NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PART CODE
PRICE
RANK
DESCRIPTION
CD-C470H,C470E,C480H/CP-C470H,C470E,C480H
SW709 92LSWICHT1663T J AC Switch,Key Type [CD]
SW710 92LSWICHT1663T J AC Switch,Key Type
[TUNER/BAND]
SW711 92LSWICHT1663T J AC Switch,Key Type [TAPE]
SW712 92LSWICHT1663T J AC Switch,Key Type [VIDEO]
SW713 92LSWICHT1663T J AC Switch,Key Type [EON]
[CD-C470H/480H Only]
SW714 92LSWICHT1663T J AC Switch,Key Type
[PTY/TI SERCH]
[CD-C470H/480H Only]
SW715 92LSWICHT1663T J AC Switch,Key Type [ASPM]
[CD-C470H/480H Only]
SW716 92LSWICHT1663T J AC Switch,Key Type
[DISPLAY MODE]
[CD-C470H/480H Only]
SW717 92LSWICHT1663T J AC Switch,Key Type
[CENTER MODE/PHANTOM]
SW719 92LSWICHT1663T J AC Switch,Key Type
[CENTER MODE/NORMAL]
SW721 92LSWICHT1663T J AC Switch,Key Type
[DOLBY PRO LOGIC/BYPASS]
SW723 92LSWICHT1663T J AC Switch,Key Type [REC/PAUSE]
SW724 92LSWICHT1663T J AC Switch,Key Type
[TUNING UP/TIME]
SW725 92LSWICHT1663T J AC Switch,Key Type [VOLUME UP]
SW726 92LSWICHT1663T J AC Switch,Key Type [X-BASS]
SW727 92LSWICHT1663T J AC Switch,Key Type
[4-SP SURROUND]
[CD-C480H Only]
SW728 92LSWICHT1663T J AC Switch,Key Type [STOP]
SW729 92LSWICHT1663T J AC Switch,Key Type [FWD]
SW730 92LSWICHT1663T J AC Switch,Key Type [FF]
SW731 92LSWICHT1663T J AC Switch,Key Type
[MEMORY SET]
SW732 92LSWICHT1663T J AC Switch,Key Type
[TUNING DOWN/TIME]
SW733 92LSWICHT1663T J AC Switch,Key Type
[VOLUME DOWN]
SW734 92LSWICHT1663T J AC Switch,Key Type
[EQUALIZER/DEMO]
SW735 92LSWICHT1663T J AC Switch,Key Type
[3D SURROUND]
SW736 92LSWICHT1663T J AC Switch,Key Type
[REVERSE MODE]
SW737 92LSWICHT1663T J AC Switch,Key Type [REV]
SW738 92LSWICHT1663T J AC Switch,Key Type [REW]
SW739 92LSWICHT1663T J AC Switch,Key Type
[EDIT NORMAL]
SW740 92LSWICHT1663T J AC Switch,Key Type [EDIT HIGH]
SWM1 92LM-SW1676A J AC Switch,Push Type [T1 CrO2]
SWM2 92LM-SW1676A J AC Switch,Leaf Type [T2 CrO2]
SWM3 92LM-SW1676A J AC Switch,Leaf Type [REC FWD]
SWM4 92LM-SW1676A J AC Switch,Leaf Type [REC RVS]
SWM5 QSW-F9003AWZZ J AG Switch,Leaf Type [F.A.S.]
SWM6 92LM-SW1676B J Switch,Leaf Type [CAM]
WT502 92LCONE7P52287 J AC Socket,Wire Trap,7Pin
WT601 QCNCW012NAWZZ J AE Socket,Wire Trap,13Pin
WT901 92LCONE9P52287 J AC Socket,Wire Trap,9Pin
WT903 92LCONE5P52287 J AC Socket,Wire Trap,5Pin
WTM1 QCNCW012NAWZZ J AE Socket,Wire Trap,13Pin
CASSETTE MECHANISM PARTS
1 LCHSM0039AWM1 J Main Chassis Ass’y
2 LPLTP0001AWZZ J AD Plate,Head [Tape 1]
3 LDAIH0002AWZZ J AD Plate,Head [Tape 2]
4 NDAIR0004AW01 J AG Take-Up Reel Ass’y [Tape 1]
7 NROLY0003AWM1 J AF Pinch Roller Foward Ass’y
8 NFLYC0012AWM1 J AG Flywheel Ass’y [Tape 1]
9 NFLYC0013AWM1 J AG Flywheel Foward Ass’y [Tape 2]
11 MCAMP0005AWZZ J AC Gear,Cam
13 NGERH0030AWZZ J AE Gear,Play Idler
15 NPLYB0004AWZZ J AB Sensor,Wing
16 MLEVP0060AWZZ J AB Lever,Trigger
17 MLEVP0027AWZZ J AC Lever,Lock [Tape 1]
18 MLEVP0028AWZZ J AC Lever,Eject Obstruct [Tape 1]
19 MLEVP0061AWZZ J AB Lever,Eject Obstruct [Tape 2]
20 LHLDS1001AW01 J AE Bearing Holder Ass’y
22 PGIDM0009AWZZ J AC Guide,Cassette [Tape 1]
23 MLEVF0011AWFW J AD Lever,Over Strok [Tape 1]
24 MLEVF0012AWM1 J AE Lever,Over Strok Ass’y [Tape 2]
