PRICE
RANK
DESCRIPTIONNO.
PART CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-C470H,C470E,C480H/CP-C470H,C470E,C480H
704 92L1R5WC3R8R25 J AA Washer,ø1.5×ø3.8×0.25mm
M1 92LMTR1858CASY J AS Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
SW4 QSW-F9001AWZZ J AE Switch,Leaf Type [Pickup In]
CABINET PARTS
201 92LCAB2512AS1 J BC Front Panel Ass’y [CD-C470H]
201 92LCAB2513AS1 J BC Front Panel Ass’y [CD-C480H]
201 92LCAB2515AS1 J BA Front Panel Ass’y [CD-C470E]
201- 1 ———— — Front Panel
(Not Replacement Item)
201- 2 PCUSG0022AWZZ J AB Cushion,Leg
201- 3 HDECQ0186AWSA J AD Operation Panel
201- 3 JKNBZ0335AWSA J AC Knob,Tuner/Memory
201- 4 JKNBZ0336AWSA J AC Knob,Open/Close,Rec./Playback
201- 5 JKNBZ0337AWSB J AD Knob,X-BASS
201- 6 JKNBZ0346AWSA J AB Knob,Graphic Equalizer
201- 7 JKNBZ0347AWSA J AB Knob,Rec Pause
201- 8 JKNBZ0348AWSA J AH Knob,RDS
[CD-C470H/480H Only]
201- 9 JKNBZ0350AWSA J AD Knob,Open/Close
201-10 JKNBZ0353AWSA J AH Knob,Operation A
201-11 JKNBZ0354AWSB1 J AF Knob,Disc Number
201-12 JKNBZ0355AWSA1 J AH Knob,Dolby Pro
201-13 JKNBZ0356AWSA J AM Knob,Operation B
201-14 JKNBZ0349AWSA J AH Knob,SRS [CD-C480H Only]
201-15 JKNBZ0391AWSA J AD Knob,Function
202 GCAB-1045AWSB J AL Top Cabinet
203 GITAR0192AWSA J AM Back Board [CD-C470H]
203 GITAR0224AWSA J AQ Back Board [CD-C470E]
203 GITAR0225AWSA J AQ Back Board [CD-C480H]
204 GDORF0038AWSB J AF Cassette Holder,Tape 1
205 92LPNL2512AS1 J AM Amp.Panel Ass’y [CD-C470H]
205 92LPNL2513AS1 J AM Amp.Panel Ass’y [CD-C480H]
205 92LPNL2515AS1 J BA Amp.Panel Ass’y [CD-C470E]
205- 1 ———— — Amp.Panel
205- 2 92LBADGE1692A J AC Badge,SHARP
206 GDORF0039AWSB J AF Cassette Holder,Tape 2
207 HDECQ0217AWSA J AF Panel,Cassette,Tape 1
208 HDECQ0218AWSA J AF Panel,Cassette,Tape 2
209 92LCAB2503BS1 J AK Side Panel Ass’y,Left
209- 1 ———— — Side Panel,Left
(Not Replacement Item)
209- 2 PCUSG0022AWZZ J AB Cushion,Leg
210 92LCAB2503CS1 J AK Side Panel Ass’y,Right
210- 1 ———— — Side Panel,Right
(Not Replacement Item)
210- 2 PCUSG0022AWZZ J AB Cushion,Leg
211 GCOVA1135AWSC J AG Cover,CD Tray
213 MLIFP0003AWZZ J AE Damper
214 MSPRD0092AWFJ J AB Spring,Cassette,Tape 1
215 LCHSM0049AWFW J AM Main Chassis
! 216 QACCB0003AW00 J BA AC Power Supply Cord
[CD-C470E]
! 216 QACCE0008AW00 J AG AC Power Supply Cord
[CD-C470H/480H]
217 92LN-BAND1318A J AA Nylon Band,80mm
219 MSPRD0093AWFJ J AB Spring,Cassette Holder Up,Tape
2
227 MLEVP0068AWZZ J AB Lever,Change
228 LCHSZ0011AWZZ J AG Chassis,CD Mechanism
229 NGERK0004AWZZ J AB Gear,Bevel
230 MSPRC0021AWFJ J AB Spring,Worm Wheel
231 NGERW0006AWZZ J AC Gear,Worm Wheel
232 NPLYD0001AWZZ J AB Pulley
233 NGERK0005AWZZ J AB Gear,Loading
234 MLEVP0066AWZZ J AE Lever,Shift
235 NGERH0064AWZZ J AD Gear,Cam
236 NGERK0003AWZZ J AC Gear,Drive
237 LHLDZ1141AWZZ J AB Support,Pinch
238 NGERH0065AWZZ J AB Gear,Turntable
239 NBLTK0029AWZZ J AB Belt,Drive
240 MSPRD0044AWFJ J AB Spring,Lock Lever
241 MLEVP0067AWZZ J AC Lever,Lock
242 LCHSZ0010AWZZ J AM Chassis,Loading
243 NROLP0009AWZZ J AB Roller
244 MLEVP0070AWZZ J AB Lever,T/T Lock
245 MSPRC0020AWFJ J AB Spring,T/T Lock Lever
246 GCAB-1044AWSA J AM CD Player Base
