Sharp AY-AP9FHR User Manual

REMOTE CONTROL
1 TRANSMITTER
2 DISPLAY (Liquid Crystal Display)
3 ON/OFF Button
4 TEMP. Button
5 DISPLAY Button
6 PLASMACLUSTER Button
7 ONE-HOUR OFF TIMER Button
8 MODE Button
9 TIMER ON Button (for setting the timer)
0 FAN Button
q TIMER OFF Button (for setting the timer)
w SWING Button
e TIMER CANCEL Button
r TURBO Button
t RESET Button
y MODE SYMBOLS
: AUTO : HEAT
: COOL : DRY
u TURBO SYMBOL
i PLASMACLUSTER SYMBOL
o FAN SPEED SYMBOLS
: AUTO : Manual setting
p TEMPERATURE AND TIMER COUNT DOWN
INDICATOR
a TRANSMITTING SYMBOL
s TIMER ON/TIMER OFF INDICATOR
Indicates when timer on or timer off is set.
L.C.D. REMOTE CONTROL DISPLAY
1
2
3
4
5
6
7
8
9
0
q
w
e
r
t
y
u
i
o
p
a
s
PART NAMES
E-6

Sharp AY-AP9FHR Specifications

General

AC input voltage	220-240 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Energy efficiency class (cooling)	A
Annual energy consumption (cooling)	410 kWh
Hourly energy consumption (cooling)	3.8 kWh
Energy efficiency class (heating) (Warmer heating season)	-
Annual energy consumption (heating) (Warmer heating season)	- kWh
Type	Split system
Multi-split	Yes
Product color	White
Hose length (max)	10 m
Refrigerating medium	R410A
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (nominal)	820 W
Cooling energy efficiency (EER, W/W)	3.21
Heating energy efficiency (COP, W/W)	3.61
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	855 W
Indoor unit depth	184 mm
Indoor unit width	810 mm
Indoor unit height	270 mm
Indoor unit weight	9000 g
Indoor units quantity	1
Indoor unit noise level (high speed)	55 dB
Outdoor unit depth	250 mm
Outdoor unit width	730 mm
Outdoor unit height	540 mm
Outdoor unit weight	32000 g
Outdoor unit noise level	61 dB
