Sharp CD-C470HCD-C470E

PRICE
RANK
DESCRIPTIONNO.
PART CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-C470H,C470E,C480H/CP-C470H,C470E,C480H
! R918 VRG-ST2EC101J J AB 100 ohm,1/4W,Fusible
R919,920 VRD-RT2HD102J J AA 1 kohm,1/2W
R921 VRD-ST2CD224J J AA 220 kohms,1/6W
R922 VRD-ST2CD393J J AA 39 kohms,1/6W
! R923 VRG-ST2EC101J J AB 100 ohm,1/4W,Fusible
R924 VRD-ST2EE222J J AA 2.2 kohms,1/4W
R925 VRD-ST2CD391J J AA 390 ohms,1/6W
R927,928 VRD-ST2EE4R7J J AA 4.7 ohms,1/4W
R931,932 VRD-RT2HD331J J AA 330 ohms,1/2W
R933~936 VRD-ST2EE6R8J J AA 6.8 ohms,1/4W
R937 VRD-ST2CD100J J AA 10 ohm,1/6W
R938 VRS-VV3DA681J J 680 ohms,2W
R951,952 VRD-ST2CD104J J AA 100 kohm,1/6W
R953,954 VRD-ST2CD102J J AA 1 kohm,1/6W
R955,956 VRD-ST2CD181J J AA 180 ohms,1/6W
R957 VRD-ST2CD103J J AA 10 kohm,1/6W
R959,960 VRD-ST2EE4R7J J AA 4.7 ohms,1/4W
R961,962 VRD-RT2HD271J J AA 270 ohms,1/2W
R965,966 VRD-ST2EE6R8J J AA 6.8 ohms,1/4W
R970 VRD-ST2CD563J J AA 56 kohms,1/6W
RD1 VRD-ST2CD102J J AA 1 kohm,1/6W
RD2 VRD-ST2CD122J J AA 1.2 kohms,1/6W
RD3 VRD-ST2CD182J J AA 1.8 kohms,1/6W
RD4 VRD-ST2CD222J J AA 2.2 kohms,1/6W
RD5 VRD-ST2CD392J J AA 3.9 kohms,1/6W
RD6 VRD-ST2CD562J J AA 5.6 kohms,1/6W
RD7 VRD-ST2CD123J J AA 12 kohms,1/6W
RD8 VRD-ST2CD102J J AA 1 kohm,1/6W
RD9 VRD-ST2CD122J J AA 1.2 kohms,1/6W
RD10 VRD-ST2CD182J J AA 1.8 kohms,1/6W
RD11 VRD-ST2CD222J J AA 2.2 kohms,1/6W
RD12 VRD-ST2CD392J J AA 3.9 kohms,1/6W
RD13 VRD-ST2CD562J J AA 5.6 kohms,1/6W
RD14 VRD-ST2CD123J J AA 12 kohms,1/6W
RD15 VRD-ST2CD122J J AA 1.2 kohms,1/6W
RD16 VRD-ST2CD182J J AA 1.8 kohms,1/6W
RD17 VRD-ST2CD222J J AA 2.2 kohms,1/6W
RD18 VRD-ST2CD392J J AA 3.9 kohms,1/6W
RD20 VRD-ST2CD562J J AA 5.6 kohms,1/6W
RD21 VRD-ST2CD123J J AA 12 kohms,1/6W
RD22 VRD-ST2CD102J J AA 1 kohm,1/6W
RD23 VRD-ST2CD122J J AA 1.2 kohms,1/6W
RD24 VRD-ST2CD182J J AA 1.8 kohms,1/6W
RD25 VRD-ST2CD222J J AA 2.2 kohms,1/6W
RD26 VRD-ST2CD392J J AA 3.9 kohms,1/6W
RD27 VRD-ST2CD562J J AA 5.6 kohms,1/6W
RD28 VRD-ST2CD123J J AA 12 kohms,1/6W
RD29 VRD-ST2CD102J J AA 1 kohm,1/6W
RD30 VRD-ST2CD122J J AA 1.2 kohms,1/6W
RD31 VRD-ST2CD182J J AA 1.8 kohms,1/6W
RD32 VRD-ST2CD222J J AA 2.2 kohms,1/6W
RD33 VRD-ST2CD392J J AA 3.9 kohms,1/6W
