Sharp AY-AP9FHR Service Manual

AYAP7FHR
2
[1] INDOOR UNIT PARTS
2-17
2-18
2-19
2-7
2-6
1-6
1-5
2-9
1-1
1-9
1-7
2-23
2-20-2
2-15
3-4
3-3
3-2
3-1
2-22-6
2-22-5
2-22-4
2-22-3
2-22-2
2-22-1
2-22
2-21-2
2-21-1
2-21
2-20-14
2-20-13
2-20-12
2-20-11
2-20-10
2-20-9
2-20-8
2-20-7
2-20-6
2-20-5
2-20-4
2-20-3
2-20-1B
2-20-1A
2-20-1
2-20
2-16
2-14
2-13
2-12
2-11
2-10
2-8
2-24
2-4
2-3
2-2
2-1
1-10
1-8

Sharp AY-AP9FHR Specifications

General

AC input voltage	220-240 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Energy efficiency class (cooling)	A
Annual energy consumption (cooling)	410 kWh
Hourly energy consumption (cooling)	3.8 kWh
Energy efficiency class (heating) (Warmer heating season)	-
Annual energy consumption (heating) (Warmer heating season)	- kWh
Type	Split system
Multi-split	Yes
Product color	White
Hose length (max)	10 m
Refrigerating medium	R410A
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (nominal)	820 W
Cooling energy efficiency (EER, W/W)	3.21
Heating energy efficiency (COP, W/W)	3.61
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	855 W
Indoor unit depth	184 mm
Indoor unit width	810 mm
Indoor unit height	270 mm
Indoor unit weight	9000 g
Indoor units quantity	1
Indoor unit noise level (high speed)	55 dB
Outdoor unit depth	250 mm
Outdoor unit width	730 mm
Outdoor unit height	540 mm
Outdoor unit weight	32000 g
Outdoor unit noise level	61 dB
