Sharp CD-C602 User Manual

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-C602,CPC602
C224 VCEAEA1HW335M J AB 3.3 µF,50V,Electrolytic
C227,228 VCKYMN1HB102K J AA 0.001 µF,50V
C229,230 VCEAEA1CW226M J AB 22 µF,16V,Electrolytic
C231,232 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
C235,236 VCTYMN1CX332K J AA 0.0033 µF,16V
C237,238 VCEAEA1HW105M J AB 1 µF,50V,Electrolytic
C239 VCQYKA1HM823K J AC 0.082 µF,50V,Mylar
C240 VCEAEA1CW226M J AB 22 µF,16V,Electrolytic
C241 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C242 VCQYKA1HM392K J AA 0.0039 µF,50V,Mylar
C243 VCQYKA1HM273K J AB 0.027 µF,50V,Mylar
C244 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C246 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C265 VCEAEA1HW475M J AB 4.7 µF,50V,Electrolytic
C301 VCKYMN1HB820K J AA 82 pF,50V
C302 VCCSMN1HL6R8K J AA 6.8 pF,50V
C312 VCCSMN1HL100J J AA 10 pF,50V
C313 VCTYMN1CX472K J AA 0.0047 µF,16V
C314 VCCUMN1HJ4R7D J AA 4.7 pF (UJ),50V
C315 VCTYMN1CY103N J AA 0.01 µF,16V
C316 VCTYMN1CX472K J AA 0.0047 µF,16V
C317 VCCSMN1HL4R7C J AA 4.7 pF,50V
C318 VCKYMN1HB102K J AA 0.001 µF,50V
C319 VCTYMN1EF223Z J AA 0.022 µF,25V
C320 VCKYMN1HB102K J AA 0.001 µF,50V
C321 VCTYMN1EF223Z J AA 0.022 µF,25V
C322 VCCCMN1HH150J J AA 15 pF (CH),50V
C323 VCCSMN1HL180J J AA 18 pF,50V
C324 VCCUMN1HJ3R3K J AB 3.3 pF (UJ),50V
C325 VCCCMN1HH220J J AA 22 pF (CH),50V
C326 VCTYMN1EF223Z J AA 0.022 µF,25V
C327 VCKYMN1HB101K J AA 100 pF,50V
C328 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C331 VCKZPA1HF223Z J AA 0.022 µF,50V
C332 VCKYMN1HB102K J AA 0.001 µF,50V
C333 VCCSPA1HL561J J AA 560 pF,50V
C336 VCCUMN1HJ220J J AA 22 pF (UJ),50V
C339 VCKZPA1HF473Z J AA 0.047 µF,50V
C342 VCTYMN1EF223Z J AA 0.022 µF,25V
C344 VCCUMN1HJ180J J AA 18 pF (UJ),50V
C351,352 VCTYMN1EF223Z J AA 0.022 µF,25V
C353 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C354 VCEAZA1AW227M J AC 220 µF,10V,Electrolytic
C355 VCTYMN1EF223Z J AA 0.022 µF,25V
C356 VCTYMN1CX222K J AA 0.0022 µF,16V
C357 VCTYMN0JY183M J AA 0.018 µF,6.3V
C358 VCKYMN1HB471K J AA 470 pF,50V
C359,360 VCEAEA1HW335M J AB 3.3 µF,50V,Electrolytic
C362 VCEAEA1HW335M J AB 3.3 µF,50V,Electrolytic
C363 VCEAEA1HW105M J AB 1 µF,50V,Electrolytic
C364 CPU100V1500PJ J AC 0.0015 µF,100V,Polypropylene
C371,372 VCQYKA1HM183K J AB 0.018 µF,50V,Mylar
C373,374 VCEAEA1HW105M J AB 1 µF,50V,Electrolytic
C383 VCTYMN1EF223Z J AA 0.022 µF,25V
C384 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C385 VCEAEA1HW105M J AB 1 µF,50V,Electrolytic
C387 VCKYMN1HB101K J AA 100 pF,50V
C388 VCKYMN1HB102K J AA 0.001 µF,50V
C390 VCCCMN1HH120J J AA 12 pF (CH),50V
C391 VCCCMN1HH150J J AA 15 pF (CH),50V
C392 VCKYMN1HB102K J AA 0.001 µF,50V
C393 VCEAEA1CW226M J AB 22 µF,16V,Electrolytic
C431~436 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
C439,440 VCEAEA1CW226M J AB 22 µF,16V,Electrolytic
C441,442 VCKYMN1HB181K J AA 180 pF,50V
C443,444 VCEAZA1HW684M J AB 0.68 µF,50V,Electrolytic
C445,446 VCQYKA1HM223K J AB 0.022 µF,50V,Mylar
C459,460 VCTYMN1CX272K J AA 0.0027 µF,16V
C461,462 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C463,464 VCKYMN1HB101K J AA 100 pF,50V
C465~468 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C471 VCKZPA1HF223Z J AA 0.022 µF,50V
C475 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C476 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
C481,482 VCEAEA1HW225M J AB 2.2 µF,50V,Electrolytic
C601,602 VCKYPA1HB102K J AA 0.001 µF,50V
C603,604 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C606 VCEAZA1EW227M J AC 220 µF,25V,Electrolytic