247 LHLDZ1139AWSA J AD Support,Stabilizer
248 92LHOLD2037AS1 J AK Stabilizer Ass’y
248- 1 ———— — Stabilizer
(Not Replacement Item)
248- 2 PMAGF0001AWZZ J AF Magnet
248- 3 92LSUPT1749D J AA Bracket,Magnet
249 NTNT-0018AWSA J AK Turntable
250 LHLDZ1140AWZZ J AB Guide
251 LHLDZ1143AWZZ J AD Holder,FL Display
252 PRDAR0035AWFW J AQ Heat Sink B
253 PRDAR0049AWFW J AK Heat Sink,Transistor
254 PRDAR0073AWFW J AM Heat Sink,Main
255 LHLDZ1142AWZZ J AB Holder,LED
257 PCOVQ1004AWZZ J AF Heat Plate
! 258 92LFSHOLD1652T J AB Holder,Fuse
261 HDECQ0185AWSB J AD CD Top Panel
267 LANGK0070AWFW J AD PWB Bracket A
268 LANGK0071AWFW J AC PWB Bracket B
270 LANGT0038AWFW J AE Bracket,Heat Shield
271 PCUSG0027AWZZ J AB Cushion,Worm Wheel
272 MSPRC0024AWFW J AB Spring,Solenoid
276 PCOVU9004AW00 J AB Felt,Operation Knob
277 LBSHC0002AWZZ J AD Bushing,AC Power Supply Cord
278 LHLDF1015AWZZ J AF Holder,Main PWB
279 LANGJ0005AWFW J AC Bracket,PWB Connect
[CD-C480H Only]
280 RCORF0002AWZZ J AE Core
281 PSLDM3029AWFW J AE Plate,Deck Shield
282 PSPAK0001AWZZ J AB Spacer,Power PWB
283 92LRDAT1587A J AC Heat Sink,Diode
284 92LCAUT1706A1 J AC Label,Class 3
285 92LCAUT1706B J AA Label,Class 3
286 LHLDZ1144AWZZ J AC Holder,LED
287 LHLDZ1105AWZZ1 J AD Holder,LED
288 LHLDZ1145AWZZ J AD Holder,LED [CD-C480H Only]
! 289 92LLUG1746A J AA Lug Terminal
293 PCUSG0029AWZZ J AC Cushion,CD Loading Chassis
294 92LCLMP1810P J Wire Holder
296 LHLDK9001AW00 J AB Holder,CD Digital Output
601 XESSD30P10000 J AA Screw,ø3×10mm
602 LX-JZ0022AFFD J AA Screw,ø3×8mm
603 XEBSD30P10000 J AA Screw,ø3×10mm
604 XJBSD30P06000 J AA Screw,ø3×6mm
605 XJBSD30P08000 J AA Screw,ø3×8mm
607 XJBSD30P14000 J AA Screw,ø3×14mm
608 XEBSF30P12000 J AA Screw,ø3×12mm
609 XJBSF30P08000 J AA Screw,ø3×8mm
610 LX-TZ0019AFZZ J AB Screw,Special
611 LX-HZ0082AFZZ J AA Screw,ø4×8mm
612 LX-JZ0010AFFD J AA Screw,ø3×10mm
613 LX-EZ0005AWFD J AA Screw,Special
617 LX-JZ0002AWFD J AA Screw,ø3×10mm
618 LX-LZ0002AW00 J AC Snap Rivet [CD-C480H Only]
619 XBPSD26P05JS0 J AA Screw,ø2.6×5mm
620 XEBSD26P12000 J AA Screw,ø2.6×12mm
622 XEBSD30P12000 J AA Screw,ø3×12mm
623 XJSSF30P10000 J AA Screw,ø3×10mm
624 XJBSD30P10000 J AA Screw,ø3×10mm
ACCESSORIES/PACKING PARTS
1 SPAKP0013AWZZ J AC Polyethylene Bag,Unit
2 SPAKA0132AWZZ J AK Packing Add.
3 SPAKC0490AWZZ J AT Packing Case [CD-C470H]
3 SPAKC0523AWZZ J AU Packing Case [CD-C470E]
3 SPAKC0524AWZZ J AY Packing Case [CD-C480H]
4 92LBAG1460C1 J AB Polyethylene Bag,Accessories
5 QANTL0005AWZZ J AG AM Loop Antenna
6 RRMCG0094AWSA J AS Remote Control [CD-C470H]
6 RRMCG0095AWSA J AS Remote Control [CD-C470E]
6 RRMCG0096AWSA J AX Remote Control [CD-C480H]
6- 1 92LLID1782A J AQ Battery Lid,Remote Control
7 TINSE0163AWZZ J AG Operation Manual [CD-C470E]
7 TINSZ0205AWZZ J AW Operation Manual [CD-C470H]
7 TINSZ0223AWZZ J AX Operation Manual [CD-C480H]
8 92LFANT1535A J AF FM Antenna
9 92LCARD1751A J AB Resistration Card
[CD-C470E Only]
10 92LBAG1770A J AB Polyethylene Bag,AC Plug
Adaptor [CD-C470E Only]
11 TLABZ0414AWZZ J AH Label,Feature [CD-C480H]
11 TLABZ0415AWZZ J AH Label,Feature [CD-C470H]
– 9 –