RD34 VRD-ST2CD562J J AA 5.6 kohms,1/6W
RD35 VRD-ST2CD123J J AA 12 kohms,1/6W
RD36 VRD-ST2CD563J J AA 56 kohms,1/6W
[CD-C470E Only]
RD37 VRD-ST2CD102J J AA 1 kohm,1/6W
RD38,39 VRD-ST2CD102J J AA 1 kohm,1/6W [CD-C480H Only]
RM02 VRD-MN2BD682J J AA 6.8 kohms,1/8W
RM03 VRD-ST2CD333J J AA 33 kohms,1/6W
RM05 VRD-ST2CD103J J AA 10 kohm,1/6W
RM06 VRD-ST2CD222J J AA 2.2 kohms,1/6W
RM07 VRD-RT2HD100J J AA 10 ohm,1/2W
RM08 VRD-ST2CD103J J AA 10 kohm,1/6W
RM09 VRD-ST2CD222J J AA 2.2 kohms,1/6W
RM1 VRD-ST2CD272J J AA 2.7 kohms,1/6W
RM10 VRD-ST2CD122J J AA 1.2 kohms,1/6W
RM11 VRD-MN2BD222J J AA 2.2 kohms,1/8W
RM12 VRD-ST2CD333J J AA 33 kohms,1/6W
RM14~16 VRD-ST2CD103J J AA 10 kohm,1/6W
RM17 VRD-ST2CD103J J AA 10 kohm,1/6W [CD-C480H Only]
RM18 VRD-ST2CD222J J AA 2.2 kohms,1/6W
[CD-C480H Only]
RM19 VRD-MN2BD332J J AA 3.3 kohms,1/8W
RM20 VRD-MN2BD103J J AA 10 kohm,1/8W
RT21 VRD-ST2CD104J J AA 100 kohm,1/6W
[CD-C470H/480H Only]
RT26 VRD-ST2CD102J J AA 1 kohm,1/6W
[CD-C470H/480H Only]
RT28 VRD-MN2BD102J J AA 1 kohm,1/8W
[CD-C470H/480H Only]
RT29 VRD-ST2CD102J J AA 1 kohm,1/6W
[CD-C470H/480H Only]
RT30 VRD-MN2BD102J J AA 1 kohm,1/8W
[CD-C470H/480H Only]
RT32 VRD-ST2CD103J J AA 10 kohm,1/6W
[CD-C470H/480H Only]
RT33,34 VRD-ST2CD563J J AA 56 kohms,1/6W
[CD-C470H/480H Only]
RT35~37 VRD-ST2CD224J J AA 220 kohms,1/6W
[CD-C470H/480H Only]
RT48,49 VRD-ST2EE391J J AA 390 ohms,1/4W
[CD-C470H/480H Only]
OTHER CIRCUITRY PARTS
BI99A/B QCNWN0723AWZZ J AM Connector Ass’y,3-3Pin
BI102/CNS102 QCNWN0941AWZZ J Connector Ass’y,6-7Pin
BI801/CNS801 QCNWN0904AWZZ J AE Connector Ass’y,6-6Pin
BIM5/CNS10/CNS QCNWN0894AWZZ J AH Connector Ass’y,6-10-2Pin
CNP3A 92LCONE6P53253 J AC Plug,6Pin
CNP1 QCNCM931EAFZZ J AC Plug,5Pin
CNP2 92LCONE8P53253 J AC Plug,8Pin
CNP3 92LCONE6P53253 J AC Plug,6Pin
CNP10 QCNCM931KAFZZ J AD Plug,10Pin
CNP101 92LCONE3P5267X J AB Plug,3Pin
CNP102 92LCONE7P5267X J Plug,7Pin
CNP301 92LCONE-2P5268 J AB Plug,2Pin
CNP303 QCNCM010LAWZZ J AC Plug,10Pin [CD-C470E]
CNP303 QCNCM010MAWZZ J AC Plug,10Pin [CD-C470H/480H]
CNP501 QCNCM010LAWZZ J AC Plug,10Pin [CD-C480H Only]
CNP502 QCNCW010LAWZZ J AD Plug,12Pin [CD-C470E]
