Sharp AY-AP9FHR Service Manual

AYAP7FHR
1 – 1
AYAP7FHR
Service Manual
CHAPTER 1. PRODUCT SPECIFICATION
[1] SPECIFICATION
1. AY-AP7FHR—AE-A7FHR
NOTE: The conditions of star(
✩
) marked items sre ‘ISO151’ : 1994(E), condition T1.
ITEMS
INDOOR UNIT OUTDOOR UNIT
AY-AP7FHR AE-A7FHR
Cooling capacity
✩
kW 2.05
Heat pump
Heating capacity
kW 2.4
Moisture removal
✩
Liters/h 0.7
Electrical data
Phase Single
Rated frequency Hz 50
Rated voltage range V 198 to 264
Rated voltage V 220 - 240
Rated current
✩
Cool A 3.0 - 2.8
Heat A 3.1 - 2.9
Rated input
✩
Cool W 635 - 635
Heat W 660 - 660
Power factor
✩
Cool % 96 - 94
Heat % 97 - 95
Compressor Type Hermetically sealed rotary type
Model 5RS084DAA01
Oil charge 300cc (RB68A or Freolalpha68M)
Refrigerant system Evaporator Louver fin and Grooved tube type
Condenser Corrugate fin and Grooved tube type
Control Capillary tube
Refrigerant volume 670g
De-Ice system Micro computercontroled reverse system
Noise level High dB(A) 37 44
Low dB(A) 33 –
Soft dB(A) 28 –
Fan system
Drive Direct drive
Air flow quantity High
m
3
/min.
7.3 28
Low
m
3
/min.
6.6 –
Soft
m
3
/min.
3.5 –
Fan Cross flow fan Propeller fan
Connections
Refrigerant coupling Flare type
Refrigerant tube size Gas, Liquid 3/8", 1/4"
Drain piping mm O.D φ18
Others
Safety device Compressor : Overload protector
Fan motor : Thermal Protector
Fuse, Micro computer control
Air filters Polypropylene net (Washable)
Net dimensions Width mm 810 730
Height mm 270 540
Depth mm 184 250
Net weight kg 9 28

Sharp AY-AP9FHR Specifications

General

AC input voltage	220-240 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Energy efficiency class (cooling)	A
Annual energy consumption (cooling)	410 kWh
Hourly energy consumption (cooling)	3.8 kWh
Energy efficiency class (heating) (Warmer heating season)	-
Annual energy consumption (heating) (Warmer heating season)	- kWh
Type	Split system
Multi-split	Yes
Product color	White
Hose length (max)	10 m
Refrigerating medium	R410A
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (nominal)	820 W
Cooling energy efficiency (EER, W/W)	3.21
Heating energy efficiency (COP, W/W)	3.61
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	855 W
Indoor unit depth	184 mm
Indoor unit width	810 mm
Indoor unit height	270 mm
Indoor unit weight	9000 g
Indoor units quantity	1
Indoor unit noise level (high speed)	55 dB
Outdoor unit depth	250 mm
Outdoor unit width	730 mm
Outdoor unit height	540 mm
Outdoor unit weight	32000 g
Outdoor unit noise level	61 dB
