NAMES OF PARTS
Front Panel
1. Disc Number Selector Buttons
2. Disc Tray
3. Multi Indicator
4. Disc Skip Button
5. Open/Close Button
6. Extra Bass Indicator
7. FM Stereo Mode Indicator
8. FM Stereo Indicator
9. (VCD/CD) Repeat Indicator
10. (VCD/CD) Play Indicator
11. (VCD/CD) Pause Indicator
12. (VCD/CD) Disc Number Indicators
13. (VCD/CD/TUNER) Memory Indicator
14. Timer Play Indicator
15. Timer Record Indicator
16. Sleep Indicator
17. Spectrum Analyzer/Volume Level Indicator
18. (TAPE 2) Racord Indicator
19. Timer Set Indicator
20. (VCD) Digest Button
21. (VCD) Book Mark Button
22. (VCD) Skip/Previous Button
(CD) Track Down/Review Button
(TUNER) Preset Down Button
(TAPE 2) Rewind Button
23. (VCD) Skip/Next Button
(CD) Track Up/Cue Button
(TUNER) Preset Up Button
(TAPE 2) Fast Forward Button
24. Timer/Sleep Button
25. Clock Button
26. (VCD) Playback Control Auto/Off Button
27. (VCD/CD) Audio Mode Button
28. (VCD) On Screen Display On/Off Button
29. On/Stand-by Button
30. Equalizer Mode Selector Button
31. Dimmer Button
32. Extra Bass/Demo Mode Button
33. Headphone Socket
34. Function Selector Button
35. (TAPE 2) Record Pause Button
36. Memory/Set Button
37. (VCD) Stop/Return Button
(CD/TAPE) Stop Button
38. (VCD) Play/Repeat/Select/Resume Button
(CD) Play/Repeat Button
(TAPE) Play Button
39. Tuning and Time Up/Down Buttons
40. Volume Up/Down Button
41. (TAPE 1) Cassette Compartment
42. (TAPE 2) Cassette Compartment
CD-C1831V
123 45
6
7
8
9
10
11
12
13
14
15
16
1817
41 42
19
33 34 35 36 37 38 39 40
20 21 22 23
24
25
26
27
28
29
30
31
32