25 MLEVF0015AWM1 J AE Lever,Mode Ass’y
26 MLEVF0007AW01 J AC Lever,Idler Ass’y [Tape 1]
28 LANGT0039AWFW J AC Blacket Motor
29 LANGT0040AWFW J AC Blacket Hold
31 MSPRP0005AWFW J AB Spring,Cassette
32 MSPRT0007AWFJ J AB Spring,Reverse Plate
33 MSPRD0031AWFJ J AB Spring,Lock Lever [Tape 1]
34 MSPRD0081AWFJ J AB Spring,Mode Lever
35 MSPRD0033AWFJ J AB Spring,Play Idler Lever
36 MSPRD0034AWFJ J AB Spring,Play Roller
37 MSPRD0035AWFJ J AB Spring,Eject Obstruct [Tape 1]
39 MSPRD0037AWFJ J AB Spring,Over Strok Lever
40 MSPRD0083AWFJ J AB Spring,Trigger Lever
42 MSPRD0082AWFJ J AB Spring,Over Stroke Lever
[Tape 2]
43 NBLTK0021AWZZ J AB Belt,Sub
44 NBLTH0003AWZZ J AC Belt,Main [Tape 1]
45 NBLTH0004AWZZ J AC Belt,Main [Tape 2]
52 92LM-LEV1756A J AB Lever,Lock [Tape 2]
53 92LM-TSPR1756C J AB Spring,Lock Lever [Tape 2]
55 92LM-RPH1746A J AM Head,Playback [Tape 1]
56 RHEDK0002AWM1 J AQ Head,Record/Playback/Erace
with Flexible PWB [Tape 2]
58 MSPRC0019AWFJ J AB Spring,Back Tension
59 92LN-BAND1318A J AA Nylon Band,80mm
60 PGIDM0020AWZZ J AB Head Bobbin
61 LPLTM0005AWZZ J AC Head Support
62 NDAIR0007AWZZ J AB Reel Table
63 NROLY0004AWM1 J AF Pinch Roller Reverse Ass’y
64 NROLY0002AWZZ J AF Pinch Roller Ass’y
65 NFLYC0014AWM1 J AF Flywheel Reverse Ass’y [Tape 2]
66 MLEVP0059AWM1 J AH Drive Lever Ass’y
67 NGERH0060AWZZ J AB Gear,FF Idlar
68 MLEVP0062AWZZ J AB Lever,H Change
69 MLEVP0063AWZZ J AB Lever,Switch
70 LHLDS1003AWM1 J AD Bearing Holder Forward Ass’y
71 LHLDS1004AWM1 J AD Bearing Holder Reverse Ass’y
72 MLEVF0013AWFW J AC Lever,Head Plate
73 MLEVF0014AWM1 J AE Reverse Plate Ass’y
74 MLEVF0016AWFW J AB Lever,Joint
75 MSPRD0084AWFJ J AB Spring,Driving Lever
76 MSPRD0085AWFJ J AB Spring,H Change
77 MSPRD0086AWFJ J AB Spring,Reel Support
78 MSPRD0087AWFJ J AB Spring,Reel Support
79 MSPRD0088AWFJ J AB Spring,Reel Support [Tape 1]
80 MSPRD0101AWFJ J AB Spring,Head Bobbin
501 LX-BZ0012AWFD J AA Screw,ø2.6×5mm
502 XHBSD20P04000 J AA Screw,ø2×4mm
503 XHBSD20P05000 J AA Screw,ø2×5mm
504 XWVSD22-03000 J AA Washer,ø2.2×0.3mm
505 LX-WZ9191AFZZ J AA Washer,ø2.3×ø3.4×0.25mm
506 LX-BZ0004AWFD J AC Screw,Lock Lever
507 LX-BZ0778AFFD J AA Screw,ø2×6mm
508 LX-WZ9064AFZZ J AA Washer,ø1.5×ø3.8×0.5mm
510 LX-WZ9230AFZZ J AA Washer,ø1.8×ø4×0.5mm
511 XSPSD14P08000 J Screw,ø1.4×8mm
513 XWSSD14-05000 J AA Washer,ø1.4×0.5mm
MM1 92LMTR2512AASY J AT Motor with Pulley [Tape]
SOLM1 92LM-SOL1676A J Solenoid Ass’y
SWM1 92LM-SW1676A J AC Switch,Leaf Type [T1 CrO2]
[CD-C480H Only]
SWM2 92LM-SW1676A J AC Switch,Leaf Type [T2 CrO2]
[CD-C480H Only]
SWM3 92LM-SW1676A J AC Switch,Leaf Type [REC FWD]
SWM4 92LM-SW1676A J AC Switch,Leaf Type [REC RVS]
SWM5 QSW-F9003AWZZ J AG Switch,Leaf Type [F.A.S.]
SWM6 92LM-SW1676B J Switch,Leaf Type [CAM]
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0010AWZZ J AC Rail,Guide
304 NSFTM0002AWFW J AE Shaft,Guide
305 92LM-CUSN1524A J AC Insulator
! 306 92LHPC1MASY J BG Pickup Unit Ass’y
306- 1 ———— — Pickup Unit
(Not Replacement Item)
306- 2 NGERR0043AFZZ J AC Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
701 92L2R6S+6CZ J AB Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 92L2S+3PZ J AA Screw,ø2×3mm
– 8 –
To Next Page