CNP502 QCNCW010MAWZZ J AD Plug,12Pin [CD-C470H/480H]
CNP801 QCNCM742FAFZZ J AB Plug,6Pin
CNPM1 QCNWN025NAWZZ J Flat Wire Holder
CNPM2 QCNCM030BAWZZ J AB Pin Header
CNS1A/B QCNWN0891AWZZ J AG Connector Ass’y,5-5Pin
CNS2A/B QCNWN0892AWZZ J AF Connector Ass’y,8-8Pin
CNS3A/B QCNWN0893AWZZ J AF Connector Ass’y,6-6Pin
CNS101 QCNWN0660AWZZ J AH Connector Ass’y,3Pin
CNS501 QCNCW010LAWZZ J AD Connector Ass’y,11Pin
[CD-C480H Only]
! F802,803 92LFUSE-T402-E J AD Fuse,T4A L 250V
! F804 92LFUSE-T162-E J AD Fuse,T1.6A L 250V
! F821 92LFUSE-T501-E J AD Fuse,T500mA L 250V
! F901,902 92LFUSE-T252-E J Fuse,T2.5A L 250V
! F951 92LFUSE-T162-E J AD Fuse,T1.6A L 250V
FE301 RTUNS0007AWZZ J AT FM Front End
FL701 VVKBJ549GK/-1 J AX FL Display
FW701 QCNWN0946AWZZ J AD Flat Wire,6Pin
FW702 QCNWN0944AWZZ J AD Flat Wire,10Pin
FW703 QCNWN0945AWZZ J AF Flat Wire,13Pin
FW901 QCNWN0969AWZZ J AE Flat Wire,9Pin
FW902 QCNWN0902AWZZ J AC Flat Wire,3Pin
FW903 QCNWN0903AWZZ J AE Flat Wire,5Pin
FWM1 QCNWN0943AWZZ J AF Flat Wire,13Pin
FWM2 QCNWN0942AWZZ J AC Flat Wire,4Pin
J501 QSOCJ0401AWZZ J AH Jack,Video/AUX
JA901 QJAKM0005AWZZ J AD Jack,Headphones
M1 92LMTR1858CASY J AS Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
M3 92LMTR2037AS1 J AP Motor with Worm Pulley
[T/T Up/Down]
MM1 RMOTV0060AWM2 J Motor with Pulley [Tape]
RX701 VHLSPSP440/-1 J AH Remote Sensor,SPSP440
SO301 QTANC0103AWZZ J AD Terminal,Antenna
SO901,902 QTANA0404AWZZ J AF Terminal,Speaker (Front/Rear)
SO903 QTANA0201AWZZ J AD Terminal,Speaker (Center)
SOLM1,2 92LM-SOL1676A J Solenoid Ass’y
SW1 QSW-P0004AWZZ J AE Switch,Push Type [Open/Close]
SW2 QSW-F0001AWZZ J AD Switch,Leaf Type [Mecha Up]
SW3 QSW-P0005AWZZ J AD Switch,Push Type [Disc Number]
SW4 QSW-F9001AWZZ J AE Switch,Leaf Type [Pickup In]
SW701 92LSWICHT1663T J AC Switch,Key Type
[ON/STAND-BY]
SW702 92LSWICHT1663T J AC Switch,Key Type [CLOCK]
SW703 92LSWICHT1663T J AC Switch,Key Type [TIME/SLEEP]
SW704 92LSWICHT1663T J AC Switch,Key Type [DISC 1]
SW705 92LSWICHT1663T J AC Switch,Key Type [DISC 2]
SW706 92LSWICHT1663T J AC Switch,Key Type [DISC 3]
SW707 92LSWICHT1663T J AC Switch,Key Type [DISC SKIP]
SW708 92LSWICHT1663T J AC Switch,Key Type
[OPEN/CLOSE]
– 7 –
