4mm x 8mm (TAP TIGHT SCREW)
1-21-4 PCUS-A234WREZ AC Cushion (CUSHION)
1-21-5 PTUBXA069WREZ AE Water tube (WATER TUBE)
1-21-6 LBND-A047WREZ AF Hose band (HOSE BAND)
1-22 RHET-A431WRZZ BF Convection heater (CONVECTION HEATER)
1-25 RLMPTA087WRZZ AL Oven lamp (OVEN LIGHT)
1-25 RLMPTA082WRZZ AL Oven lamp (OVEN LIGHT) (Interchangeable)
1-25 RLMPTA085WRZZ AL Oven lamp (OVEN LIGHT) (Interchangeable)
1-25 RLMPTA096WRZZ AL Oven lamp (OVEN LIGHT) (Interchangeable)
1-26 RMOT-A028WRZZ AN Ventilation fan motor (FAN MOTOR)
1-26 RMOT-A034WRZZ AU Ventilation fan motor (FAN MOTOR) (Interchangeable)
1-27 RV-MZA366WRZZ BB Magnetron (MAGNETRON)
1-28 RMOTEA490WRZZ BA Convection motor (CONVECTION MOTOR)
1-29 RMOT-A029WRZZ AT Exhaust fan motor (SIROCCO MOTOR)
1-29 RMOT-A035WRZZ AY Exhaust fan motor (SIROCCO MOTER) (Interchangeable)
1-30 RTHM-A137WRZZ AH Thermal cut-out (Convection) (THERMAL CUT OUT)
1-30 RTHM-A123WRZZ AK Thermal cut-out (Convection) (THERMAL CUT OUT) (Interchangeable)
1-31 FDTCTA240WRKZ AU Humidity sensor
Mechanical parts
8-1 LANGKB372WRPZ AE THERMO MOUNT PLATE
8-2 PCUS-A262WREZ AD CUSHION
8-3 DOVN-A794WRKZ BX OVEN CAVITY ASSEMBLY
8-3-1 FSFTTA068WRFZ SHAFT ASSEMBLY
8-13 HDECQA513WRFZ PANEL R
8-15 LANGQA784WRPZ AF CONVECTION TERMO ANGLE
8-16 PSHT-A021WRFZ AD SHUTTER
8-17 MSPRTA228WREZ AB LATCH SPRING
8-18 FDUC-A490WRYZ AN EXHAUST DUCT ASSEMBLY
8-21 LANGKB126WRPZ AK TT MOTOR MOUNT ANGLE
8-22 FSLDHA077WRYZ AS HEAT COVER R ASSEMBLY
8-23 MLEVPA296WRFZ AG SWITCH LEVER
8-25 PPAC-A113WREZ AC STEAM DUCT PACKING L
8-26 PDUC-B181WRFZ AN STEAM DUCT ORG
8-27 PDUC-B132WRFZ AG FAN NOZZLE R
8-28 FTNK-A049WRKZ AY TANK ASSY (RESERVOIR)
8-28-1 PCOVPA525WRFZ AF TANK LID (RESERVOIR LID)
8-32 MJNTPA016WRFZ AG WL JOINT
8-33 MSPRPA106WREZ AF TANK SPRING
8-34 PCOVPA575WRFZ AQ TANK COVER
8-35 PCOVPA576WRFZ AH TANK COVER L
8-36 PJNT-A018WRFZ AD WL JOINT UPPER (WATER SENSOR)
8-37 PPAC-A131WREZ AC PUMP PACKING
8-39 LANGKB449WRPZ AF CONV. MOTOR MOUNTING ANGLE
8-40 LANGKB360WRPZ AL CONV. COVER ANGLE A
8-41 FANGKA229WRYZ AM CONV. COVER ANGLE ASSEMBLY
8-42
LANGKB364WRPZ AM CONV COVER ANGLE C
8-43 LBNDKA180WRPZ AE HEATER MOUNTING
8-44 NFANMA064WRWZ AF FAN BLADE
8-45 NFANMA069WRPZ AF COOLING FAN
8-46 PDUC-B086WRWZ BB CONVECTION DUCT
8-47 PFPF-A301WREZ AK HEAT INSULATION
8-48 PSLDHA281WRPZ AN CONV COVER
8-49 PSPA-A147WREZ AG SPACER
8-50 LANGKB315WRPZ AF SIDE AG
8-51 LANGKB340WRPZ AE REAR AG
8-52 LANGKB344WRPZ AH WATER PROOF AG
8-53 LANGKB353WRKZ AF OVEN SUPPORT AG
8-55 LANGQA792WRPZ AG LAMP MOUNTING ANGLE
8-64 PDUC-B131WRFZ AG FAN NOZZLE F
8-70 PCUS-A210WREZ AC CUSHION
8-72 PCUS-A212WREZ AC CUSSION
8-74 PCUS-A214WREZ AE CUSSION
*
*
To Next Page
