Sharp CD-C471 W User Manual

CD-C471 W
SHARP PARTS GUIDE
MODEL
CD-C471 W
CD-C471 W mini component system consisting of
CD-C471W mini component system, front (CP-C471), senter
(GBOXS0006AWM6)and surround(GBOXSOOO7AWM6)
Speaker System.
“HOW TO ORDER REPLACEMENT PARTS”
To have your order filled promptly and correctly, please furnish the
following information.
1. MODEL NUMBER
2. REF. No.
Contact your nearest SHARP Parts Distributor to order.
3. PART NO.
4. DESCRIPTION
For location of SHARP Parts Distributor
* MARK: SPARE PARTS-DELIVERY SECTION
/------- Explanation of capacitors/resistors parts codes
Capacitors
VCC . . . . . . . . . . . . . . . Ceramic type
VCK . . . . . . . . . . . . . . . . . . . . . Ceramic type
VCT . . . . . . . . . . . . . . . . . . . . . Semiconductor type
VC l l MF . . . . . . . . . . . . Cylindrical type (without lead wire)
VC l l MN . . . . . . . . . . . . Cylindrical type (without lead wire)
VC l l TV . . . . . . . . . . . . . Square type (without lead wire)
VC l l TQ . . . . . . ..__.. Square type (without lead wire)
VC l l CY ...___..,.,,.. Square type (without lead wire)
VC l l CZ . . . . . . . . . . . . . Square type (without lead wire)
VC l l l l l l l l l J The 13th character represents capacity difference.
(“J” r5%, “K” +I O%, “M” +20%, “N” +30%,
“‘2” +0.25 pF, “D” 20.5 pF, “Z” +80-20%.)
Resistors
VRD . . . . . . . . . . . . . . . .._.... Carbon-film type
VRS . .._............... Carbon-film type
VRN . . . .._.._.............. Metal-film type
VR l l MF . . . . . . . . . . . . . Cylindrical type (without lead wire)
VR l l MN ..,,_,,,,,,,,., Cylindrical type (without lead wire)
VR l l TV ._.............. Square type (without lead wire)
VR l l TQ . . . .._..... Square type (without lead wire)
VR l l CY . .._______..... Square type (without lead wire)
VR l l CZ . . Square type (without lead wire)
VR l l l l l l l l l J . The 13th character represents error.
(“J” +5%, “F” +I%, “D” *0.5%.)
If there are no indications for other parts, the resistors are 6%
If there are no indications for the electrolytic capacitors, error is ?20%.
carbon-film type.
\
i
NOTE:
Parts marked with “A” are important for maintaining the safety of the set.
Be sure to replace parts with specified ones for maintaining the safety and performance of the set.
