NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[2] CABINET PARTS
Accessory and packing
!
1-7 DPWBFC618WRUZ BP Inverter unit assembly (INV UNIT ASSY)
1-8 QACC-A137WRZZ AU Power supply cord (POWER SUPPLY CORD)
1-9 DPWB-B088DRKZ BP Control unit (CONTROL UNIT)
1-10 QFS-BA009WRE0 AH Fuse 20A (FUSE 20A)
1-11 FPWBFA457WRKZ BC Noise filter unit (NOISE FILTER)
1-14 RTRNPA188DRZZ AZ Transformer (TRANSFORMER)
1-20 RMOTEA489WRZZ AW Fan motor (Ventilation) (FAN MOTOR)
1-26 R MOT-A028WRZZ AN Cooling fan motor (FAN MOTOR)
1-26 R MOT-A034WRZZ AU Cooling fan motor (FAN MOTOR)
Cabinet parts
7-1 FCABDA055WRWZ AX BACK PLATE ASSY
7-2 FDAI-A360WRYZ AY BOTTOM PLATE ASSEMBLY
7-3 GCABUB173WRPZ BG OUTER CASE CABINET [R]
7-3 GCABUB276WRPZ BG OUTER CASE CABINET [W]
Mechanical parts
8-4 GCOVPA021WRFZ AF DRIP TRAY COVER [R]
8-4 GCOVPA035WRFZ AH DRIP TRAY COVER [W]
8-5 GCUPPA033WRFZ AQ DRIP TRAY [R]
8-5 GCUPPA037WRFZ AP DRIP TRAY [W]
8-6 GLEGPA108WRFZ AF BACK SHADE GUIDE
8-7 LHLDPA016WRFZ AK PWB HOLDER
8-8 PCUS-A221WREZ AC CUSHION
8-9 PGID-A119WRFZ AN DEW TRAY GUIDE L [R]
8-9 PGID-A121WRFZ AN DEW TRAY GUIDE L [W]
8-10 PGID-A120WRFZ AN DEW TRAY GUIDE R [R]
8-10 PGID-A122WRFZ AN DEW TRAY GUIDE R [W]
8-11 PPAC-A069WREZ AF STOPPER
8-12 PSKR-A508WRFZ AG DEW SHIELD [W]
8-12 PSKR-A509WRFZ AK DEW SHIELD [R]
8-19 FHNG-A39 2WRYZ AS LEFT HINGE ASSEMBLY
8-20 FHNG-A39 1WRYZ AS RIGHT HINGE ASSEMBLY
8-29 NFANJ A065WRFZ AK FAN BLADE
8-30 PC US-A199WREZ AE CUSHION
8-31 PDUC -B244WRFZ AQ FAN DUCT
8-54 LANGKB358WRPZ AF MOTOR ANGLE
8-56 LBNDKA166WREZ AD WIRE HOLDER
8-58 MCAMPA160WRMZ AL L DOOR CAM
8-59 MCAMPA161WRMZ AL R DOOR CAM
8-60 MSPRTA277WREZ DOOR SPRING-R
8-61 MSPRTA267WREZ AF DOOR SPRING L
8-62 PC OV-A109WR PZ AH FILTER COVER
8-63 PC OV-A155WR FZ AT EXHAUST COVER
8-65 PC US-A204WREZ AC CUSHION
8-66 PC US-A205WREZ AC CUSHION
8-67 PC US-A206WREZ AC CUSHION
8-68 TCAUAA3 68WRRZ AF CAUTION LABEL [R]
8-68 TCAUAA4 10WRRZ AC CAUTION LABEL [W]
8-72 PC US-A212WREZ AC CUSSION
8-77 PC US-A217WREZ AC CUSSION
8-79 PC US-A223WREZ AB DEW TRAY GUIDE CUSHION
8-89 PC US-A265WREZ AD CUSHION
8-94 PC US-A234WREZ AC CUSHION
8-95 PC US-A293WREZ AH CUSHION
8-98 GC AP-A020WR F Z AN STEAM CAP [R]
8-98 GC AP-A025WR F Z AL STEAM CAP [W]
8-115 PC US-A240WREZ AC BOTTOM CUSHION L
8-127 PSPAJA011WRFZ AF SIDE SPACER
Screw, washer and nut
9-1 XOTS740P10000 AB Screw : 4mm x 10mm
9-2 XOTS740P08000 AA Screw : 4mm x 8mm
9-4 XEBS730P10000 AA Screw : 3mm x 10mm
9-3 LX-BZA138WREZ AB Special screw
9-5 XHTS740P08000 AC Screw : 4mm x 8mm
9-7 XETS740P08000 AA Screw : 4mm x 8mm
9-8 XEPS740P25K00 AC Screw : 4mm x 25mm
9-24 XEPS740P10000 AA Screw : 4mm x 10mm
9-27 LX-NZA057WREZ AG Special nut
9-32 LX-C ZA088WREZ AB Special screw
9-34 LX-B ZA148WREZ AC Special screw
9-36
XEPS740P08000 AB Screw : 4mm x 8mm
9-37 XOBS740P30000 AC Screw : 4mm x 30mm
9-44 XHPS740P10XS0 AC Screw : 4mm x 10mm
9-46 LX-CZ0052WRE0 AA Special screw
*
*
*
*
*
*
