Sharp AY-AP9FHR - Indoor Unit (AY-AP12 FHR)

ENGLISH
1 AUX. Button
2 Inlet (Air)
3 Open Panel
4 Air Filters
5 Indicator
6 Receiver Window
7 Vertical Adjustment Louvres
8 Horizontal Adjustment Louvres
9 Outlet (Air)
0 Power Supply Cord
q Remote Control
w PLASMACLUSTER Lamp
(blue)
e TURBO Lamp (green )
r TIMER Lamp (orange )
t OPERATION Lamp (red )
OUTDOOR UNIT
NOTE: Actual units might vary slightly from those shown above.
INDOOR UNIT (AY-AP12FHR)
y Inlet (Air)
u Refrigerant Tube and
Interconnecting Cord
i Drainage Hose
o Outlet (Air)