C607,608 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C609,610 VCEAZA1CW477M J AC 470 µF,16V,Electrolytic
C611,612 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C613,614 VCEAZA1HW226M J AB 22 µF,50V,Electrolytic
C701 VCKYMN1HB101K J AA 100 pF,50V
C702 VCTYMN1CY103N J AA 0.01 µF,16V
C703~705 VCKYMN1HB101K J AA 100 pF,50V
C706 VCEAEA1HW335M J AB 3.3 µF,50V,Electrolytic
C707~710 VCTYMN1CY103N J AA 0.01 µF,16V
C712 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C713 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C714 VCTYMN1EF223Z J AA 0.022 µF,25V
C716 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C717 VCTYMN1EF223Z J AA 0.022 µF,25V
C901,902 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
C903 VCEAZW1EW338M J AG 3300 µF,25V
C921,922 VCQYKA1HM223K J AB 0.022 µF,50V,Mylar
C923 VCEAZA1CW227M J AC 220 µF,16V,Electrolytic
C924 VCEAZA1EW477M J AD 470 µF,25V,Electrolytic
C925 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C926 VCKZPA1HF223Z J AA 0.022 µF,50V
C927 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
RESISTORS
VRD-MN2BD000C J AA 0 ohm,Jumper,ø1.4×3.5mm,Ivory
R1 VRD-MN2BD102J J AA 1 kohm,1/8W
R2 VRD-MN2BD104J J AA 100 kohm,1/8W
R3 VRD-MN2BD153J J AA 15 kohms,1/8W
R4 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R5 VRD-MN2BD682J J AA 6.8 kohms,1/8W
R6 VRD-MN2BD101J J AA 100 ohm,1/8W
R7 VRD-MN2BD102J J AA 1 kohm,1/8W
R8 VRD-MN2BD123J J AA 12 kohms,1/8W
R9 VRD-MN2BD273J J AA 27 kohms,1/8W
R10 VRD-ST2CD823J J AA 82 kohms,1/6W
R11 VRD-MN2BD332J J AA 3.3 kohms,1/8W
R12 VRD-MN2BD153J J AA 15 kohms,1/8W
R13 VRD-MN2BD333J J AA 33 kohms,1/8W
R14 VRD-MN2BD103J J AA 10 kohm,1/8W
R15 VRD-MN2BD473J J AA 47 kohms,1/8W
R16 VRD-MN2BD152J J AA 1.5 kohms,1/8W
R17 VRD-MN2BD823J J AA 82 kohms,1/8W
R18 VRD-ST2CD335J J AA 3.3 Mohms,1/6W
R19 VRD-MN2BD393J J AA 39 kohms,1/8W
R20 VRD-MN2BD103J J AA 10 kohm,1/8W
R21 VRD-MN2BD563J J AA 56 kohms,1/8W
R22 VRD-MN2BD682J J AA 6.8 kohms,1/8W
R23 VRD-MN2BD122J J AA 1.2 kohms,1/8W
R24 VRD-MN2BD103J J AA 10 kohm,1/8W
R25 VRD-MN2BD122J J AA 1.2 kohms,1/8W
R26,27 VRD-ST2CD224J J AA 220 kohms,1/6W
R28,29 VRD-ST2CD102J J AA 1 kohm,1/6W
R30 VRD-MN2BD183J J AA 18 kohms,1/8W
R31 VRD-MN2BD103J J AA 10 kohm,1/8W
R32 VRD-MN2BD563J J AA 56 kohms,1/8W
R33 VRD-MN2BD562J J AA 5.6 kohms,1/8W
R34 VRD-MN2BD102J J AA 1 kohm,1/8W
R35 VRD-MN2BD471J J AA 470 ohms,1/8W
R36,37 VRD-MN2BD473J J AA 47 kohms,1/8W
R38 VRD-MN2BD333J J AA 33 kohms,1/8W
R39,40 VRD-MN2BD223J J AA 22 kohms,1/8W
R41 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R42 VRD-MN2BD561J J AA 560 ohms,1/8W
R43 VRD-MN2BD120J J AA 12 ohms,1/8W
R45 VRD-ST2CD102J J AA 1 kohm,1/6W
R46,47 VRD-MN2BD102J J AA 1 kohm,1/8W
R54 VRD-ST2CD102J J AA 1 kohm,1/6W
R56 VRD-MN2BD122J J AA 1.2 kohms,1/8W
R57 VRD-MN2BD273J J AA 27 kohms,1/8W
R58 VRD-MN2BD681J J AA 680 ohms,1/8W
R60 VRD-MN2BD102J J AA 1 kohm,1/8W
R73 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R74 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R75,76 VRD-MN2BD102J J AA 1 kohm,1/8W
R77,78 VRD-ST2CD102J J AA 1 kohm,1/6W
R82 VRD-MN2BD101J J AA 100 ohm,1/8W
R86~88 VRD-MN2BD102J J AA 1 kohm,1/8W
R89,90 VRD-ST2CD102J J AA 1 kohm,1/6W
R91,92 VRD-ST2CD103J J AA 10 kohm,1/6W
R93 VRD-ST2EE4R7J J AA 4.7 ohms,1/4W
R94 VRD-ST2EE560J J AA 56 ohms,1/4W
R95 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R96 VRD-MN2BD103J J AA 10 kohm,1/8W
R97 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R98 VRD-ST2CD103J J AA 10 kohm,1/6W
